ICE MAKER
Model BI-95BTP
FEATURES
1.
High ice production
2.
Requires no drain
3.
Front vented for built-in installation
4.
Conserves water
5.
Conserves energy
6.
Field reversible door with zero clearance
door swing
7.
Adjustable temperature control
8.
1/2 inch wide flange
9.
Corrosive resistant components
ADDITIONAL FEATURES:
• Will accept flat or raised panel
• Panel size: H 13-15/32" X W 12-15/16"
• Travel pin keeps door securely closed
• See through, removable ice bucket
• Shipping weight: 65 lbs.
• Available in 110/115V 60 cycle or 220/230V 50/60 cycle
KCC Printed in U.S.A.
13-13/16 (35.1)
* POWER
CORD
15-1/16 (38.2)
W/FLANGE
* ON BACK OF UNIT
INCHES (CENTIMETERS)
BENEFITS
Produces up to 23 lbs. of ice per day and stores 12 lbs.
Easy and inexpensive to install. Only needs 1/4 inch outside diameter
water line connection.
No need for extra fans, air space, or special venting to the outside of the
cabin. Do not obstruct front grille.
Only 2-3/4 gallons of water required to produce approximately 22 lbs. of ice.
Uses less electricity than a 75-watt light bulb.
Fits any location, easy access.
Permits adjustment of daily ice rate.
Surrounds front of cabinet for easy mounting in surrounding cabinets.
Hinges and fasteners are stainless steel to prevent corrosion.
All specifications subject to change without notice.
25-1/4
(64.0)
HT/W FLANGE
24-3/4
(62.9)
8-1/2
(21.6)
* WATER
LINE
INLET
ADD 1-1/2" TO DEPTH FOR
WATER LINE CONNECTION
8900 N. 55th Street
Milwaukee, Wisconsin 53223
(414) 354-0300
FAX (414) 354-7905
www.u-line.com
17 (43.2)
14-3/8 (36.5)
FLANGE
P/N SS-BI-95BTP
