Page 1 & user guide Jet Thruster Single & Combi www.jetthruster.com Jet Thrusters - JT-30 | JT-50 | JT-70 | JT-90 All our products are manufactured according to CE regulations. We keep the rights to change descriptions, graphs or statements, which are required for technical development of our Jet Thruster systems.
Page 2 Electrical Installation SELECT YOUR CONTROLS: CONTROLLER VERSION (PAGES 5-10) D-010-10C Holland Marine Parts D-010-06 D-010-10...
Page 3 - Power is on (no power check fuse) Combi Jet Thruster se�ngs Bow & Stern Thruster Green + Red Light on Conven�onal Bow Thruster + Stern Jet Thruster - Power on + Controller func�on ok Conven�onal Stern Thruster + Bow Jet Thruster Red Light Flashing Fast...
Page 4 CONTROLLER UNIT: SINGLE & DUAL HELM SET UP Combi Single E-307-00 (10m) E-301-00 (10m) E-304-00 (2m) (5m) (10m) (10m) 12V service battery Series parallel switch Always connect all battery negatives to a common ground. Pump unit (use E-308-00 to extend cable) Directional 3-way valve(s) (use E-309-00 to extend cable) D-010-10C...
Page 5 CONTROLLER UNIT: SINGLE & DUAL REMOTE SET UP Transmitter E-307-00 (10M) Receiver E-301-00 (1m) E-304-00 (2m) (5m) (10m) (10m) 12V service battery Always connect all Series parallel switch battery negatives to a common ground. Pump unit (use E-308-00 to extend cable) Directional 3-way valve(s) (use E-309-00 to extend cable) D-010-10C...
Page 6 CONTROLLER UNIT: BOW AND STERN DOUBLE SYSTEM & REMOTE SET UP D-010-10C Holland Marine Parts D-010-06 D-010-10...
Page 7 This controller is designed to control Jet Thrusters in single- and combi mode. Also This controller can be used to operate Conventional thrusters of any brand, also in combination with a Jet Thruster. This controller is designed to be used in pleasure crafts, to maneuver yachts sideways.
Page 8 2. Installation and Explanation Installation and Explanation - The controller Should be mounted Ver cally in an acessible loca on. - Use Washers under the moun ng screws to avoid damage and ensure a proper ﬁxa on. - The controller is (if the provided caps are used) splashproof. (IP53) - Ventilaton is not necessary.
Page 9 3. Program Functions and Settings behind the Left cap you’ll ﬁnd the dipswitches, Control Led’s and Invertswitches. Below their function is described. Dipswitches ((Firmware V04.001) dd 20-11-2018) On is Up and Down is Oﬀ. (Between brackets is standard setting.) - 1- Single (on) or Combi (oﬀ) (on) - 2- Conventional Bow thruster.
Page 10 Electrical Installation: Jet Thruster Single and Combi Holland Marine Parts recomments Optima Batteries Optima battery YT S 5.5L JT-30 12V 1 x YT S 5.5L 75Ah Visit our website JT-50 24V 2 x YT S 5.5L 75Ah www.jetthruster.com JT-70 24V 4 x YT S 5.5L 75Ah...
Page 11 If the controller indicated no Common ground there will be a Green light on and Red Flashing fast. Please follow this schedule to resolve this problem. Battery for Jet Thruster Battery for Controller Common Grounding point D-010-10C Holland Marine Parts...
Page 12 Jet Thruster pump units 30Kgf 50Kgf JT-50 compact 110 thrust LBS 24V/48V JT-30 compact 66 thrust LBS 12V Force Force 30 Kgf 50 Kgf Voltage DC Voltage DC 24V / 48V E-motor capacity kW E-motor capacity kW Current Current 480A...
Page 13 MosFet battery separator from the alternator. Please note: More electricity will be required as a result of the installation of the Jet Thruster. That is why in some cases it is recommended for the alternator to be converted to high yield or to place a separate alternator.
Page 14 JT-30 (12V) charged with 12V charger Contactor Optima battery Fuse Main switch Controller Charger 12V Service batteries Diode bridge Alternator Start battery D-010-10C D-010-06 D-010-10 Holland Marine Parts...
Page 15 JT-50 (24V) charged with 12V charger Series parallel switch Strips pre mounted Contactor Optima batteries Fuse Main switch Controller Charger 12V Service batteries Diode bridge Alternator Start battery D-010-10C Holland Marine Parts D-010-06 D-010-10...
