Textron JACOBSEN Eclipse 100 Series Instruction Sheet

This kit is intended only for use with the Jacobsen
and Eclipse2 100 series greens mower.
!
CAUTION
Before you install this kit, read the Safety & Operation
Manual to become familiar with the mower, the controls,
and proper use of the equipment.
Stay alert for potential hazards and follow all safety
precautions. Read all instructions completely and make
sure you understand them before proceeding with the
assembly.
1. Park the mower on a flat and level surface, fully lower the
cutting units to the ground, engage the parking brake,
turn the ignition switch to the OFF position, and remove
the key.

Light Assembly ____________________________________________________________________

Eclipse Mowers
1. Assemble headlight (Item 3) to light mount (Item 2).
2. Assemble light mount to adapter bracket (Item 6) using
two 5/16-24 x 3/4" Hex head screws (Item 1), lockwashers
(Item 5), and nuts (Item 8).
3. Assemble light assembly to Eclipse mower using 5/16-18
x 1/2" screws (Item 7) and lockwashers (Item 5).
Eclipse2 Mowers
1. Assemble headlight (Item 3) to light mount (Item 2).
2. Assemble light mount (Item 2) to Eclipse
two 5/16-18 x 1-3/4" screws (Item 12), lockwashers (Item
5), and spacers (Item 13)
3
2
8
1
5
7

Light Kit Harness __________________________________________________________________

1. Locate identification tag on light kit harness. Check
harness revision.
a. Eclipse mowers can use harness with Rev B or Rev C
harness without jumper harness.
Litho in U.S.A. 5-2012
mower using
2
6
Figure 1 - Eclipse Mowers
Eclipse
a. Wait for all movement to stop before making any
® ®
Eclipse
adjustments or modifications.
b. Allow sufficient time for the unit to cool down.
c. Take this opportunity to thoroughly inspect the
equipment and perform other required maintenance.
Before you attempt to clean, adjust, or repair any of this
equipment, disengage all drives, shut down the engine,
and allow the unit to cool. Remove the key from the
ignition switch and disconnect the power connector to
prevent accidental discharge and potential bodily
injuries.
Light kit jumper harness 4271571 may be required to install
this kit on Eclipse2 mowers.
2
12
b. Eclipse2 mowers will require jumper harness 4271571
with Rev B harness.
c. Eclipse2 mowers can use harness with Rev C harness
without modification.
INSTRUCTION SHEET
®
100 Series Light Kit
Service Kit No. 63320
!
WARNING
3
5
13
Figure 2 - Eclipse2 Mowers
Part No. 4206040-Rev B
