Vicpas TPC-651H User Manual

Industrial touch panel computers with intel atom processors
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TPC-651H/1251H
Industrial Touch Panel
Computers with Intel Atom
Processors
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPC-651H and is the answer not in the manual?

Questions and answers

Related Manuals for Vicpas TPC-651H

Summary of Contents for Vicpas TPC-651H

  • Page 1 TPC-651H/1251H Industrial Touch Panel Computers with Intel Atom Processors User Manual...
  • Page 2 Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp. All other product names or trademarks are properties of their respective owners. This Manual Covers the Following Models • TPC-651H • TPC-1251H Part No.2003065102 3rd Edition Printed in Taiwan November 2011 TPC-651H/1251H User Manual...
  • Page 3 Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper instal- lation.
  • Page 4 - Product name and serial number - Description of your peripheral attachments - Description of your software (operating system, version, appli- cation software, etc.) - A complete description of the problem - The exact wording of any error messages TPC-651H/1251H User Manual...
  • Page 5 Safety Instructions Read these safety instructions carefully. Keep this User's Manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for clean- ing. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
  • Page 6 Advantech disclaims all responsibility for the accuracy of any statements contained herein. Caution! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. TPC-651H/1251H User Manual...

  • Page 7: Table Of Contents

    LCD Specifications ............4 Touchscreen Specifications..........4 Power................. 4 I/O Ports Arrangement ............5 Figure 1.1:TPC-651H - I/O Port Arrangement ....5 Figure 1.2:TPC-1251H - I/O Port Arrangement .... 5 Panel Mounting ..............6 Figure 1.3:Panel Mounting ..........6 Dimensions and Cutout ............. 6 Figure 1.4:TPC-651H Dimensions ........
  • Page 8 C.2.4 IOCTL_WDT_GETTIMEOUT: ........37 C.2.5 IOCTL_WDT_SETTIMEOUT: ........37 C.2.6 IOCTL_WDT_REBOOT: ........... 37 Examples ................. 38 TPC-651H/1251H User Manual viii...

  • Page 9: Chapter 1 General Information

    General Information...

  • Page 10: Introduction

    Chapter 1 General Information 1.1 Introduction The TPC-651H and TPC-1251H Touch Panel Computers are state-of-the- art Human Machine Interfaces featuring 5.7" and 12.1 displays with Intel Atom eMenlow XL processors and the following key features: • Fanless By using a low-power processor, the system does not have to rely on fans, which often are unreliable and causes dust to circulate inside the equipment.

  • Page 11: Specifications

    1.2 Specifications 1.2.1 System Kernel • CPU: Intel Atom Z520 1.33GHz • BIOS: Award 4 Mbit flash BIOS • System Chipset: eMenlow XL + Poulsbo • VGA: Integrated in eMenlow XL • Ethernet: 10/100/1000Base-T • Watchdog Timer: W83627DHG watchdog timer; 1.6 second timeout period •...

  • Page 12: Lcd Specifications

    • Controller: RS-232 Interface • Lifespan: 1 million touches at single point 1.5 Power • Input Voltage: 18 - 32V (the fuse will become an open circuit if the input level exceeds 33V • Typical: 24V @0.93Amp TPC-651H/1251H User Manual...

  • Page 13: I/O Ports Arrangement

    1.6 I/O Ports Arrangement The arrangement of the I/O ports is shown in in Figure 1.1 and 1.2. Figure 1.1: TPC-651H - I/O Port Arrangement Figure 1.2: TPC-1251H - I/O Port Arrangement Chapter 1...

  • Page 14: Panel Mounting

    • Weight: TPC-651H - 1.43kg, TPC-1251H - 2.5kg • Dimensions (W x H x D): TPC-651H: 195 x 148 x 58 mm (7.68" x 5.83" x 2.28") TPC-1251H: 311 x 237 x 52.3 mm (12.24" x 9.33" x 2.06") • Cutout: TPC-651H: 189.1 x 142.1 mm...
  • Page 15 86.1 86.1 70.5 70.5 141.1 141.1 Figure 1.4: TPC-651H Dimensions Chapter 1...
  • Page 16 6.50 6.50 186.3 186.3 227.5 227.5 Figure 1.5: TPC-1251H Dimensions TPC-651H/1251H User Manual...

  • Page 17: Chapter 2 System Setup

    System Setup...
  • Page 18 You can easily get TPC started by following the below steps. • Step 1: Unpack the TPC package. Check the packing list at the begin- ning of this manual to make sure all items have been included. Figure 2.1: Unpack the Package TPC-651H/1251H User Manual...
  • Page 19 • Step 2: Install a CompactFlash card containing Windows CE, embed- ded Windows XP or another operating system. Figure 2.2: Install CompactFlash Memory Card Warning It is suggested to turn OFF system power as you plug in or pull out the memory card, even though the CompactFlash memory is hot swappable.
  • Page 20 After installing your system software, you will be able to set up the Ether- net, SVGA, and touchscreen functions. All drivers are stored in a CD- ROM disc entitled “TPC-651H or TPC-1251H” which can be found in your accessory box.

  • Page 21: Chapter 3 Features In Windows Xp Embedded

    Features in Windows XP Embedded...

  • Page 22: Ewf

    Enable read-only media, such as CD-ROM or flash, to boot and run. Prolong the lifespan of write-sensitive storage, such as CompactFlash. TPC-651H/1251H XPE provides EWF RAM RDG mode on system par- tition. All wirte to system partition will be redirected to RMA once this mode is enabled.

