Surge Suppression Filters
FTSF1 Series
Introduction
•
Rated current: 0.5A~300A
•
Optional medical versions (H Type)
•
Various terminals: wire, solder lug, stud, terminal blocks, etc
•
Custom speci c versions available on request
Features and Bene ts
•
Have both surge and ltering function.
•
Surge class conforms to GB/T 17626.5-2008 / IEC61000-4-5:2005 Standard.
•
FTSF1 series lter is common AC lter, which is designed with one-stage common mode lter circuit.
They have good filtering effect and the effective filter range is 150kHz ~ 30MHz. Compact structure,
cost-effective, safe, convenient, and more reliable.
Typical Applications
Electrical & electronic equipment
Consumer goods
Household appliance
Completed EMC Solution Provider
Datacom equipment
Electronic devices with simultaneous surge and ltering requirements
O ce automation equipment
Advertisement
Table of Contents
Related Manuals for filtemc FTSF1 Series
Summary of Contents for filtemc FTSF1 Series
- Page 1 Surge class conforms to GB/T 17626.5-2008 / IEC61000-4-5:2005 Standard. • FTSF1 series lter is common AC lter, which is designed with one-stage common mode lter circuit. They have good filtering effect and the effective filter range is 150kHz ~ 30MHz. Compact structure, cost-effective, safe, convenient, and more reliable.
- Page 2 Surge Suppression Filters Technical Data Rated Voltage: VR 110/250VAC Operating Frequency: FR 50/60Hz Rated Current: I R 0.5~300A@40℃ Test Voltage: Vtest 300VDC, 3S(line-line); 2000VAC, 3S(line-ground) Climatic Category (IEC 60068-1) 25/085/21(-25℃/+85℃Damp heat test for 21 days) Tabulates Terminals Leakage Current [mA] Rated Weight [g] Part No.
- Page 3 Surge Suppression Filters Surge Test Results Output voltage waveform (di erential mode1.3KV) Input voltage waveform (di erential mode2KV) Input voltage waveform (common mode 4KV) Output voltage waveform (common mode1.3KV) Insertion Loss (dB) Common Mode Differential Mode Note: Insertion loss is tested with a system of empty load and 50 -50 according to...
- Page 4 Surge Suppression Filters 150K FTSF1-10 FTSF1-20 Outline Drawing and Dimensions (mm) 150 MIN. 150 MIN. 20#BN 20#BN FILTEMC 20#YEGN 2- 4.5±0.5 20#BU 20#BU 51±1 9±0.5 60±0.5 19±0.5 71 MAX. 30 MAX. FTSF1-3 6.3*0.8±0.2 7.3±0.2 74 MAX. 4.5±0.5 51±1 10±0.5 63±0.5 22±0.5...
- Page 5 Surge Suppression Filters Important Notes on EMI Filter Application 1. Storage of EMI Filters: EMI lters mustn't be left out in the heat of the sun or exposed to the rain, it should be stored in warehouse with good ventilation, surrounding temperature between -30℃ and +65 ℃, the highest relative air humidity lower than 90%, and no corrosive liquid or gas.
- Page 6 Surge Suppression Filters 3. Reminding and Warning： Please read all the safety warnings and instructions before installing lters and putting them into use: • Don't take terminals as supporting point when moving filters to avoid the terminals distortion, loosening or broken. •...
