Installation manual
EN
something new in the air
D C I n v e r t e r
SL-SLI-SLSI-RS-SLS -RSI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Air Leaf 200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Innova Air Leaf 200

  • Page 1 Installation manual something new in the air D C I n v e r t e r SL-SLI-SLSI-RS-SLS -RSI...
  • Page 2 By following the suggestions contained in this manual, the product you have purchased will operate without problems giving you optimum room temperatures with minimum energy costs. Innova S.r.l Conformity This unit complies with European directives: •...
  • Page 3: Table Of Contents

    General General warnings ............. . . Fundamental safety rules .
  • Page 4: General Warnings

    Do not leave the room closed for long periods. declaration of conformity to the client in respect of the Periodically open the windows to ensure a correct laws in force and the indications given by INNOVA in the change of air. instructions leaflet supplied together with the appliance.
  • Page 5: Product Range

    GENERAL It is forbidden to dispose of or leave in the reach of The external parts of the appliance can reach children the packaging materials which could become temperatures of more than 70°C. a source of danger. It is forbidden to climb onto the appliance or rest any object on it.
  • Page 6: Overall Dimensions Air Leaf

    GENERAL Overall dimensions Air Leaf 2 pipes U.M. SL/RS/SLS 200 SL/RS/SLS 400 SL/RS/SLS 600 SL/RS/SLS 800 SL/RS/SLS 1000 Dimensions 1135 1335 1535 SL / RS U.M. RSI/SLI/SLSI 200 RSI/SLI/SLSI 400 RSI/SLI/SLSI 600 RSI/SLI/SLSI 800 RSI/SLI/SLSI 1000 Dimensions 1178...
  • Page 7 GENERAL Dimensions U.M. RSI/SLI/SLSI 200 RSI/SLI/SLSI 400 RSI/SLI/SLSI 600 RSI/SLI/SLSI 800 RSI/SLI/SLSI 1000 1178 SLSI 4 pipes Dimensions U.M. SL 200 SL 400 SL 600 SL 800 SL 1000 1135 1335 1535 SL 4T Dimensions U.M. SLI200 SLI400 SLI600 SLI800 SLI1000 1125 1325...
  • Page 8: Positioning The Unit

    The operations for the mounting of machines with fixtures appliance but will also invalidate the warranty and hence on the right are exactly the same. INNOVA shall not respond for any damage to persons, Only the images are to be considered as a mirror image. animals or property.
  • Page 9: Side Opening

    INSTALLATION Side opening On the left-hand side lift the cover that protects the On the opposite side, lift the cover that protects the screw, loosen the screw that fixes the left panel, then screw and unscrew it. move it slightly to the left and lift it up. Move the side panel slightly to the right and lift it out.
  • Page 10: Horizontal Or Ceiling Installation (Sl,Sli)

    INSTALLATION Horizontal or ceiling installation (SL, SLI) Using the paper template, trace on the ceiling the position For installation of the SL versions, horizontal condensation of the two fixing brackets and the two rear screws. Using collection basin accessory kits are available GB0520/ a suitable drill, make the holes and insert the wall plugs (2 GB0524.
  • Page 11: Air Intake Grill Fixing (Sl, Sls, Rs)

    INSTALLATION Air intake grill fixing (SL, SLS, RS) To prevent the grille from being accidentally removed or So it it takes just fix the screws in dedicated holes located left loosened by the quick-release pads preventing the fan on grill's fixing bars. coil from functioning properly (in this case, the ventilation See the figure below.
  • Page 12: Hydraulic Connections

    INSTALLATION Hydraulic connections U.M. 1000 Pipeline diameter The choice and sizing of the hydraulic lines must be made The hydraulic lines and joints must be thermally insulated. by an expert who must operate according to the rules of good technique and the laws in force, taking into account Avoid partially insulating the pipes.
  • Page 13: Condensation Discharge

    INSTALLATION Mounting the condensation discharge pipe in the horizontal version (SL, SLI) To mount the horizontal bowl on the SL versions refer to N.B. for the horizontal installation carefully note the the instructions in kits GB0520/GB0524. following precautions: check that the "L" pipe and the flexible rubber hose make sure that the machine is installed perfectly level are correctly connected to the bowl.
  • Page 14: Electrical Connections

    INSTALLATION Warnings for commissioning, mounting the thermostatic head To mount the thermostatic head: Remove the tool from the thermostatic head before - tighten the head to the valve body starting the system. To facilitate the system mounting, filling and venting operations, even without electric power, the thermostatic head is supplied with a tool that keep it open.
  • Page 15: Cleaning Air Suction Filter

    INSTALLATION 2.16 Cleaning air suction filter After a period of continuous operation and in consideration intends to restart the system after a period of inactivity, of the concentration of impurities in the air, or when he proceed as described. Extraction of filter cells in the versions with aspiration grill with flaps extract the front grill by lifting it slightly and turn it until it extract the filter, pulling it horizontally outwards.
  • Page 16 INSTALLATION Cleaning filtering seats suck up the dust with a vacuum cleaner It is forbidden to use the unit without the net filters. wash the filter with running water without using detergents or solvents, and leave to dry. The appliance is fitted with a safety switch that Remount the filter on the cooler-convector (fig.
  • Page 17: Energy Saving Tips

    INSTALLATION For the versions with a mobile panel, rest it in its position, parallel to the front panel and press until it is blocked. 2.17 Energy saving tips Always keep the filters clean; limit where possible the effect of direct sun rays in the when far possible, keep the doors and windows rooms being conditioned (use curtains, shutters etc.) closed in the room being conditioned;...
  • Page 18: Troubleshooting

    INSTALLATION TROUBLESHOOTING Troubleshooting The ventilation does not activate even if there is hot or In case of water leaks or anomalous functioning cold water in the hydraulic circuit. immediately cut off the power supply and close the The appliance leaks water during the heating function. water taps.
  • Page 19: Technical Specifications

    INSTALLATION Effect Cause Remedy Check the clogging of filters and clean The fan touches the structure. them if necessary The unbalancing causes excessive The appliance makes a strange noise. The fan is unbalanced. vibrations of the machine; replace the fan. Check the clogging of filters and clean Clean the filters them if necessary...
  • Page 20 INSTALLATION AIRLEAF - 2 TUBI Model u.m. u.m. 1000 SLSI SLSI SLSI SLSI SLSI SOUND DATA Maximum sound power level 51,00 51,00 53,00 53,00 54,00 54,00 55,00 55,00 57,00 57,00 dB(A) Sound pressure level at maxi- 41,0 39,0 42,0 40,0 44,0 41,0 46,0...
  • Page 21 INSTALLATION AIRLEAF - 4 TUBI u.m. 1000 Model u.m. COOLING PERFORMANCES (W 7/12 °C; A 27 °C) 0,71 0,71 1,42 1,42 2,01 2,01 2,43 2,43 2,92 2,92 Total cooling capacity Sensible cooling capacity 0,55 0,55 1,11 1,11 1,50 1,50 1,92 1,92 2,26 2,26...
  • Page 24 INNOVA s.r. l . INNOVA S.r.l. Fraz . St rada, 16 - 38085 PIEVE DI BONO (TN) - ITALY Via I Maggio 8 - 38089 Storo (TN) - ITALY tel. +39.0465.670104 fax +39.0465.674965 tel. +39.0465.670104 fax +39.0465.674965 info@innovaenergie.com info@innovaenergie.com N273539D - Rev. 07...
