- Page 1 Manual for Control Panel of Floor Scrubber Machines Model Number RT50D, RT-50D+ RT50, RT-50+...
- Page 2 Table of Contents 1. Power-On Screen....................3 2. Interface Description................... 3 3. Battery Type Selection..................4 4. Electrical Parameters...................5 5. Explanation of Error Codes.................5...
- Page 3 1. Power-On Screen Figure 1-1 Upon powering on the floor scrubber, the screen displays "SUNMAX" on the first line and "Automatic System" on the second line. 2. Interface Description The interface when the machine works normally is shown in Figure 2-1.
- Page 4 ② Clean Water Valve Status: 1 indicates the water valve is dispensing water; 0 indicates the water valve is closed, controlled by the water valve button on the panel. ③ Moving Status: Default "P" for Parking; "D" for forward; "R" for reverse with horn beep;...
- Page 5 Protection Voltage for Brush and Vacuum: 21.6V 4. Electrical Parameters Supply Voltage: DC 24V ~ 35V Operating Temperature: -20°C ~ 80°C Operating Humidity: 0 ~ 95%RH Storage Temperature: -40°C ~ 85°C 5. Explanation of Error Codes Code Explanation Diagram Battery voltage is low, please Low Battery charge as soon as possible.