Page 16 JT-50 (24V) charged with 12V Step up Charger Optima batteries Contactor Mac Plus - Step up charger Fuse Main switch Controller Charger 12V Service batteries Diode bridge Alternator Start battery D-010-10C D-010-06 D-010-10 Holland Marine Parts...
Page 17 JT-70/JT-90 (24V) charged with 12V charger Series parallel switch Strips pre mounted Optima batteries Contactor Controller Fuse Main switch Charger 12V Service batteries Diode bridge Alternator Start battery D-010-10C Holland Marine Parts D-010-06 D-010-10...
Page 18 JT-70/JT-90 (24V) charged with 12V Step up Charger Optima batteries Mac Plus - Step up charger Contactor Controller Fuse Main switch Charger 12V Service batteries Diode bridge Alternator Start battery D-010-10C D-010-06 D-010-10 Holland Marine Parts...
Page 19 JT-70/JT-90 (24V) in a 24V board network Optima batteries Controller Contactor 24V -> 12V converter Fuse Main switch Charger 24V Service batteries Diode bridge Alternator Start battery D-010-10C Holland Marine Parts D-010-06 D-010-10...
Page 20 JT-70/JT-90 (48V) in a 24V board network Series parallel switch Strips pre mounted Controller Optima batteries Contactor 24V -> 12V converter Fuse Main switch Charger 24V Service batteries Diode bridge Alternator Start battery D-010-10C D-010-06 D-010-10 Holland Marine Parts...
Page 21 JT-70/JT-90 (48V) in a 12V board network Series parallel switch Strips pre mounted Optima batteries Mac Plus - Step up Charger 12V -> 24V Contactor Controller Fuse Main switch Charger 12V Service batteries Diode bridge Alternator Start battery D-010-10C Holland Marine Parts D-010-06 D-010-10...
Page 22 JT-50/JT-70/JT-90 (48V) in combination with electric propulsion Controller Contactor 48V -> 12V 20A converter Main switch Fuse Main propulsion Charger 48V Fuse D-010-10C D-010-06 D-010-10 Holland Marine Parts...
Page 23 JT 70/90 - 48volt - 230V Grid Battery cable size: <1m 70mm2 >1m 95mm2 * This battery setup example shows a <1m cable length D-010-10C Holland Marine Parts...
Page 24 The Series Parallel Switch creates a temporary 24V environment out of two 12V batteries to power the DC motor from the pump unit. The switch itself operates at 12V. The moment the Jet Thruster system activates, 12V power activates the coil that makes the switch connects the battery cables.
Page 25 Operation: The pump head of the Jet Thruster system must be installed under the water line in order to prime this centrifugal pump. In some limited cases of fast moving vessels a vacuum can be produced when the nozzles rise above the waterline and the in- take remains in the water.
Page 26 air leading out of vessel Contactor at pump unit Select applied contactor support and position of F (+12V) and G (Ground) according to the pump unit the installation is applied for. See appendices for additional information. Position of electrical valve must be above water line.
Page 27 air leading out of vessel Contactor at pump unit Select applied contactor support and position of F (+12V) and G (Ground) according to the pump unit the installation is applied for. See appendices for additional information. Position of electrical valve must be above water line.
Page 28 Torque on battery cable connections and other parts Warning: Loose or unsufficient tightened battery connections can cause damage or ﬁre: Make sure to tighten the nuts of the connections as mentioned. Use quality terminals and right crimping tools to ensure a quality electrical installation safety! Fuse holder: torque 15Nm to nuts.
Page 29: Warranty Provisions
Jet Thruster system. Remember: Always use com- mon sense when installing, using and servicing the Jet Thruster and it’s components. In case anything is not clear: Contact your dealer or Holland Marine Parts BV for assistance.
Page 30: Before You Start
Installation & maintenance Before you start: watch our installation video’s! www.youtube.com/user/hollandmarineparts D-010-10C Holland Marine Parts...
Page 31 Important information before you start A Jet Thruster is a Battery powered water pump system which pumps water from A to B: The water intake and water exit can be at different locations in a boat, which is unique for bow or stern thruster systems for pleasure boats.
