Front lift arm field kit for series ej - engine type kubota d1105-e
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FITTING INSTRUCTIONS
For:
Series: EJ - Engine type: Kubota D1105-E
Product code: TR30001
WARNING: If incorrectly used this machine can cause severe
injury. Those who use and maintain this machine should be
trained in its proper use, warned of its dangers and should
read the entire manual before attempting to set up, operate,
adjust or service the machine.
RJ 100 / 06 2005
TR3 - Front Lift Arm Field Kit LMAC187
24764G-GB (rev.0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jacobsen TR3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Textron Jacobsen TR3

Summary of Contents for Textron Jacobsen TR3

  • Page 1 24764G-GB (rev.0) FITTING INSTRUCTIONS TR3 - Front Lift Arm Field Kit LMAC187 For: Series: EJ - Engine type: Kubota D1105-E Product code: TR30001 WARNING: If incorrectly used this machine can cause severe injury. Those who use and maintain this machine should be trained in its proper use, warned of its dangers and should read the entire manual before attempting to set up, operate, adjust or service the machine.

  • Page 3: Table Of Contents

    CONTENTS JACOBSEN TR3 FRONT LIFT ARM FIELD KIT FITTING INSTRUCTIONS CONTENTS PAGE SAFETY INSTRUCTIONS OPERATING INSTRUCTIONS ..................4 SAFETY SIGNS ......................4 STARTING THE ENGINE ..................... 4 DRIVING THE MACHINE .................... 4 TRANSPORTING ......................4 LEAVING THE DRIVING POSITION ................4 SLOPES ........................

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS JACOBSEN TR3 FRONT LIFT ARM FIELD KIT FITTING INSTRUCTIONS all times, in any conditions. This safety symbol indicates important safety • Remove or avoid obstructions in the area to messages in this manual. When you see this be cut, thus reducing the possibility of injury symbol, be alert to the possibility of injury, carefully to yourself and/or bystanders.

  • Page 5: Blocked Cutting Cylinders

    SAFETY INSTRUCTIONS JACOBSEN TR3 FRONT LIFT ARM FIELD KIT FITTING INSTRUCTIONS BLOCKED CUTTING CYLINDERS • Stop the engine and make sure all moving parts are stationary. • Apply brakes and disengage all drives. • Release blockages with care. Keep all parts of the body away from the cutting edge.

  • Page 6: Preparation

    PREPARATION JACOBSEN TR3 FRONT LIFT ARM FIELD KIT FITTING INSTRUCTIONS PREPARATION CAUTION: Read the tractor’s manual and become familiar with the tractor, the controls and proper use of the equipment. Stay alert for potential hazards and follow all safety precautions. Read all instructions...

  • Page 7: Front Lh Lift Arm

    FRONT LH LIFT ARM JACOBSEN TR3 FRONT LIFT ARM FIELD KIT FITTING INSTRUCTIONS REMOVE CUTTING UNIT FROM LIFT ARM Remove M10 x 65 Hex Head Bolts (B), M10 Plain Washers (C) and M10 Nyloc Nuts (D) from Lift Arm (A) Clamp Block.

  • Page 8: Assemble New Lift Arm To Front Axle

    FRONT LH LIFT ARM JACOBSEN TR3 FRONT LIFT ARM FIELD KIT FITTING INSTRUCTIONS ASSEMBLE NEW LIFT ARM TO FRONT AXLE Smear bore of new Lift Arm (A) bushes with Shell Darina R2 grease (or equivalent). Clean surface of Lift Arm Pivot Pin (E) (removed in Step 4.3.2) to remove old...

  • Page 9: Assemble Cutting Unit To Lift Arm

    FRONT LH LIFT ARM JACOBSEN TR3 FRONT LIFT ARM FIELD KIT FITTING INSTRUCTIONS CONTINUED Align holes in Ram Pin (B) with slot in Lift Arm (A) Plate. Reassemble hardware (D, E and F) removed in Step 4.2.1 to Ram Pin and Lift Arm.

  • Page 10: Front Rh Lift Arm

    FRONT RH LIFT ARM JACOBSEN TR3 FRONT LIFT ARM FIELD KIT FITTING INSTRUCTIONS UPDATE RH LIFT ARM Repeat above procedure for Front RH Lift Arm. GB-10...

  • Page 11: Front Rubber Bump Stops

    JACOBSEN TR3 FRONT LIFT ARM FIELD KIT FITTING INSTRUCTIONS FRONT RUBBER BUMP STOPS Fit the self adhesive rubber pads to the top decks of the front two units in the positions shown below. GB-11...

  • Page 12: Parts List

    PARTS LIST JACOBSEN TR3 FRONT LIFT ARM FIELD KIT FITTING INSTRUCTIONS ITEM PART No DESCRIPTION REMARKS LMSE192 Lift Arm, Front LH LMSE193 Lift Arm, Front RH 4138556 Shaft-Pivot 450035 Bolt-Hex M10 x 65 450391 Wshr-M10 x 21 x 2.2 450379...
