  • Page 2 WARRANTY Hamar Laser Instruments, Inc., warrants each instrument and other articles of equipment manufactured by it to be free from defects in materials and workmanship under normal use and service, its obligation under this warranty being limited to making good at its factory any instrument and other article of...

  • Page 3: Table Of Contents

    L-703SP Surface Plate Calibration System ..................1 System Components ........................1 Computer System Requirements ....................1 System Features ..........................1 L-703SP Surface Plate Calibration System - Hardware Overview ..........2 L-703S Laser Control Panel and Functions .................2 The I/O and Status LEDs .....................2 L-703S Laser Modes ......................2 L-703S Angular Adjustments ....................3...
  • Page 4 Performing a Flatness Quick-Check on a Line-Segment after Lapping ......47 Appendix A – Installing Additional Microsoft Software ..............52 Installing Microsoft .NET Framework 4 ..................52 Appendix B – ANSI B89.3.7.2013 Standard Tolerance Table ............53...

  • Page 5: L-703Sp Surface Plate Calibration System

    L-703SP Surface Plate Calibration System The L-703SP Surface Plate Calibration System has been designed to quickly and very accurately check the calibration of surface plates using the Moody Method, following the ASME B89.3 Standard for Surface Plate Calibration. It uses Plane6 Surface Plate Calibration Software and specially designed fixtures to give a high degree of accuracy when calibrating surface plates.

  • Page 6: L-703Sp Surface Plate Calibration System - Hardware Overview

    L-703SP Surface Plate Calibration System - Hardware Overview This section describes the equipment and operation for calibrating surface plates using Hamar Laser’s L-703SP Surface Plate Calibration Laser System. The system includes the laser, targets, fixtures, and software. L-703S Spindle & Straightness Laser - Features and Setup Operating range of 50 ft.

  • Page 7: L-703S Angular Adjustments

    A/C Connector The L-703S comes with a rechargeable battery. The connector is shown in Figure 3 To connect it, line up the red dot on the A/C adapter plug with the red line on the connector. L-703S Angular Adjustments The L-703S comes with pitch (vertical) and yaw (horizontal) angular adjustments to adjust (tilt) the laser to align it to reference points or a rotation axis.
  • Page 8 L-703S Level Vials When using the L-703S in machine tools, we typically will do measurements with the laser at the NORMal position (12:00) and then rotated with the spindle 180 degrees to the INverted position (6:00). There are level vials on the side of the laser to help you know if the laser is directly at 12:00 or 6:00.

  • Page 9: L-703Sp Surface Plate Calibration System - Hardware Overview

    The T-1297 3-Axis Wireless Spindle & Straightness Target Hamar Laser’s T-1297 3-Axis Wireless Spindle & Straightness Target is designed work with our L-703S Spindle & Straightness Laser. With Bluetooth communication and multiple measuring axes, the T-1297 target is a multi-purpose target that can be used for many different applications.
  • Page 10 T-1297 Angular Mode - Optional To use the T-1297 Targets in Angular Mode, the T-1295-AO-3 Lens or the A-1295- AO-6 Lens need to be purchased. To use them, insert the lens into the target face making sure line up the red or yellow dots at 12:00 when you insert it (see Figure 7). Note: To use this in angular mode, this will require the purchase of the T-1295-AO-3/6 Angular Lens and Lathe10 or MultiTurn10 Software.
  • Page 11 T-1297 Target LEDs The T-1297 LED’s have several colors and actions to indicate certain functions: Bluetooth LED Green – means the target is connected to the computer Bluetooth LED Green/Yellow – alternating green/yellow means the target is communicating with Plane6 software On Tgt LED Continuous Green –...

  • Page 12: How To Pair The T-1297 Target's Bluetooth To A Pc

    How to Pair the T-1297 Target’s Bluetooth to a PC For your computer to see the Bluetooth device, you need to turn it on. 1. Tap on Start (the Microsoft Logo) > Settings. 2. Navigate to Devices and go to Bluetooth Or click on the Bluetooth icon in the system tray and click on Add a Bluetooth Device.
  • Page 13 Enter 1280 for the passcode when prompted and hit Connect. Your Target is now paired and ready to be used. Exit Settings window...

