Atoll PH100 Owner's Manual

OWNER'S MANUAL ~ PHONO PREAMPLIFIER
1
2 3 4 5
1) Ground.
2) Module output.
3) Module input.
4) Setup switches (Left channel).
DETAILS OF FUNCTIONS
8) ON/OFF led indicator.
CONNECTING
6 7
5) Setup switches (Right channel).
6) General power plug.
7) ON/OFF switch.
8
Page 4 ATOLL ELECTRONIQUE
CONFIGURATIONS
The PH100 Phono preamp. offers several setups directly from the rear side of the
module. It is operated by the pair of 4 points DIL: one for the Right channel, one for
the Left channel (you can also refer to the screen-printed diagrams on the rear side).
Make sure that the 2 switch blocks are in the same position.
1) MM – MC Setup: depending of the type of your cartridge, you can select the Input
as MM or MC as shown on the board below:
3 4
• For an MM cartridge, put and
• For a high level MC cartridge (MCH), put
4
OFF.
• For a low level MC cartridge (MCL), put
ON.
2) Input impedance choice:
These settings apply to both MM and MC cartridges.
They allow you to adapt the musicality of your PH100 to your system.
Warning: the configurable input resistor is unrelated to the output resistor of
your cartridge (very low compared to the configurable input resistor).
1
• To select a 47 k resistor, put ON.
1
• To select a 100 k resistor, put OFF.
• To select a condensator of 100 pF, put
2
• To select no condensator, put OFF.
Page 5
OFF.
3 4
3
ON, and
OFF OFF
3 4
and
ON OFF
ON ON
1 2
2
ON.
47 k 100 pF
100 k -
ATOLL ELECTRONIQUE
PH100
TYPE
MM
MCH
MCL
ON
OFF
