VXI Passport 10G User Manual

HOW TO WEAR YOUR HEADSET

1. Place the headset on your head.
2. Position the earpiece(s) directly on the ear(s).
3. Slide the headband in or out of the side support for proper fit.
4. Position the microphone about one finger's width away from your face
just below your lower lip. There is painted dot or the word "TALK" embossed
or printed on the plastic microphone housing. This mark must face your mouth
(see illustrations at right).

CHOOSE YOUR CONNECTION

A. Telephone Amplifier or Telephone / Computer Switchbox
1. Connect your headset to the amplifier/switchbox headset cord. Be sure the other end of this cord is
plugged into the headset port on the amplifier/switchbox (look for a headset icon). If necessary, consult
the amplifier/switchbox user guide to locate the correct port.
B. Direct-to-Telephone Headset Port (for headset compatible phones only)
1. Make sure the headset is connected to a lower cord that is compatible with your phone system.*
2. Plug the end of the lower cord into the headset port on your telephone. Some phones allow connection
to the handset port, please consult your telephone user manual for more information.
C. Computer Connection
1. For USB ports, pair with VXI's TuffSet or Passport USB Lower Cord. Plug into an USB port on your computer.
2. For sound cards, pair with VXI's "QD1030 Cord". Insert the cord's red plug into the microphone port and the black
plug into the speaker port on your computer.
* For technical assistance or product information, please call VXI Customer Service toll free at 1-800-742-8588
VXI HEADSET INSTRUCTIONS
"TALK" OR A
PAINTED DOT