  • Page 14: L-703Sp Surface Plate Calibration System - Hardware Overview

    Hardware Overview A-703SP-LM Surface-Plate Mounting Fixture To accurately measure the flatness of surface plates, the L-703SP requires a stable mounting fixture to hold the laser and a special flatness- measuring base for the target to achieve the highest accuracy possible.
  • Page 15 Please note - for surface plates smaller than 24 inches (611 mm), there is a second mounting foot (pad) location that is approximately 10 inches (250 mm) from the back mounting foot, so the A-703SP-LM can be used on plates as small as 12x12 in.

  • Page 16: A-1297-Sp High Accuracy, Flatness Measuring Base For T-1297 Target

    A-1297-SP High Accuracy, Flatness Measuring Base for T-1297 Target A-1297-SP is used to mount the T-1297 Target (see Figure 14) to measure flatness of the plate for measuring: Flatness measurements of surfaces. • Flatness, straightness & squareness measurements of machine tool axes. •...
  • Page 17 A-703SP-SE-A/B/C/D Target Straight-Edges and Rulers Used with the A-703SP-LM Surface-Plate Mounting Fixture (see Figure 11) as a guide for the T-1297 Target to take flatness data for each line segment. They come in the following sizes: • A-703SP-SE-A Target Straight-Edge and Ruler – 18 in. (457 mm) •...
  • Page 18 Selecting Straight Edge Length To select the length of the straight edge, use the table below to see which length to use. It is recommended that you select the straight-edge length that is less than 1.5 times the Grid Line Dimension, which ensures the best stability for the bar. For example, for the 18x18 plate, use the 18 in.

  • Page 19: Preparing For An Alignment

    Do not wipe back and forth. The same applies to the L-703SP Laser Window. If you see a reflection on the lens window on the laser (see Figure 19), this means it is contaminated and needs to be cleaned.

  • Page 20: Plane6 Surface Plate Calibration Software - System Requirements

    Plane6 Surface Plate Calibration Software - System Requirements • Physical memory (RAM): 8 GB recommended for Win10 & 11 Processor: Intel Pentium4 or later version or AMD equivalent, 1.3 GHz minimum speed • Available Hard Drive space: 20 GB minimum •...

  • Page 21: Getting Started With Plane6

    Registration Code (see Figure 20). To obtain the Product Registration Code, send the PC ID Code (automatically generated – see Figure 20) displayed on the screen to Hamar Laser Support (Support@hamarlaser.com). A Hamar representative will issue a Product Registration Code via email to complete the registration process (see Figure 21).

  • Page 22: Creating A New Project File Or Opening An Existing Project File

    Creating a New Project File or Opening an Existing Project File When Plane6 opens, the Project Selection screen displays. Recent Projects – This will list the most recent projects that were saved. Open Project – select one of the recently saved projects and click Open Project to open the project.

  • Page 23: File Structure And Converting Raw Data Values In Csv Files To Inches Or Millimeters

    Each project is saved into a dedicated folder in the Projects folder that you specified in the New File dialog box. File Structure In each Plane6 folder, there are 2 data files. The ***.p6z file contains all the data taken •...

  • Page 24: Plane6 Software - Summary Of Main Screens

    Plane6 Software – Summary of Main Screens Step 1: Set Up Plane6 Enter the horizontal and vertical dimension of the plate and the border width from the edge of the plate to the measuring line. Then select the number of points you want to measure for the horizontal, vertical and diagonal lines.
  • Page 25 Step 3: Results - After recording the data, click on Step 3 to view the overall flatness results and whether it is in tolerance or out. You can also view the data for each line segment and a 3d graph of the alignment.

  • Page 26: Plane6 Screens - File Menus

    Plane6 Screens - File Menus The File Menu New Project – see above Open Existing Project – same as above Save Project – saves the project. Save Project As –allows you to save an existing project as a new project. It keeps all the data from the existing project.

  • Page 27: Navigating Plane6 With The Status Bar

    The Help Menu. About This Program - Usual info about the program. User Manual - Opens a PDF of the manual. Navigating Plane6 with the Status Bar Software Steps In the upper right part of the screens is the Navigation Bar. It lists the number of steps in the software along with arrows to move to the left or the right.