  • Page 23: Horm

    3.2 HORM HORM stands for Hibernate Once Resume Many. In HORM environ- ment, a single hibernation file is used to boot the system repeatedly. To set a HORM environment, please follow the steps below. Please make sure EWF is disabled. You can run OSUnLock to disable EWF.
  • Page 24 TPC-651H/1251H User Manual...

  • Page 25: Appendix A Serial Port Settings

    Serial Port Settings...

  • Page 26: Com1/ Com2 Connector Definition

    Appendix A Serial Port Settings A.1 COM1/ COM2 Connector Definition COM 1 COM 2 RS-232 RS-422 RS-485 NDCD NDTR NDSR NRTS NCTS TPC-651H/1251H User Manual...

  • Page 27: Rs-485 / Rs-422 Setting

    A.2 RS-485 / RS-422 Setting Choose integrated peripherals. Choose serial port 2 mode. Appendix A...
  • Page 28 Choose RS-485 or RS-422 for serial port and then save the change. TPC-651H/1251H User Manual...
  • Page 29 Appendix A...
  • Page 30 TPC-651H/1251H User Manual...

  • Page 31: Appendix B Watchdog Timer Programming

    Watchdog Timer Programming...

  • Page 32: Overview

    • Can be enabled and disabled by user's program. • Timer can be set from 1 to 255 seconds or 1 to 255 minutes. • Generates an interrupt or resets signal if the software fails to reset the timer after time-out. TPC-651H/1251H User Manual...
  • Page 33 B.2 Watchdog Timer Programming The I/O port address of the watchdog timer is 2E(hex) and 2F(hex), 2E (hex) is the address port. 2F(hex) is the data port. You must first assign the address of register by writing address value into address port 2E(hex), then write/read data to/from the assigned register through data port 2F (hex).
  • Page 34 0. [default=0] Bit 4: Read status of watchdog timer, 1 means timer is "time out". AA (hex) ----- Write this address to I/O port 2E (hex) to lock the watchdog timer.2 TPC-651H/1251H User Manual...

  • Page 35: Example Programs

    B.3 Example Programs 1. Enable watchdog timer and set 10 sec. as timeout interval ;----------------------------------------------------------- Mov dx,2eh ; Unlock W83627HF Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ;...
  • Page 36 Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Set minute as counting unit Mov al,0f5h TPC-651H/1251H User Manual...
  • Page 37 Out dx,al Inc dx In al,dx Or al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 5 minutes and start counting Mov al,0f6h Out dx,al Inc dx Mov al,5 Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al 3.
  • Page 38 4. Enable watchdog timer to be reset by keyboard ;----------------------------------------------------------- Mov dx,2eh ; unlock W83627H Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- TPC-651H/1251H User Manual...
  • Page 39 Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be strobed reset by keyboard Mov al,0f7h Out dx,al Inc dx In al,dx Or al,40h Out dx,al ;-----------------------------------------------------------...
  • Page 40 Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register Inc dx In al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; lock W83627HF Mov al,0aah Out dx,al TPC-651H/1251H User Manual...

  • Page 41: Appendix C Watchdog Timer Programming On Wince

    Watchdog Timer Programming on WinCE...

  • Page 42: Deviceiocontrol

    This function sends a control code directly to a specified device driver, causing the corresponding device to perform the specified operation. BOOL DeviceIoControl( HANDLE hDevice, DWORD dwIoControlCode, LPVOID lpInBuffer, DWORD nInBufferSize, LPVOID lpOutBuffer, DWORD nOutBufferSize, LPDWORD lpBytesReturned, LPOVERLAPPED lpOverlapped ); TPC-651H/1251H User Manual...

  • Page 43: Parameters

    C.1.1 Parameters • hDevice [in] Handle to the device that is to perform the operation. Call the Cre- ateFile function to obtain a device handle. • dwIoControlCode [in] Specifies the control code for the operation. This value identifies the specific operation to be performed and the type of device on which the operation is to be performed.

  • Page 44: How To Use The Control Code

    WDT driver, your application must trigger the watchdog once during the watchdog timer period. If your application has not triggered at the specified period, the device will reboot automatically. lpInBuffer: unused. nInBufferSize: unused. lpOutBuffer: unused. nOutBufferSize: unused. TPC-651H/1251H User Manual...
  • Page 45 C.2.4 IOCTL_WDT_GETTIMEOUT: Gets the Watchdog time setting. lpInBuffer: unused. nInBufferSize: unused. lpOutBuffer: The DWORD points to your watchdog time setting. The Watchdog time setting is just a number. 0 means 2 seconds, 1 means 5 seconds, 2 means 10 seconds, 3 means 15 seconds, 4 means 30 seconds, 5 means 45 seconds and 6 means 60 seconds.
  • Page 46 // assign the WDT driver name wsprintf(szClassName, TEXT("WDT1:")); // Open the WDT driver m_hWDT = CreateFile(szClassName, GENERIC_READ GENERIC_WRITE, 0, NULL, OPEN_EXISTING, FILE_ATTRIBUTE_NORMAL, NULL); if ( m_hWDT == INVALID_HANDLE_VALUE ) { DebugMsg(CString("WDT driver fail")); return; DWORD dwTemp; DWORD nIndex=2; TPC-651H/1251H User Manual...
  • Page 47 // Set the Watchdog Timer as 10 seconds. Number 2 means 10 seconds. DeviceIoControl(m_hWDT, IOCTL_WDT_SET_TIMEOUT, &nIndex, sizeof(nIndex), NULL, 0, &dwTemp, NULL); // Enable the Watchdog timer DeviceIoControl(m_hWDT, IOCTL_WDT_ENABLE, NULL, 0, NULL, 0, &dwTemp, NULL); While (1) { // do your job here. Sleep(8000);...
  • Page 48 TPC-651H/1251H User Manual...
