FujiFilm CA-503/A Operation Manual

ENDOSCOPE COMPONENT
Cleaning Adapter
CA-503/A
OPERATION MANUAL
FW536C
1. Important Safety Information
For the USA Market - CAUTION:
Federal law restricts this device to sale by or on the order of a physician.
<Intended Use>
This product is the cleaning adapter used in combination with our endoscopes in
medical facilities.
Do not use this product for any other purpose.
<Precautions in Using This Product>
Before using this product, carefully read the Operation Manual (Cleaning, Disin-
fection and Storage) of the endoscope in use.
<Sterilization>
This product has not been sterilized.
When using this product, perform disinfection or sterilization at the level appro-
priate to the intended use, in accordance with the Operation Manual (Cleaning,
Disinfection and Storage) of the endoscope in use.
<Preparation and inspection before use>
Prior to using this product, prepare a spare one to avoid unexpected accidents such
as equipment failure. If a replacement is not available, you may not be able to con-
tinue endoscopic procedures.
Make sure to check this product before use according to the procedures provided
in the Operation Manual (Cleaning, Disinfection and Storage) of the endoscope
in use, to avoid unexpected accidents and take full advantage of this product's
capabilities. If the inspection result shows any defects, do not use this product and
consult your local dealer.
<Applicable Endoscope>
This product is used in combination with our endoscopes described in "3. Main
Specification." Do not use this product in other combinations.
<Disposal>
When disposing of this product, comply with local laws and regulations in your
area. Determine whether or not this product is to be treated as infective waste, de-
pending on the use.
<Marks on the Package>
<Conventions Used in This Manual>
This manual uses the following conventions to make it easy to understand operations.
Convention
CAUTION
2. Method of Use
CAUTION
<Operation Procedure>
For details on how to use this product, refer to the Operation Manual (Cleaning,
Disinfection and Storage) of the endoscope in use.
3. Main Specification
<Operating Environment>
Temperature
Relative humidity
Atmospheric pressure : 70 to 106 kPa (within range of atmospheric pressure)
<Storage Environment>
CAUTION
Temperature
202B1261806A
Relative humidity
110912-2.0-DT-E2
Atmospheric pressure : 70 to 106 kPa (within range of atmospheric pressure)
Printed in Japan
<Applicable Endoscope>
This product is used in combination with our endoscopes.
The applicable endoscopes are listed in the following table.
For the endoscopes other than listed here, please consult your local dealer.
The list of applicable endoscopes (example)
200 series
EC-201WI
EC-201WL
EC-201WM
EC-250LP5
EC-250WI5-H-
EC-250WI5-S-
EC-250WL5-H-
EC-250WL5-S-
EC-250WM5
EG-201FP
EG-250CT5
EG-250PE5
EG-250WR5
EG-270N5
Marks Location
Package box
Package box
Explains situations that may cause damage to equipment if
not avoided.
Use this product only in combination with the our
endoscope. There is a risk of damaging the equipment.
: +10 to +40°C
: 30 to 85% (except when there is condensation)
Do not store this product in a place which does not meet
the storage environment. There is a risk of failure.
: +10 to +40°C
: 30 to 85% (except when there is condensation)
400 series
EC-450BI5 EC-530FI
EC-450LP5 EC-530FL
EC-450WL5 EC-530FM
EC-450WM5 EC-530IT
ED-450XL5 EC-530LP
EG-450PE5 EC-530LT
EN-450P5/20 EC-530MP-H-
EN-450T5 EC-530MP-S-
EC-530MT
EN-450T5/W
EC-530WI-H-
EC-530WI-S-
EC-530WL
EC-530WM-H-
EC-530WM-S-
EC-590WI
EC-590WL
EC-590WM
EC-590ZW/L
EC-590ZW/M-H-
ED-530XT
ED-530XT8
EG-530CT
EG-530FP
EG-530N
EG-530NP
EG-530WR
EG-590WR
EG-590ZW
ES-530WE
Meanings
Lot No.
Not sterilized
Meaning
500 series Other
FC-1Z
FG-1Z
FG-1ZP
