- Page 1 User’s Manual Utility mount for DJI RC2 by Thor’s Drone World...
- Page 2 Index What’s included. How to Mount the LifThor Freya to your RC2 Secondary Monitor set up Tablet or Smart Phone set up How to connect your RC2 with your tablet (Apple or Android) How to mount the LifThor Freya on a tripod How to use a lanyard with your LifThor Freya Other recommended accessories for DJI RC2...
- Page 3 Content A. LifThor Freya Utility Mount B. (2x) 2.5x8mm screws C. ¼”-20 Knob screw D. Universal phone / tablet clamp E. Hex Key F. Wrench G. Philip screwdriver H. Type C - HDMI 4K High Speed cable (40cms)
-
Page 4: How To Mount
How to mount: Unscrew the (2x) thumb screws located on the back of the mount to remove the back piece. back Lower plate... - Page 5 Align the controller with the mount’s lower plate to get access to the controller’s mounting points. Hold it in place by using the (2x) 2.5x8mm screws, leave it loosely for now.
- Page 6 Re-attach the back piece with the (2x) thumb screws - not too tight since you will still need to be able to align properly the mount to the RC.
- Page 7 Make sure the mount is properly aligned and positioned between the middle of the antennas. If you are having trouble aligning the mount release more pressure of the screws...
- Page 8 Once the mount is properly aligned, tighten all 4 screws to keep the mount in place.
- Page 9 If needed, to adjust the angle of the utility mount you can loosen it up using the hex key and wrench provided.
- Page 10 How to mount a HDMI monitor Connect your RC2 Utility mount Controller with the monitor using the Cable provided. Using the (¼”-20) knob screw provided, screw the monitor in place through the top opening of the utility mount and secure it tightly.
- Page 11 How to mount a Tablet / Smart Phone Set up : Screw the universal clamp in place using the (¼”-20 ) Knob screw provided. As shown.
- Page 12 The universal clamp has two mechanisms to ensure your tablet sit secure and in place. Ratchet part to The first mechanism is adjust the height. the ratchet part, it can be extended in 6 fixed steps (3 on the top / 3 Release on the bottom) to adjust button...
- Page 13 Place the phone / tablet in landscape mode by pulling the spring mechanism upwards and release it to secure the device in place. * It’s the spring-loaded part that will hold your device in place !
- Page 14 Please note to be able to connect the RC2 with any Tablet (Apple or Android) you will need a Video Capture card – included- and a tablet with Type C (USB C) input port input port Type C (USB C) plug Video Capture card.
- Page 15 It’s only possible to connect those tablets with a Type C (USB C) input port, meaning those tablets that use a Type C Cable to charge. If your tablet uses a Micro USB or Lightning cable you won’t be able to connect to your RC2 For Apple Devices.
- Page 16 How to mount to a tripod The LifThor Freya is equipped with a built-in mounting point located at the bottom of the unit to mount it to a tripod – with ¼”-20 threads.
- Page 17 *Suggested products for your LifThor Freya Body Tripod / Harness Buy it now! Quick release mounting bracket Suitable to use with your LifThor Freya - on top of the utility mount together with a monitor or under with a tripod. Buy it now!
- Page 18 How to attach a StrapThor lanyard: (Sold separately ) Unplug the Quick Release adapter from the lanyard by pressing firmly on the sides.
- Page 19 Loop the string through the LifThor Freya utility mount and pull to secure, reconnect it to the lanyard. Utility mount...
- Page 20 *Suggested product for your LifThor Freya Lanyard Adjustable neck strap with specialized quick release mechanism which allow a better view of the RC. Buy it now!
- Page 21 Other recommended accessories for you DJI RC2 Lanyard System for DJI RC1 / RC2 Check it out! Tripod mount for RC1/ RC2 Check it out!
- Page 22 www.lifthor.com ww.thorsdroneworld.com...
