- Page 2 Ship the product prepaid. All material in this manual is the property of ComSonics, Inc. and protected under the United States copyright law. No material shall be reproduced or used in any form or by any means (graphic,...
-
Page 3: Table Of Contents
Sniffer Sleuth User’s Manual Table of Contents Specifications ....................ii Read This First!..................... iii Introducing Sniffer Sleuth................1 Setup Function Modes: Mute ......................3 Loudness ....................4 Distance....................5 Squelch..................... 6 Battery...................... 7 Frequency....................8 External Antenna ................... 10 Using Sleuth in the Field................12 Using Sleuth with the Docking Station ............ -
Page 4: Specifications
Sniffer Sleuth User’s Manual Specifications Operating frequency ranges 80 ~ 120 MHz (Model 001), 120 ~ 150 MHz (Model 002) Tuning increments 1.0 kHz Tuning stability < ±1.0 kHz Terminal sensitivity: with Sniffer I.D. -72 dBmV (0.7 µV/m @ 126 MHz) with Sniffer ... -
Page 5: Read This First
As supplied from ComSonics, the Sleuth battery pack is only partially charged. Before using the unit for a full day’s operation, the battery pack must be charged for 4 to 6 hours. - Page 6 Sniffer Sleuth User’s Manual...
-
Page 7: Introducing Sniffer Sleuth
Sniffer Sleuth User’s Manual Introducing Sniffer Sleuth Sleuth is a hand-held signal leakage detection device. When programmed, Sleuth makes active measurements on a chosen frequency and shows the results on a liquid crystal display (LCD). It indicates detected leakage by receiving and processing a modulated carrier. - Page 8 Sniffer Sleuth User’s Manual Introducing Sniffer Sleuth The Sleuth “panel” is equipped with two keys. The ON / OFF button turns Sleuth on and off. The FUNCTION button switches the Sleuth from its normal, or operating, mode into one of the Setup modes. Repeated presses of the FUNCTION button scroll through each of the different setup functions and then back to the operating mode.
-
Page 9: Mute
Sniffer Sleuth User’s Manual Setup Function Modes: Mute Sleuth powers up in its operating mode, allowing you to instantly begin to make measurements. There are seven additional “Setup” function modes: Mute, Loudness, Distance, Squelch, Battery, Frequency, and External Antenna, which you can use to change Sleuth’s operating parameters. In each of these modes, Setup is highlighted, as well as the particular setup function;... -
Page 10: Loudness
Sniffer Sleuth User’s Manual Setup Function Modes: Loudness The Loudness mode allows adjusting of Sleuth’s speaker volume. To access this function, turn Sleuth on; after the self-test, press the FUNCTION button until Loudness is flashing. To change the loudness, press the rocker switch down to decrease loudness; press the rocker switch up to increase loudness. -
Page 11: Distance
Sniffer Sleuth User’s Manual Setup Function Modes: Distance The Distance mode allows adjusting of Sleuth’s readout over different operating ranges. A strong reading made at a distance of ten feet would be significantly attenuated if made at 150 feet. When the distance setting is adjusted. -
Page 12: Squelch
Sniffer Sleuth User’s Manual Setup Function Modes: Squelch The Squelch mode allows adjusting of Sleuth’s squelch threshold. To access this function, turn Sleuth on; after the self-test, press the FUNCTION button until Squelch is flashing. To change the squelch threshold, press the rocker switch down to decrease the threshold level; press the rocker switch up to increase the threshold level. -
Page 13: Battery
Sniffer Sleuth User’s Manual Setup Function Modes: Battery The Battery mode displays Sleuth’s battery level. To access this function, turn Sleuth ON; after the self-test, press the FUNCTION button until Battery is flashing. The Relative Indicator remains active in this mode, displaying the relative battery level. -
Page 14: Frequency
Sniffer Sleuth User’s Manual Setup Function Modes: Frequency Allows adjusting of Sleuth’s target frequency. To access this function, turn Sleuth ON; after the self-test, press the FUNCTION button until Frequency is flashing. The Distance indicator now reads the previously-set target frequency, followed by MHz instead of Ft. - Page 15 Sniffer Sleuth User’s Manual Setup Function Modes: Frequency Press FUNCTION again to exit the Frequency mode; this will occur automatically after 5 seconds. NOTE: the model’s frequency range limits how far the frequency can be adjusted in any direction. For instance, on a unit already set to 121.2255, pressing down will yield no results, as “111.2255”...
-
Page 16: External Antenna
Sniffer Sleuth User’s Manual Setup Function Modes: External Antenna When Sleuth is turned on (and not housed in the Docking Station), it always defaults to using the internal dipole. However, this mode allows switching of the Sleuth’s antenna from the internal dipole to an external hand-held dipole antenna. - Page 17 Sniffer Sleuth User’s Manual Using Sleuth in the Field Sleuth is in its operating (normal) mode after it’s turned on and performs a brief self-test. Before turning on Sleuth for field use, make sure the battery is fully charged, and make any user-preference changes that aren’t likely to change during field use - e.g., target frequency, mute, and squelch.
-
Page 18: Using Sleuth In The Field
Sniffer Sleuth User’s Manual Using Sleuth in the Field On Sleuth’s LCD, the µV/m indicator displays the intensity of the signal it is detecting relative to the distance range selected (see Setup Function Modes: Distance). The relative indicator displays the intensity of the detected signal at ±10 dB from the selected sensitivity reference, which can be... -
Page 19: Using Sleuth With The Docking Station
Sniffer Sleuth User’s Manual Using Sleuth with the Docking Station The Docking Station is designed to allow Sleuth to be easily used in a vehicle. It provides a stable platform for holding Sleuth so that the buttons and LCD can be easily seen, and extends battery time by connecting the Sleuth to the vehicle’s power supply. - Page 20 Sniffer Sleuth User’s Manual Using Sleuth with the Docking Station Installation Instructions Docking Station...
-
Page 21: Using Sleuth With An External Antenna
Sniffer Sleuth User’s Manual Using Sleuth with an External Antenna Sleuth can also be used with a handheld external dipole antenna by means of an external antenna adapter (part #100892-001). To use, mount the adapter into the antenna port on the front of the Sleuth unit, then attach the external antenna’s cable to the adapter. -
Page 22: Changing The Battery
Sniffer Sleuth User’s Manual Charging the Battery Sleuth uses a 9.6V nickel-cadmium (NiCad) battery housed within the handle. Everyday use of the battery and recharging will eventually require its replacement. To replace the Sleuth battery, remove the screw (see below) holding the battery compartment door in place. -
Page 23: Appendix A: Adjusting The Dipole Antenna
Sniffer Sleuth User’s Manual Appendix A: Adjusting the Dipole Antenna Optimum antenna lengths for the dipole are given for possible Sleuth frequencies in the table below. Model 100760-001 (80 MHz ~ 120 MHz) Model 100760-002 (120 ~ 150 MHz) Frequency... -
Page 24: Appendix B: Ec Declaration Of Compliance
The Technical File required by these directives, including the original of this Declaration of Conformity, are maintained at the corporate headquarters of ComSonics, Inc. (as listed above) and within the European Community at ComTec Cable Accessories, Ltd., Over Industrial Park, Over, Cambridge CB4 5QE, United Kingdom.
