PCB Piezotronics ICP M260A01 Installation And Operating Manual page 16

Model Number
260A01
Performance
Sensitivity(± 20 %)(Z Axis)
Sensitivity(± 20 %)(X or Y Axis)
Measurement Range(Z Axis)
Measurement Range(X or Y Axis)
Maximum Force(z axis)
Maximum Force(x or y axis)
Maximum Moment(z axis)
Maximum Moment(x or y axis)
Broadband Resolution(z axis)
Broadband Resolution(x or y axis)
Upper Frequency Limit
Low Frequency Response(- 5 %)(z-axis)
Low Frequency Response(- 5 %)(x or y axis)
Non-Linearity
Cross Talk(between x and y axis)
Cross Talk(between (x or y axis) and z axis)
Environmental
Temperature Range
Electrical
Full Scale Output(Z Direction)
Full Scale Output(X and Y Direction)
Discharge Time Constant(z axis)
Discharge Time Constant(x or y axis)
Excitation Voltage(all channels)
Constant Current Excitation(all channels)
Output Impedance
Output Bias Voltage
Spectral Noise(1 Hz)(X & Y)
Spectral Noise(10 Hz)(X & Y)
Spectral Noise(100 Hz)(X & Y)
Spectral Noise(1,000 Hz)(X & Y)
Spectral Noise(1 Hz)(Z)
Spectral Noise(10 Hz)(Z)
Spectral Noise(100 Hz)(Z)
Spectral Noise(1,000 Hz)(Z)
Output Polarity
Physical
Preload
Stiffness(z axis)
Stiffness(x or y axis)
Size (Height x Length x Width x Bolt Diameter x ID x 0.390 in x 1.075 in x 0.95 in x 0.205
Sensing Surface) in x 0.319 in x 0.680 in
Weight
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
[6]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
EN GLISH SI
2.5 mV/lb 0.56 mV/N
10 mV/lb 2.25 mV/N
1,000 lb 4.45 kN
500 lb 2.22 kN
1,320 lb 5.87 kN
660 lb 2.94 kN
14 ft-lb 18.98 Nm
13 ft-lb 17.63 Nm
0.006 lb-rms 0.027 N-rms
0.002 lb-rms 0.0089 N-rms
90 kHz 90 kHz
0.01 Hz 0.01 Hz
0.001 Hz 0.001 Hz
≤ 1 % FS ≤ 1 % FS
± 3 % ± 3 %
± 5 % ± 5 %
-65 to +250 °F -54 to +121 °C
± 2.5 VDC ± 2.5 VDC
± 5 VDC ± 5 VDC
≥ 50 sec ≥ 50 sec
≥ 500 sec ≥ 500 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
0.0003 lb/√Hz 0.00134 N/√Hz
0.00015 lb/√Hz 0.000668 N/√Hz
0.00005 lb/√Hz 0.000223 N/√Hz
0.000015 lb/√Hz 0.0000668 N/√Hz
0.0015 lb/√Hz 0.00668 N/√Hz
0.00055 lb/√Hz 0.00245 N/√Hz
0.0002 lb/√Hz 0.000891 N/√Hz
0.000055 lb/√Hz 0.000245 N/√Hz
Positive Positive
5,000 lb 22.25 kN
10 lb/µin 1.75 kN/µm
4 lb/µin 0.7 kN/µm
9.90 mm x 27.3 mm x 24.1 mm x 5.21
mm x 8.10 mm x 17.27 mm
0.927 oz 26.27 gm
Stainless Steel Stainless Steel
Hermetic Hermetic
4-Pin 4-Pin
Side Side
[1][2]
Optional versions have identical specifications and accessories as listed for the standard model except
[1][2] where noted below. More than one option may be used.
- Water Resistant Cable
W
Electrical Connection Position
[3]
[3]
[4]
[5]
[3]
[3]
N OTES:
[1]Sensitivites are for listed preload. Sensitivites may vary ±5% depending on preload used.
[2]Sensitivities are dependent upon supplied bolt.
[3]Typical.
[4]Zero-based, least-squares, straight line method.
[5]Preload should be at least 10 times the X and Y operating range used.
[6]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 081A70 Mounting Stud (1)
Model 082B02 Anti-Friction Washer (1)
Model 083A10 Pilot Bushing (1)
Model M081A70 Mounting Stud (1)
Entered: LK Engineer: RPF
Date: 04/17/2020 Date: 04/17/2020 Date: 04/17/2020 Date: 04/17/2020 7753
3425 Walden Avenue, Depew, NY 14043
Revision: P
ECN #: 50553
OPTION AL VERSION S
Side Side
Sales: KK Approved: RPF Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
