Onkyo DX-C120 Service Manual

b) On 40748) Cevy.0y ad) COxcy40)
ONKYO SERVICE MANUAL ©"
COMPACT DISC PLAYER
MODEL DX-C120 MODEL DX-C220
MODEL DX-C320
BMD, BMDN |120V AC, 60Hz
MP 230V AC, 50Hz
only DX-C220 | 120/220V AC, 50/60Hz
SAFETY-RELATED COMPONENT WARNING!! S Pp EC | F | C AT | O N S
COMPONENTS IDENTIFIED BY MARK A ON Compact Disc Automatic Changer Model DX-C320/C220/C120
THE SCHEMATIC DIAGRAM AND IN THE PARTS Signal readout system: Optical non-contact
LIST ARE CRITICAL FOR RISK OF FIRE AND Reading rotation: About 500 - 200 r.p.m.
ELECTRIC SHOCK. REPLACE THESE COM- | | (constant linear velocity)
PONENTS WITH ONKYO PARTS WHOSE PART Error correction system: Cross interleave Reed-Solomon code
NUMBERS APPEAR AS SHOWN IN THIS MANUAL. D/A converter: 1 bit PWM/ACCUPULSE
MAKE LEAKAGE-CURRENT OR RESISTANCE Sampling frequency: 352.8 kHz (8 times oversampling)
MEASUREMENTS TO DETERMINE THAT Number of channels: 2 (stereo)
EXPOSED PARTS ARE ACCEPTABLY IN- Frequency response: = 2Hz - 20kHz
SULATED FROM THE SUPPLY CIRCUIT BEFORE Total harmonic distortion: 0.004% (at 1kHz)
RETURNING THE APPLIANCE TO THE Dynamic range: = 6d
CUSTOMER. Signal to noise ratio: 96dB
Channel separation: 90dB (at 1kHz)
Wow and Flutter: Below threshold of measurability
Output level: 2 volts r.m.s.
Power consumption: 13 watts
Power supply rating: European and Australian models:
AC 230V, 50Hz
USA and Canadian models:
AC 120V, 60Hz
Worldwide model:
AC 120V and 220V
Dimensions (W x Hx D): 455 x 120 x 425 mm
(17-15/16" x 4-3/4" x 16-11/16")
Weight: 7.4 kg (16.3 lbs)
ONKYO.
AUDIO COMPONENTS
Specifications and external appearance are subject to change
1 without notice because of product improvements.
