Argent IN38905 Care & Installation Manual

ARGENT 80 IN WALL CISTERN - MECHANICAL
IN38905
495
495
R1/2
R1/2
1000
1000
535
585
max.-150
78
x
x
Inlet height to be
taken from pan
being used
0
Finished Floor Level
0
RECOMMENDED FLUSH PLATES:
Kubic
Grace Round
Disclaimer: Products in this specification manual must by regulation be installed by licensed and registered trade people. The manufacturer/distributor reserves the right
to vary specifications or delete models from their range without prior notification. Dimensions are nominal measurements only. Dimensions and set-outs listed are correct at
time of publication however the manufacturer/distributor takes no responsibility for printing errors.
Customer Central
1300 364 748
WELS 4 Star / 3.5Lpm
WELS REG No. L05256
86
86 20-70
95
95
535
585
735
735
max.-150
78
0
In-Wall Cistern (Mechanical Activation)
IMPORTANT INSTALLATION NOTE:
mm
mm
20-70
0
Care & Installation Guide
Inlet valve water pressure and pipe
sizing must comply with AS3500 &
Manufacturers Specification.
Maximum 500kpa static.
Minumum 100kpa dynamic.
Not suitable for low pressure systems.
1. Inspect all parts prior to installation
for suitability and/or defect.
2. Any suspected defect should be
reported as soon as possible.
3. Should any product be installed
despite a fault having been
found and reported, liability will
not be accepted for the cost of
labour to remove and install any
replacement products.
Flush Plate Selection
support@customer-central.com.au
Edge
www.argentaust.com.au
