VMIC reserves the right to make any changes, without notice, to this or any of VMIC’s products to improve reliability, performance, function, or design. VMIC does not assume any liability arising out of the application or use of any product or circuit described herein; nor does VMIC convey any license under its patent rights or the rights of others.
Page 3
1. Connecting the VMIVME-7454 to a VMIVME-7588 or VMIVME-7686. 2. Connecting the VMIVME-7454 to a VMIVME-7587. Do not power-up the VMIVME-7454 without it being connected to the CPU Board in W A R N I N G one of the hardware configurations shown on the following pages.
Page 4
Note connected. Use the last connector on the cable; otherwise, use the connector best suited for your application. 6. Slide the CPU board into the VMEbus chassis. 7. Attach cables to the VMIVME-7454 front panel as shown in Figure 1.
Page 5
Connecting the VMIVME-7454 to a VMIVME7588, Including the SCSI 2 Selection Switch Figure 1...
Page 6
VMIVME-7454 Installation Guide Table 1 SCSI 2 ID Settings Switch Positions SCSI ID Conflicts with the CPU SCSI Controller ID of 7.
Page 7
VMEbus CPU Board Component Side IDE Hard Drive Connector (Not Used) Floppy Drive Connector Floppy Connector Cable 360-000106-003 from the VMIVME-7454 Connecting a Floppy Cable to a VMIVME-7588 or VMIVME-7686 Figure 2...
Page 8
Note connected. Use the last connector on the cable; otherwise, use the connector best suited for your application. 6. Slide the CPU board into the VMEbus chassis. 7. Attach cables to the VMIVME-7454 front panel as shown in Figure 3.
Page 9
Connecting a VMIVME-7587 to a VMIVME-7454 Figure 3...