  • Page 28: Plane6 Screens - Preferences

    Plane6 Screens - Preferences Click Preferences to open a window to change Plane6 settings. You can also click on the Preferences button in the lower right side of each screen in Plane6. see Page 27) Note: If you are installing the software yourself, you will need to go to Enter Target Info ( and follow the procedure to enter the target serial number and calibration factors.
  • Page 29 Targets Target settings Vertical & Horizontal Tolerance (±) – this is a display tolerance for Step 2 that changes the display background color to orange if these tolerances are exceeded. The default is: Vertical: ± .010 in. (10,000 µin.) Horizontal: ± .030 in. (30,000 µin.) Vertical: ±...

  • Page 30: Targets - Setup Procedure

    Targets - Setup Procedure When you buy a new system and laptop from HLI, the target setup is already pre-configured into Plane 6. However, if you are installing Plane6 on your laptop, then you must follow this procedure to set up the target. 1.
  • Page 31 4. Target Name. Enter a “nick name” for the target. This name will show up in the Target area on the data displays. The target part number and focal length are automatically displayed by Plane6 5. Serial Number and Calibration Date – enter the serial number and calibration date (supplied with the system) 6.
  • Page 32 7. Target Network ID This is needed for our A-1519/1520 Scanning targets and not used in this application. 8. Calibration Factors - Vertical and Horizontal Slope Offsets and Focal Length. These are correction factors that are used for another application and are not needed for surface plate calibration.

  • Page 33: Plane6 Screens - Step 1: Dimensions And Tolerances

    Plane6 Screens - Step 1: Dimensions and Tolerances Enter the horizontal and vertical dimension of the plate and the border width from the edge of the plate to the measuring line. Then select the number of points you want to measure for the horizontal, vertical and diagonal lines. Next select the plate grade enter the plate serial number and top and bottom temperature (if measured).
  • Page 34 Moody Center Tolerance: As per Moody Method procedure, this is the maximum allowed deviation between the intersecting diagonal lines after all point adjustments have been made. If this tolerance is exceeded, it suggests that measurement errors were made and it suggested that the data be retaken.

  • Page 35: Plane6 Screens - Step 2: Data Collection

    When setting up the laser, put should be placed at the point where the target icon is located and pointed in the direction of the arrow (see more information below under L-703SP - How It Works Page 37).
  • Page 36 Save Project – click here to save the data already recorded. Note - Plane6 has an auto-saving feature. See page 19 Restoring File Backup to see how to recover data from backups. Clear All – this clears all the data from all the line segments recorded for the plate.
  • Page 37 Target – this is the dropdown list of all the targets that have been set up in Preferences to allow you to change the target if using your laptop with a different set of laser/target. This is normally not changed unless you are switching laptops and laser/target kits.

  • Page 38: Plane6 Screens - Step 3: Results

    Plane6 Screens - Step 3: Results When all the data is collected, click on Step 3 icon to bring you to the Step 3: Results. This shows the Moody Method calculations to get the overall flatness results. The results are summarized in the Results Table and the plate-grade tolerance, chosen from Step 1, is applied and a red X or green check-mark is displayed to indicate if the overall flatness is in or out of tolerance.

  • Page 39: Plane6 Screens - Step 4: Graph

    Plane6 Screens - Step 4: Graph To see a more comprehensive graph of the flatness results, click on Step 4: Graph. This takes you to a user adjustable graph where you can rotate the graph, zoom in and out and adjust the graph to study the results. To rotate the graph, use a mouse to click and drag left/right or up/down.

  • Page 40: Interpreting The Plus And Minus Signs In The Live Displays

    Interpreting the Plus and Minus Signs in the Live Displays The signs of the data displays indicate the position (high/low or left/right) of the target is relative to the laser beam. See the interpretation below. Vertical Axis Side View A +V center value indicates the target is higher than the laser beam.

