Summary of Contents for smart-e VHX-EN6350
-
Page 2: Table Of Contents
6.2 1U Rack Mounting................9 7. Web GUI User Guide................10 8. Switch Model..................17 9. Encoder and Decoder Matching Settings........... 17 10. 2K60 over IP System Control............... 19 11. Classic Application Example............. 19 Smart-e (UK) Ltd Copyright 2023 e&oe... -
Page 3: Introduction
☆ Controlled via IR, RS-232, TCP/IP, Web GUI and Controller Box ☆ Support POE function (802.3af Class 3, PD mode) ☆ Smart networking design for easy and flexible installation VHX-6350 AVoIP User Manual V1.0 Page 1 / 20 © 2023 Smart-e (UK) Ltd... -
Page 4: Package Contents
Input: 8-bit, 10-bit, 12-bit (1080p@60Hz); Color Depth Output: 8-bit Audio Formats LPCM 2.0CH (32/44.1/48KHz) Human body model — ±8kV (Air-gap discharge) & ESD Protection ±4kV (Contact discharge) VHX-6350 AVoIP User Manual V1.0 Page 2 / 20 © 2023 Smart-e (UK) Ltd... - Page 5 Operating 14 - 113°F / -10 - 45°C Temperature Storage -4 - 140°F / -20 - 60°C Temperature Relative Humidity 20 - 90% RH (no condensing) VHX-6350 AVoIP User Manual V1.0 Page 3 / 20 © 2023 Smart-e (UK) Ltd...
-
Page 6: Operation Controls And Functions
IR OUT IR signal output port. 12V IR signal input port. IR IN RS-232 serial port, supporting signal pass-through and RS-232 local serial port control. VHX-6350 AVoIP User Manual V1.0 Page 4 / 20 © 2023 Smart-e (UK) Ltd... -
Page 7: Decoder Panel
5.2 Decoder Panel D E C POWER LINK USB DEVICE RESET DC 12V HDMI OUT AUDIO OUT RS-232 IR IN IR OUT 13 12 10 11 VHX-6350 AVoIP User Manual V1.0 Page 5 / 20 © 2023 Smart-e (UK) Ltd... - Page 8 ▪ Local DC 12V/1A power supply DC 12V ▪ POE from Network Switch. Device acts as PD mode. When the Switch supports POE function, DC power supply is not needed. VHX-6350 AVoIP User Manual V1.0 Page 6 / 20 © 2023 Smart-e (UK) Ltd...
-
Page 9: Ir Pin Definition
6U rack sale). The mounting steps are as follows: Step 1: Use included screws to fix two mounting ears on the product, as shown in the figure below: VHX-6350 AVoIP User Manual V1.0 Page 7 / 20 © 2023 Smart-e (UK) Ltd... - Page 10 Step 3: Use screws to fix mounting ears on the rack to complete the mounting, as shown in the figure below: VHX-6350 AVoIP User Manual V1.0 Page 8 / 20 © 2023 Smart-e (UK) Ltd...
-
Page 11: Rack Mounting
Step 3: Fasten screws between two 1U rack panels, so that four products are mounted in a 1U rack, as shown in the figure below: VHX-6350 AVoIP User Manual V1.0 Page 9 / 20 © 2023 Smart-e (UK) Ltd... -
Page 12: Web Gui User Guide
IR IN IR OUT DC 12V HDMI IN HDMI OUT AUDIO RS-232 IR IN IR OUT DC 12V HDMI OUT AUDIO OUT RS-232 IR IN IR OUT VHX-6350 AVoIP User Manual V1.0 Page 10 / 20 © 2023 Smart-e (UK) Ltd... - Page 13 Web GUI login interface. Step 4: Input the default User “admin” and the default Password “admin”, and then click “Log In” to enter the Web GUI interface. VHX-6350 AVoIP User Manual V1.0 Page 11 / 20 © 2023 Smart-e (UK) Ltd...
- Page 14 Firmware Version, IP Address, Subnet Mask, Gateway and MAC Address. ■ Video Configuration Page On this page, you can configure the video properties as required. VHX-6350 AVoIP User Manual V1.0 Page 12 / 20 © 2023 Smart-e (UK) Ltd...
- Page 15 Audio Selection: You can configure the Audio Input (HDMI/Analog). EDID Setting: You can choose an EDID option from the drop-down list as shown in the below figure. VHX-6350 AVoIP User Manual V1.0 Page 13 / 20 © 2023 Smart-e (UK) Ltd...
- Page 16 EDID. (This file can be downloaded from the Download EDID of the Decoder Video page.) Decoder Video Configuration Decoder video configuration page includes Transmission Protocol, Scaler Setting, Download EDID, Video Timeout Setting, ID Setting and Picture Setting. VHX-6350 AVoIP User Manual V1.0 Page 14 / 20 © 2023 Smart-e (UK) Ltd...
- Page 17 (Brightness, Contrast, Hue and Saturation). ■ Settings Page On this page, you can set Network settings, configure Security Module, modify username and Login Password as required. VHX-6350 AVoIP User Manual V1.0 Page 15 / 20 © 2023 Smart-e (UK) Ltd...
- Page 18 When the progress bar reaches 100%, it indicates the upgrade is successful, and the device will be restarted automatically. Clicking “Reset” can reset the device to factory default settings. Clicking “Reboot” can reboot the device. VHX-6350 AVoIP User Manual V1.0 Page 16 / 20 © 2023 Smart-e (UK) Ltd...
-
Page 19: Switch Model
Please set the IDs of Encoders and Decoders respectively on the Encoder/Decoder Video Configuration page of Web GUI, then match all Encoders and Decoders via one of following three methods. VHX-6350 AVoIP User Manual V1.0 Page 17 / 20 © 2023 Smart-e (UK) Ltd... - Page 20 Decoder. You can select Encoder 1~40 to match the current Decoder by directly pressing button 1~40. If you press and hold the button 1 for 5 seconds, Encoder 41~80 can be selected. IR remote control VHX-6350 AVoIP User Manual V1.0 Page 18 / 20 © 2023 Smart-e (UK) Ltd...
-
Page 21: K60 Over Ip System Control
H DM I O UT AU DI O O UT RS -2 3 2 I R IN I R OU T 4 × DEC Video Wall VHX-6350 AVoIP User Manual V1.0 Page 19 / 20 © 2023 Smart-e (UK) Ltd... - Page 22 The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. VHX-6350 AVoIP User Manual V1.0 Page 20 / 20 © 2023 Smart-e (UK) Ltd...
