- Page 2 •Angled eyepiece and rotating tripod mount make it easy to use whether you’re standing or prone. •ARCA-Swiss compatible tripod mount •M-LOK attachment points for accessories such as Red Dots or Range Finders. 2 | Signature HD Spotting Scope...
- Page 3 SIGNATURE HD SPOTTING SCOPE PRODUCT MAP Eyepiece with Twist-up Eyecup Magnification Adjustment Ring M-LOK Acessory Rails Retractable Sunshade Fine Focus Adjustment ARCA-SWISS 1/4” - 20 Tripod Mount Objective Lense 20-60x85mm 3 | Signature HD Spotting Scope...
- Page 4 (Sold Separately) Burris offers an accessory eyepiece with a fixed power 30x magnification. Ideal for tactical and precision shooting, it is available with either an SCR Mil or SCR MOA reticle. SCAN TO VIEW PRODUCT 4 | Signature HD Spotting Scope...
- Page 5 Remember that your field of view is reduced as magnification is increased. It might be easier to start with a lower power and then zoom for greater detail. 5 | Signature HD Spotting Scope...
-
Page 6: Viewing Tips
Extendable sunshade The integrated sunshade can be used to block stray light and reduce glare. To use the sunshade, just slide the hood forward. This also provides some protection from rain and snow. 6 | Signature HD Spotting Scope... -
Page 7: Adjust The Viewing Angle
NEEDS NEW PHOTOS •Rotate spotting scope body to the most comfortable viewing position. •Hold the scope body in place and tighten the thumbscrew by turning to the right or clockwise. 7 | Signature HD Spotting Scope... - Page 8 M-LOK ACCESSORY MOUNT Remove the rubber covers engraved with the Burris logo, located on either side of the scope body, just in front of the eyepiece to expose the M-LOK slots. The M-LOK will accept any M-LOK compatible accessory that fits within the...
-
Page 9: Care And Maintenance
Care & Maintenance The Signature HD spotting scope is fully waterproof and fogproof. In the event that the lenses are subject to dust, dirt or mud, follow these steps to clean and protect the lens surface. Failure to remove grit before final cleaning can damage lens coatings. - Page 10 High 18 mm ± 5% EYE RELIEF 19.7 mm ± 5% Fine Focus FOCUS LENGTH 16.25 in. (ZERO DIOPTER) 70.4 oz WEIGHT -5°F to 150°F STORAGE TEMP 5°F to 140°F OPERATING TEMP IPX7 WATERPROOF 10 | Signature HD Spotting Scope...
- Page 11 1 1 | Signature HD Spotting Scope...
- Page 12 INSTR-9103...