Page 32 3: Position of Nozzles (Bow and Stern) The Jet Thruster will be most effective when the nozzles are placed as far forward or aft as possible. The topside of the nozzle tube must be 7-10cm below the waterline, not deeper or higher.
Page 33 1: Pump, pump position and water inlet A Jet Thruster makes use of a dedicated, not-self-priming, centrifugal pump. You must place the pump below the water line for this reason. More speciﬁc: At least the top side of the pump head must be below the water line.
Page 34 You can place the pump any where in the boat as long as you keep the pump below the water line. You have to keep the water inlet close to the pump. Similar to cooling water for the main engine, the Jet Thruster sys- tem has a thru-hull connection.
Page 35 The water inlet must be close to the pump. The inlet is protected with a ﬁlter. Make use of the tool, pro- vided with the water inlet to have grip/control during installation. After you drilled the hole, make sure to remove anti fouling until you reach the gelcoat. You can mark the exact outside diameter of the flange from the inlet by carving around the flange with a knife.
Page 36 Do not lift the valve by the cover or by the cable, it is not designed for that. Jet Thruster Single: Remove the black plastic cover, by unscrewing the 3 screws. Below the cover you will ﬁnd the terminals CDE for electrical connection.
Page 37 If your boat comes out of the water, do not clean it yet! Now in this situation the waterline is visible very well. It will give you a perfect reference where to place the nozzle. Jet Thruster nozzles are very small.
Page 38 You can use the 0-degree nozzle to place these in the sides of the boat. Because the pump can be in a different place, you can guide the hoses thru the boat, towards the valve, and the pump. A Jet Thruster is a Very flexible and efficient stern thruster.
Page 39 A Jet Thruster nozzle assembly includes the following components: • Composite nozzle • Composite guide ring • Composite 45 elbow (if you do not need it, do not use it) • Composite spacer rings 15mm & 25mm • Composite 2” nut •...
Page 40 Important Preparation advice: Possible the best thing you can do is to cut all hoses to the required length before you start the Nozzle parts assembly with Sikaflex291i: • Make sure the directional 3-way valve is ﬁxed ﬁrmly into position •...
Page 41: Frequently Asked Questions
Frequently asked questions D-010-10C Holland Marine Parts...
Page 42 D-010-10C Holland Marine Parts...
Page 43 D-010-10C Holland Marine Parts...
Page 44 • The nozzles of the Jet Thruster are located beneath the water line. Do not activate the system and do not operate the Jet Thruster when there are people, animals or vulnerable items in the vicinity of your boat and the inlet and nozzles.
Page 45 - In rare conditions it might be possible that the pump unit of the Jet Thruster does not prime. If you notice a high rpm from the pump unit and no thrust force, do not attempt to prime the pump unit by continuous activating the system.
Page 46 Winterising: Youtube Channel: 2” / 51 mm Jet Thruster - See video Preferably have the system winterised by a specialist. Please note: Frost/ice can do a lot of damage if you fail to drain the system. Use a compressor to remove the water present in the system by means of air pressure.
Page 47: Troubleshooting
- Check - Change the Fuse 20A - Red Led Flashing fast - Engine is overheated - Let the Jet Thruster cool down 20+ min - Red Led Flashing fast - There is no common ground cable - See page 12 for wire schedule...
Page 48 - In rare conditions it might be possible that the pump unit of the Jet Thruster does not prime. If you notice a high rpm from the pump unit and no thrust force, do not attempt to prime the pump unit by continuous activating the system.
Page 49 D-010-10C Holland Marine Parts...
Page 50 Exploded View Jet Thruster JT-30 Single Compact I-331-00 Pump unit JT30 I-309-00 I-307-00 V-500-00 I-336-00 I-114-00 I-310-00 I-312-00 I-308-00 I-115-00 I-321-00 I-113-00 I-302-00 I-316-00 Pump unit JT-30 JT-30-50 2-Way pump outlet P-507-52 3-Way valve V-500-00 Hose clamp 77-94 mm I-331-00...
Page 51 Option 2b: P-507-52 V-100-58 I-113-58 I-114-00 Pumpunit JT50 I-311-00 I-307-00 I-310-00 I-309-00 I-316-00 I-115-00 I-302-00 I-321-00 I-336-00 Exploded View Jet Thruster 50 Single Compact Vertical I-321-00 P-115-58 V-100-58 I-321-00 I-113-58 I-115-00 I-302-00 I-114-00 I-336-00 I-114-00 I-316-00 D-010-10C Holland Marine Parts...
