GRAYHILL 3D2104 Series Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Series 3D2104 Development Kit
Quick Start Guide
Bulletin 1250 rev.0817

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3D2104 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GRAYHILL 3D2104 Series

Summary of Contents for GRAYHILL 3D2104 Series

  • Page 1 Series 3D2104 Development Kit Quick Start Guide Bulletin 1250 rev.0817...

  • Page 2: Revision History

    Revision History Revision Date Description 12/07/2018 Original Release 3D2104 Dev Kit – Quick Start Guide Bulletin XXXX rev.1218...

  • Page 3: Hardware Setup Instructions

    Introduction These instructions describe how to connect the 3D2104 Display to its development board and how to connect the power, Ethernet, CAN bus, and RS-232 serial bus. Equipment from Grayhill Included with 3D2104DEV-100 Kit  3D2104VT-100 Display  3D2104 Mounting Frame ...
  • Page 4 Connect the 35-pin DT cable to Breakout Board. Be sure to match Pin 1 on the cable to Pin 1 on the Breakout Board. Note that this connector is keyed. 3. Connect the power cable to the Breakout Board. 4. Connect DB9 serial cable to Breakout Board COM 1 port.
  • Page 5 8. Connect Ethernet cable to the Breakout Board. 9. Mount the frame with the 3D2104 Display to the Breakout Board using the 3 thumb screws provided. 10. Connect 35-pin DT cable to back of the 3D2104 Display. Note that this connector is keyed 3D2104 Dev Kit –...
  • Page 6 PC to CAN-bus Interface The Series 3D2104 Display device has three CAN bus interfaces that can be used for various purposes. The GridConnect USB-to-CAN adapter and software is a PC to CAN-bus interface that can be used for monitoring and sending messages on the CAN bus. The GridConnect software can be installed on the development PC as shown below: 1.

  • Page 7: Power Requirement

    Appendix A POWER REQUIREMENT Voltage: 12V Current: 1.5A J6, J7, J8, J9, J10, J11 J2, J3, J4 TE CONN TYCO PJ-002AH RCJ-014-SMT 555153-1 747844-6 J1 MAIN CONNECTOR Mating Connector HOUSING: DEUTSCH DT16-18-SA-K004 TERMINAL: DEUTSCH 0462-201-16141 BOARD LAYOUT SCHEMATIC 3D2104 Dev Kit – Quick Start Guide Bulletin XXXX rev.1218...

  • Page 8: System Connector (J1)

    SYSTEM CONNECTOR (J1) POWER SWITCHES VBAT (SW1), VSW (SW2) 3D2104 Dev Kit – Quick Start Guide Bulletin XXXX rev.1218...
  • Page 9 VIDEO INPUTS VIDEO1 (J2), VIDEO2 (J3), VIDEO3 (J4) ETHERNET CONNECTOR (J5) 3D2104 Dev Kit – Quick Start Guide Bulletin XXXX rev.1218...

  • Page 10: Can Connectors

    CAN CONNECTORS RS232 CONNECTORS CAN1 (J6), CAN2 (J7), CAN3 (J8) COM1 (J9), COM2 (J10), COM3 (J11) 3D2104 Dev Kit – Quick Start Guide Bulletin XXXX rev.1218...
