PRODUCT DESCRIPTION

Programmable regulators with RS232 or RS485 serial interface are designed to measure temperature and relative humidity of air, to
measure concentration of CO
environment.
The CO2 concentration is measured using the dual wavelength NDIR sensor with the multipoint calibration. This principle compensates
aging of the sensing elements and offers maintenance free operation and outstanding long term stability.
The function of two output relays can be set from regulator keyboard (or from computer) and using the jumpers (see „Electrical wiring").
You can assign one of measured or computed value (dew point temperature, absolute humidity, specific humidity mixing ratio and specific
enthalpy) to each relay. Setting of delay, hysteresis, audible alarm is enabled for each relay too. Devices are equipped with four button
keyboard and two-line LCD display. The visual indication of the CO
Regulators support Modbus RTU protocol and protocol compatible with standard Advantech-ADAM. For setting of all parameters you
can use TSensor software (see www.cometsystem.com).
type * serial interface
H5321 RS232
H5324 RS232
H5421 RS485
H5424 RS485
H6320 RS232
H6321 RS232
H6420 RS485
H6421 RS485
* models marked HxxxxZ are custom - specified devices

INSTALLATION AND OPERATION

The mounting holes and connection terminals are accessible after unscrewing the four screws in the corners of regulator and removing
the lid. Devices have to be mounted on a flat surface to prevent deformation. Pass cables (external diameter 3 to 6.5 mm) through released
glands and connect wires. Wire cross-section choose from 0.14 to 1.5mm
to insert attached plugs into unused cable glands. The cables should be located as far as possible from potential interference sources.
Unpack the external CO probe and connect it to the device. Pay attention to mounting the device and probes, because incorrect choice
2
of working position or place of measuring could adversely affect accuracy and long-term stability of measured values.
Actual parameters settings of each relay can be displayed by pressing of „ ▲" key. To change any parameter, press the „Set" key, enter
password (default 0000) and set required value. Then click on „Set" and pressing „Esc" key exit setup mode. To change the password
and to set all other parameters (acoustic alarm, limits of CO
select the computed value etc.) is used Extended setting mode (see manual for devices at www.cometsystem.com).
After switching the device starts internal test. During this time (about 20 s) LCD display shows ---- instead of CO
Devices don´t require special maintenance. We recommend you periodical calibration for validation of measurement accuracy.

COMMUNICATION PROTOCOLS AND ERROR STATES

Description of communication protocols you can download from www.cometsystem.com. Device setting from the manufacturer is ModBus
RTU, address 1, communication speed 9600 Bd (no parity, 2 stop bits).
Device continuously checks its state during operation and if an error appears, it is displayed relevant code: Err 1 – measured or calculated
value (except the concentration of CO
concentration measurement error occurred, Err 5 and Err 6 - there is problem with assigned value to output relay, Err 9 – inserted
password is not valid, Err 0, Err 3 and Err 4 – it is a serious error, please contact distributor of the device (for devices with an external
probe CO2G-10 the Err 4 indicates that the probe is not connected).

SAFETY INSTRUCTIONS

- Don´t use and don't store the devices without the cover of the temperature and humidity sensors.
- Temperature and humidity sensors have not to be exposed to direct contact with water and other liquids.
- It is not recommended to use the humidity regulators for long time under condensation conditions.
- Take care when unscrewing the filter cap as the sensor element could be damaged.
- Don't connect or disconnect devices while power supply voltage is on.
- Installation, electrical connection and commissioning should be performed by qualified personnel only.
- Devices contain electronic components, it needs to liquidate them according to currently valid conditions.
- To complement the information in this data sheet read the manuals and other documentations that are
available in the Download section for a particular device at
COMET SYSTEM, s.r.o.,
756 61 Roznov pod Radhostem, Czech Republic
Regulators with RS232 and RS485 serial interface
H5321 • H5324 • H5421 • H5424 • H6320 • H6321 • H6420 • H6421
in air, to signal alarms and control of external devices. Regulators can be used in a chemical non-aggressive
2
measured values
CO
2
CO
2
CO
2
CO
2
T + RH + CO + CV
2
T + RH + CO + CV
2
T + RH + CO + CV
2
T + RH + CO + CV
2
) is over the upper limit, Err 2 – measured or calculated value is below the lower limit or CO
2
Bezrucova 2901
concentration is provided by three LEDs to the left side of the display.
2
version
probe on cable
ambient air
probe on cable
ambient air
ambient air
probes on cable
ambient air
probes on cable
T...temperature, RH...relative humidity, CO
. The communication cables should be shielded. Do not forget
2
indication, response to the error status, choice of communication protocol,
2
www.cometsystem.com
QUICK START MANUAL
mounting galvanic isolated output
wall no
wall no
wall yes
wall yes
wall no
wall no
wall yes
wall yes
...concentration CO in air, CV...computed values
2 2
concentration value.
2
Specifications are subject to change without notice.
