Surge Suppression Filters
FTSF2 Series
Introduction
•
Rated current: 0.5A~1600A
•
Optional medical versions (H Type)
•
Various terminals: wire, solder lug, stud, terminal blocks, etc
•
Custom speci c versions available on request
Features and Bene ts
•
Have both surge and ltering function.
•
Surge class conforms to GB/T 17626.5-2008 / IEC61000-4-5:2005 Standard.
•
FTSF2 series filter is high performance AC filter, which is designed with two-stage common mode filter circuit.
They have excellent common and differential mode filtering effect with filtering range from 10kHz to 30MHz.
Typical Applications
Electrical & electronic equipment
Consumer goods
Household appliance
Completed EMC Solution Provider
Datacom equipment
Electronic devices with simultaneous surge and ltering requirements
O ce automation equipment
Advertisement
Table of Contents
Related Manuals for filtemc FTSF2 Series
Summary of Contents for filtemc FTSF2 Series
- Page 1 Surge class conforms to GB/T 17626.5-2008 / IEC61000-4-5:2005 Standard. • FTSF2 series filter is high performance AC filter, which is designed with two-stage common mode filter circuit. They have excellent common and differential mode filtering effect with filtering range from 10kHz to 30MHz.
- Page 2 Surge Suppression Filters Technical Data Rated Voltage: VR 110/250VAC Operating Frequency: FR 50/60Hz Rated Current: I R 0.5~1600A@40℃ Test Voltage: Vtest 300VDC, 3S(line-line); 2000VAC, 3S(line-ground) Climatic Category (IEC 60068-1) 25/085/21(-25℃/+85℃Damp heat test for 21 days) Tabulates Terminals Leakage Current [mA] Rated Weight [g] Part No.
- Page 3 Surge Suppression Filters Surge Test Results Output voltage waveform (di erential mode1.3KV) Input voltage waveform (di erential mode2KV) Input voltage waveform (common mode 4KV) Output voltage waveform (common mode1.3KV) Insertion Loss (dB) Common Mode Differential Mode Note: Insertion loss is tested with a system of empty load and 50 -50 according to...
- Page 4 Surge Suppression Filters 100K FTSF2-10 FTSF2-20 Outline Drawing and Dimensions (mm) 6.3*0.8±0.2 7.3±0.2 150 MIN. 150 MIN. 86 MAX. 20#BN 20#BN FILTEMC 20#YEGN 2- 5.0±0.5 2- 4.5±0.5 20#BU 20#BU 51±1 9±0.5 63±1 10±0.5 60±0.5 19±0.5 75±0.5 22±0.5 71 MAX. 30 MAX.
- Page 5 Surge Suppression Filters Important Notes on EMI Filter Application 1. Storage of EMI Filters: EMI lters mustn't be left out in the heat of the sun or exposed to the rain, it should be stored in warehouse with good ventilation, surrounding temperature between -30℃ and +65 ℃, the highest relative air humidity lower than 90%, and no corrosive liquid or gas.
- Page 6 Surge Suppression Filters 3. Reminding and Warning： Please read all the safety warnings and instructions before installing lters and putting them into use: • Don't take terminals as supporting point when moving filters to avoid the terminals distortion, loosening or broken. •...
