OPERATION MANUAL
Features
• Operating Bands 160m – 6m
• 5-inch Color Touch Screen
• FWD/REF/SWR Meter
• Selection for 3 Antennas
• 1-30 MHz 1200 watts SSB
• 1-30 MHz 1000 watts CW
• 1-30 MHz 700 watts DIGI mode
• 50 MHz 300 watts
• Inductance 6.3 uH / Capacitance 1100 pF
• Matching Range 5:1
• Tuned 1.5:1
• Minimum Tuner Level 3 Watts
• W 8 x L 10 x H 5.5 / Weigh 7.5 pounds
Automatic Antenna Tuner
Designed and Manufactured in the USA
Copyright 2022 KM3KM Electronics LLC.
mercuryAT
V 1.3
Advertisement
Table of Contents
Related Manuals for KM3KM mercuryAT
Summary of Contents for KM3KM mercuryAT
- Page 1 • Matching Range 5:1 • Tuned 1.5:1 • Minimum Tuner Level 3 Watts • W 8 x L 10 x H 5.5 / Weigh 7.5 pounds Automatic Antenna Tuner Designed and Manufactured in the USA Copyright 2022 KM3KM Electronics LLC.
-
Page 2: Safety Warning
SAFETY WARNING Very high RF voltages, as well as large RF current flow, may be present in your mercuryAT. Like all antenna tuners meant for high power use, the mercuryAT handles a great deal of RF energy. Your mercuryAT is designed to safely handle this RF energy within its specifications, with a reasonable margin of safety. -
Page 3: Good Practice
GOOD PRACTICE Be sure to observe the mercuryAT specified power ranges. If the tuner fails due to overload, it could also damage your Transmitter or Amplifier. An antenna tuner transforms the impedance at the power point from the line to the equipment, to a value suitable for the transmitter, typically 50 Ohms. -
Page 4: Connections Diagram
Power Cable: Connect the power cable to an external power supply up to 13.8VDC. Use Red for (+) and black for (-). Never power up your mercuryAT through the transceiver. Use the same power source with which the transceiver is powered since mercuryAT does not have a power switch. -
Page 5: Main Screen
Tune Button - Press the TUNE Button to tune, the banner (TUNE CALL) will be displayed and mercuryAT will be ready to receive a continuous 10-watts carrier to start the auto adjustment. SLEEP Button - mercuryAT will turn off the Display. The Antenna Relays and LC adjustment will remain energized, however. -
Page 6: Rear View
Do not block rear area and please leave either the left or right side of mercuryAT clear for proper airflow. DC Power Connector - Connect the power cable to an external power supply up to 13.8VDC. -
Page 7: Tuning Guide
PTT Disconnect cable is installed, this is not necessary. Make sure that the Bypass Button on the mercuryAT is turned off and press the TUNE Button for 2 seconds. You will see the Banner read “Tune CALL” on the screen. -
Page 8: Radio Interface Configuration
The control connection from mercuryAT to your transceiver allows for an automatic tuning process when the TUNE button on the tuner or transceiver is pressed. The mercuryAT sends a PTT signal (Active Low) into a tuner-dedicated port on the transceiver and the transceiver begins transmitting a low-level CW tone. - Page 9 ICOM IC-7000. IC-7600. IC-7300. IC-7610. IC-7700. IC-7100. IC-7200. IC-706. IC-707. IC-718. IC-725. IC-728. IC-736. IC-738. IC-746. IC-756. For ICOM RF power is lowered while mercuryAT is running. There is no need to change settings after or before tuning. YAESU FT-450D. FT-950. FT-DX1200. FT-DX10.
- Page 10 YAESU FT-891. FT-857D. FT-897D. FT-100. FT-100D. FT-991A For FT-991(A), go to menu 143 and select LAMP. For the FT-891, go to menu 16-15 and select LAMP. YAESU FTDX-101D. FTDX-101MP. FTDX-3000...
-
Page 11: Warranty
Return Policy: You have 10 calendar days to return from the date you received your mercuryAT. To be eligible for a return, your item must be in the same condition that you received it. Your mercuryAT must be in the original packaging; you must have the receipt or proof of purchase.
