Polygroup TG70P3D88L14 Assembly Instructions

NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com OR +1 (888) 919-0070
TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from Polygroup®!
Carefully follow the instructions below on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap before inserting into the assembled
stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all wires are free of branch hinges.
7. Connect the light strings as per the color labels indicated in Fig. B and insert green label adapter into the wall outlet. Your entire tree
should now be lit.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one
to the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
MODEL #: TG70P3D88L14
Tree top
Section 2
Section 1
Side view
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
Click
To close the stand, press the metal button
and fold the legs together.
Control box
1
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: AC 120V, 60Hz, 0.25A
Output: DC 28V 0.45A
Controller: 0.45A
Insert Blue Label
Plugs Into Blue
Labeled Extension Cord
Insert Green
Label Extension
Cord into Adapter
Adapter
To Be Plugged
Into Wall
Outlet