  • Page 41: L-703Sp - How It Works

    L-703SP - How It Works Step-by-Step Surface Plate Calibration Procedure Step 1 – Plate Setup These parameters need to be entered: the plate border size (default is 1.5 in. 37 mm). • • the plate grade, the plate size in X & Y, •...
  • Page 42 Step 3 – Assemble Laser and Laser Mount Insert the L-703S Laser into the L-703SP-LM Laser Mounting Fixture and tighten the thumb screw very tight and make sure to keep the top if...
  • Page 43 Step 3a –Place Laser Mount + L-703S on top of the straight edge on the plate a. Find the correct corner on which to place the A-703SP-LM from Plane6 Step 2 Measure Screen, keeping track of the name plate location. b.
  • Page 44 Step 4 – Assemble the T-1297 Target and A- 1297-SP Measuring Base Now assemble the T-1297 Target into the A-1297-SP Precision Measuring base. Notice that the T-1297 has an alignment ball. This will insert into the slot on the A-1297-SP to align the target to the A-1297-SP base’s measuring feet.
  • Page 45 Step 4b – Move the T-1297 Target + Base to the Far End of Straight Edge a. Move the T-1297 Target + Base to the far end of the straight edge. b. Adjust the H (yaw) and V (pitch) axis adjustments on the L-703S laser to tilt the beam until the values are less than: H Axis: 30,000...
  • Page 46 Step 6 – Move Laser to Second Diagonal and Record Data First take off the L-703SP-LM Laser Mount and set it aside. Then move the straight edge to the second diagonal using the corner locator tools to position the straight edge.
  • Page 47 Again when using the corner edge tool, always put the scale side touching the tool. Place the L-703SP-LM Laser Mount on the straight edge as shown Step 3a above. Place the target at the near position and you are ready to record.
  • Page 48 Step 7c – Record Mid-Point Line Segment Using the mark made by the Mid-Point Marking Tool (see Step 1), position the Corner Locating Tool on the midpoint and align the mark on the locating tool with the mark on the plate. Position the straight edge to the right of the Corner Locating Tool (when looking from the Laser End of the straight edge toward far end).
  • Page 49 Step 8 - Record the Rest of the Line Segments Record the rest of the line segments, following the recommended sequence from Plane6. Notes on taking data: 1. Display Value Tolerance - Pay attention to the H axis value. If the value gets higher than 30,000 µin.
  • Page 50 4. Manually Picking Data Points - You can turn off Auto Step if you want to move the target icon manually. 5. Reversing Direction on a Line Segment - You can also hit Reverse Direction to change the direction of a line if you need to. Step 9 –...

  • Page 51: L-703Sp - How It Works

    One of the annoying parts of using electronic levels when re-surfacing a surface plate is you have to shoot the entire plate for flatness to see how the lapping process is going. This is a waste of time! With the L-703SP Surface Plate Calibration Systems, you can do quick-checks of a single line segment in about 5 minutes to see how much the flatness error has been reduced.
  • Page 52 Step 2 - Set Up Laser Line Bring the T-1297 Target and A-1297-SP Target-Measuring Base to the first measuring point as you did above. Zero the display by clicking on the Zero button. Due the extremely high resolution, it’s expected that the value won’t be exactly zero due to some measurement noise but they will be close.
  • Page 53 Step 4 – Setup Test Project Set up a new project with the line length you want and the number of points you want to use to measure the line segment. Step 4 – Record the Values Go to Step 2 and select the line segment you want to record.
  • Page 54 An example on how to do the Math to get the exact flatness values:...
  • Page 55 Plane6 Sample Report...

  • Page 56: Appendix A - Installing Additional Microsoft Software

    Appendix A – Installing Additional Microsoft Software Installing Microsoft .NET Framework 4 You must have Microsoft .NET Framework installed before installing the Plane6 software. If you are unsure about whether you have Microsoft .NET Framework 4 installed on your computer, open the Control Panel.

  • Page 57: Appendix B - Ansi B89.3.7.2013 Standard Tolerance Table

    Appendix B – ANSI B89.3.7.2013 Standard Tolerance Table Plane6 Software uses the tolerances for the standard plate sizes shown in Figure 29 below from the ANSI B89.3.7.2013 Standard for Granite Surface Plates. For non-standard sizes, we use the formula from the standard: “Flatness tolerance for surface plates, whose sizes are not listed in Table 1, is obtained from the following formula: Overall flatness tolerance (µm) = 1 + 1.6*D Overall flatness tolerance (µin.) = 40 + D...
