Access Extender Settings
After setup, you can access extender settings via any of the methods below. You can reselect main network, change extended network settings and more.
Note: If your extender and router use the same network name, Method 1 is recommended.
Method 1: Via the Tether App
1. Connect your smartphone to the extender's or router's network.
2. Launch the Tether app, select your extender, and log in.
3. View or change extender settings as needed.
LED Explanation
LED Status Indication (For Range Extender Mode)
The extender is on or off.
On/Off
The system is starting up or firmware upgrade is in progress.
(Power) Blinking
The extender is connected to your router's wireless network and is in a
Solid blue
suitable location.
The extender is receiving a weak signal. Try relocating it closer to your
Solid red
router.
Blinking
WPS connection is in progress.
(Signal)
Off
No wireless connection is established.
The extender is connected or not connected to the 2.4GHz wireless
2.4GHz On/Off
network of your router.
The extender is connected or not connected to the 5GHz wireless
5GHz On/Off
network of your router.
Access Point Mode (AP Mode)
AP Mode: stable wireless performance, wire connection with main router required.
To change your extender to Access Point Mode, do the following:
a. By Web: Login → Find the Mode button on top.
For details, refer to the user guide at https://www.tp-link.com/support.
Mode Logout
English
b. By Tether: Login → Tools →Operation Mode
Operation Mode
System Time
System
Home Clients Tools
Q1. What should I do if the Tether app cannot find my device during setup?
Try another method by following the steps below:
1. Connect your smartphone to the extender's network TP-Link_Extender.
< Settings
Wi-Fi
CHOOSE A NETWORK...
TP-Link_Extender
Other...
2. Launch the Tether app, and select your extender.
Tip: If you have connected to the extender's Wi-Fi but still cannot find your device, try turning off
your cellular data.
3. Follow app instructions to complete the setup.
If you are still having problems, contact our technical support.
Q2. What should I do if the
setup via the Tether app or web browser?
You may have entered incorrect Wi-Fi password for your host router during the
configuration. Check the password and try again.
Make sure the extender is close to your router, preferably within 16 feet, and away
from large electrical appliances.
If you have enabled wireless MAC filtering, wireless access control, or access
control list (ACL) on your router, disable them first, then follow any method on the
front page to complete the configuration.
Try setting it up via the WPS button.
Reset the extender and go through the configuration again.
If you are still having problems, contact our technical support.
Reboot
Wi-Fi
My Devices
Local Device
RExxx
XX-XX-XX-XX-XX-XX
LED doesn't turn solid on after completing
Method 2: Via a Web Browser
1. Connect your computer or smartphone to the extender's network. If you are using a
computer, unplug the Ethernet cable if any.
2. Launch a web browser, enter http://www.tplinkrepeater.net in the address bar, and log in.
3. View or change extender settings as needed.
EasyMesh-Compatible
You can experience strong, stable, and seamless wireless connections
throughout your home with EasyMesh, a whole home mesh standard that works
across different access points for ultimate flexibility.
Seamless Roaming
Connects mobile devices to your routers or extenders that provide the best coverage. Devices
compatible with EasyMesh also share a single Wi-Fi name so you stay connected in every room.
One-Click Settings
Within 2 minutes, press the WPS button on the main router and the extender, then the
EasyMesh network is all set up. TP-Link extenders in factory settings can be connected to
form an EasyMesh network directly without any redundant setup.
Flexible Scalability
Flexibly scale your home networking with different vendors,* different topologies, different Protocols
and different product categories.
*This product is compatible with standardized EasyMesh technology but has not obtained the Wi-Fi EasyMesh
certification. TP-Link EasyMesh-compatible products can network with other devices that use EasyMesh. Failed
connections may be due to firmware conflicts of different vendors. The EasyMesh-Compatible function is still being
developed on some models and will be supported in subsequent software updates.
For more information, visit
https://www.tp-link.com/easymesh/.
Q3. How do I reset the extender?
With the extender powered on, use a pin to press the Reset button for 1 second.
The extender will reboot.
If you need more setup help, please visit
https://www.tp-link.com/support/faq/3074/, or simply scan the QR code.
Safety Information
• Keep the device away from water, fire, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
• Do not use the device where wireless devices are not allowed.
• The socket-outlet shall be installed near the equipment and shall be easily accessible.
Please read and follow the above safety information when operating the device. We cannot
guarantee that no accidents or damage will occur due to improper use of the device. Please use this
product with care and operate at your own risk.
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863.
The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of the Radio Equipment Regulations 2017.
The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca
To communicate with TP-Link users or engineers, please join the TP-Link Community
at https://community.tp-link.com.
AX1500/AX1800/AX3000 Wi-Fi 6 Range Extender Model: RE500X/RE600X/RE700X
SAME
Network Name & Password
for seamless roaming
Scan for Setup Video
Reset
