Owner 's Manual
REFRIGERATOR
FREEZER
Please read carefully the manual instruction and safety caution
before operating your refrigerator and retain it for future reference
G*-*372****
G*-*272****
P/No. : MFL68683054_Rev.02
G*-*222****
G*-*202****
Copyright ©
-
2020
LG Electronics Inc. All Rights Reserved
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG G 372 Series
Summary of Contents for LG G 372 Series
- Page 1 Owner ’s Manual REFRIGERATOR FREEZER Please read carefully the manual instruction and safety caution before operating your refrigerator and retain it for future reference G*-*372**** G*-*222**** G*-*272**** G*-*202**** www.lg.com P/No. : MFL68683054_Rev.02 Copyright © 2020 LG Electronics Inc. All Rights Reserved...
-
Page 2: Table Of Contents
IMPORTANT SAFET Y INFORMATION .. 3 CONTENTS INSTALLATION ..........10 FEATURE CHART .......... 11 OPERATION ............ 13 Starting Before Setting The Temperature Temperature Control Hygiene Fresh (Optional) Ice Making Defrosting Pull Out Tray (Optional) Deodorizer (Optional) Water Dispenser (Optional) SUGGESTIONS ON FOOD STORAGE..17 CLEANING ............. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION BASIC SAFETY PRECAUTIONS This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazard that can hurt you or others or cause damage to the product. All safety messages will be preceded by the safety alert symbol and the hazard signal word WARNING or CAUTION. - Page 4 • Children should be supervised to ensure that they do not play with the appliance. • If the supply cord is damaged, it must be replaced by LG Electronics Service Agent in order to avoid a hazard • This product uses an LED Lamp which can not be replaced by the user. Please contact authorized service centre for the lamp replacement.
- Page 5 IMPORTANT SAFETY INFORMATION 1. When connecting the power o not pull out the cord or touch the power Unplug the power plug when cleaning or plug with wet hands. handling the refrigerator. It may cause electric shock or injury. It may cause electric •...
- Page 6 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not install the refrigerator in the wet Do not use or store inflammable materials place or the place which ether, benzene, alcohol, medicine, LP gas, water or rain splashes. spray or cosmetics near or in the Deterioration of insulation of electric parts may cause...
- Page 7 IMPORTANT SAFETY INFORMATION 2. . When using the refrigerat Do not spray water at the outside or the When any strange smell or smoke is inside of the refrigerator or do not clean it detected from the refrigerator, disconnect with benzene or the power plug thinner.
- Page 8 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator When you want to dispose the refrigerator, Prevent children from entering the product. contact to the down-block office. It may endanger the life of a When you want to dispose child if the child enters the Down-block the large living waste such refrigerator.
- Page 9 IMPORTANT SAFETY INFORMATION CAUTION Violating this direction may cause injury or damage house or furniture. Always be careful, please. Do not install the refrigerator in the wet Do not insert the hands into the bottom of place or the place which water or rain the refrigerator.
-
Page 10: Installation
THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE AND UTILIZES THE LATEST IN TECHNOLOGY. WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH ITS PERFORMANCE AND RELIABILITY. BEFORE USING YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY. IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION, AND MAINTENANCE, AND ALSO SUPPLIES SOME USEFUL HINTS. -
Page 11: Feature Chart
FEATURE CHART DISPENSER MODEL FREEZER COMPARTMENT Freezer Temperature Freezer Door Rack Control Dial Optional) Freezer Shelf Twisting Ice Serve (Optional) or General Freezer Door Rack Type Ice Tray REFRIGERATOR Water Tank COMPARTMENT Lamp Deodorizer Movable Rack (Optional) (Optional) Pull out tray (Optional) Refrigerator Temperature Control Knob... - Page 12 FEATURE CHART NON DISPENSER MODEL FREEZER COMPARTMENT Freezer Temperature Freezer Door Rack Control Dial Optional) Freezer Shelf Twisting Ice Serve (Optional) or General Freezer Door Rack Type Ice Tray REFRIGERATOR Egg Storage Rack COMPARTMENT Lamp Deodorizer Movable Rack (Optional) (Optional) Pull out tray (Optional) Refrigerator Temperature...
-
Page 13: Operation
OPERATIONS STARTING When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures prior to filling it with fresh or frozen foods. If operation is interrupted, allow 5 minutes delay before restarting. BEFORE SETTING THE TEMPERATURE This refrigerator has one temperature control knob for the refrigerator compartment and one temperature control dial for the freezer compartment. -
Page 14: Hygiene Fresh (Optional)
OPERATIONS HYGIENE FRESH (OPTIONAL) CAUTION Before installing or using the product, make sure to read the owner's manual carefully to use the product accurately as intended. This HYGIENE FRESH filter has the antibacterial function of removing the virus or bacteria inside the refrigerator and the deodorizer function to remove the scent. ICE MAKING Determine which type ice-making system you have. -
Page 15: Pull Out Tray (Optional)
OPERATIONS PULL OUT TRAY (OPTIONAL) The pull out tray offers easy access to the rear of the food drawer by sliding the tray out. Please do not hold the bottom of the tray when slide the tray in, as it could catch your hand. How to remove the Pull Out Tray Fully extend the Pull-Out-Tray and lift the front then pull it out slowly. -
Page 16: Water Dispenser (Optional)
OPERATIONS WATER DISPENSER (OPTIONAL) Put water after the water tank being in position. Necessarilly separate the water tank to clean it or not use it. When the water tank is not position after filling it with water, water can leak out by the valve pushed. -
Page 17: Suggestions On Food Storage
SUGGESTIONS ON FOOD STORAGE STORING FOOD Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important � factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, pineapples, and �... -
Page 18: Cleaning
CLEANING WATER DISPENSER (OPTIONAL) Grille - Wipe with a wet cloth, and dry with a dry cloth. Water Tank - 1. Putting the Water Is not necessary to remove the water tank in order to supply it (it could be filled like shows fig. 1 pulling the tank gate). fig. -
Page 19: General Information
CLEANING It is important that your refrigerator be kept clean to Frost model which defrosts automatically, leave prevent undesirable odors. Spilled food should be both doors open during the entire cleaning process. wiped up immediately, since it may acidify and Disconnect the power supply, and remove food and stain plastic surfaces if allowed to settle. -
Page 20: Lamp Replacement
LAMP REPLACEMENT This product applies LED Lamp which can not be replaced by the user. Please contact authorized service centre for the lamp replacement. IMPORTANT WARNINGS ABOUT GROUNDING (EARTHING) DO NOT USE AN EXTENSION CORD In the event of an electric short circuit, grounding Use this appliance on a dedicated circuit;... -
Page 21: Before Calling For Service
BEFORE CALLING FOR SERVICE SERVICE CALLS CAN OFTEN BE AVOIDED! IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE POSSIBLE CAUSES FIRST : PROBLEM POSSIBLE CAUSES Has the power cord plug been removed or loosened THERE IS NO REFRIGERATION OR FREEZING from the electrical wall outlet? A fuse in your home may be blown or the circuit breaker... -
Page 22: Earth/ Grounding Construction (Optional)
It is recommended to install the earth wire to prevent electric shock in case of electricity leakage. How to connect the earth wire: • Connect the earth wire's metal ring end to the earth screw on the back of the refrigerator. •... -
Page 23: Smart Diagnosis
Installing the LG ThinQ Application Search for the LG ThinQ application from the Google Play Store or Apple App Store on a smart phone. • Follow instructions to download and install the application. • Run the LG ThinQ application and follow the instructions in the application to register the appliance.