Page 52 Exploded View Jet Thruster JT-70/90 Single Pump unit JT-50 JT-90 24V I-321-00 V-200-50 I-213-00 I-275-01 I-316-00 I-267-00 I-269-GF I-336-00 I-261-00 Pump unit JT-90 JT-50 JT-90 24V 2-Way pump outlet P-259-00 3-Way valve V-200-50 Water inlet 4” I-267-00 Hose 110 mm / L=1m/3.3ft I-268-01 Nut 4”...
Page 53 Exploded View Jet Thruster JT-70/90 Combi P-259-00 Pump unit JT-50 JT-90 24V V-200-50 I-336-00 I-316-00 I-269-GF I-321-00 I-213-00 I-267-00 Option for vertical pump Exploded View Jet Thruster JT-70/90 Vertical Single Pump unit JT-50 JT-90 24V I-317-00 V-200-50 I-213-00 I-213-00 I-321-00 I-316-00 I-331-00 I-336-00 D-010-10C...
Page 54 Technical Specifications JT-30 Pump head in position I 60mm 210mm 243mm P-115-52: Straight pump outlet P-513-52: 90 pump outlet P-507-52: 2-way pump outlet 3 options for hose connector Water inlet assembly: on pump outlet: Connect with flexible hose to inlet on pump unit.
Page 55 158,7 105,3 158,7 105,3 158,7 226,25 226,25 226,25 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS JT-30 Pump outlet Position 2 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS JT-30 Pump outlet Position 2 Ra 3.2 0.03 0.03 Ra 3.2 0.03 0.03 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±0.5º...
Page 56 Outlet Inlet 226,25 227,5 D-010-10C Holland Marine Parts UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS JT-30 Vertical + inlet 0.03 0.03 Ra 3.2 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±1º - BREAK ALL EDGES Drawn by Toofan Pour Part No.
Page 57 JTV-30-50 12V Jet Thruster Vertical 30Kgf D-010-10C Holland Marine Parts...
Page 58 Technical Specifications JT-50 Compact Pump head in position I 60mm 210mm 243mm P-115-58: Straight pump outlet P-513-58: 90 pump outlet P-507-58: 2-way pump outlet Water inlet assembly: 3 options for Connect with flexible hose to inlet on pump unit. hose connector Max.
Page 59 Technical Specifications JT-50 Compact Pump head in position II 60mm 210mm 243mm P-115-58: Straight pump outlet P-513-58: 90 pump outlet P-507-58: 2-way pump outlet 2 options for Water inlet assembly: hose connector Connect with flexible hose to inlet on pump unit. on pump outlet: Max.
Page 60 Technical Specifications JT-50 Compact Vertical 60mm 210mm 243mm P-115-58: Straight pump outlet P-513-58: 90 pump outlet P-507-58: 2-way pump outlet 3 options for hose connector on pump outlet: Outlet Inlet 226,25 227,5 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS JT-50 vertical+ inlet 0.03 0.03 D-010-10C...
Page 61 ﬁrmly and secure in place. Because the pump head is close to the hull, the Jet Thruster Vertical is an ideal Jet Thruster for boats with shallow draft such as Waterskiing and wakeboarding boats.
Page 62 Note: If you do not place the pump head below the water line, the Jet Thruster system will not work: Check the boat to ﬁnd the waterline! It’s possible to position the pump under an angle. In many cases this is the only option.
Page 63 Insert tool in water inlet and use wrench to srew inlet in place - Thoroughly clean all parts, threads and surfaces with Acetone. - Test ﬁt the modiﬁed Water Inlet in the pump head, but be careful not to damage the pump head threads - Apply sufficient Sikaflex 291i / PU Sealant to all parts as indicated in the picture Have one person present inside the boat who will hold on the Pump assembly Have one person present outside the boat to continue with the following steps:...
Page 64 Technical Specifications JT-70 Pump head in position I Ø 76mm / 3” Ø 76mm / 3” Ø 76mm / 3” 100x100mm / 3.94”x 3.94” 100x220mm / 3.94”x 8.66” 100x220mm / 3.94”x 8.66” P-242-00: Straight pump outlet P-222-00: 90 pump outlet P-259-00: 90 pump outlet Water inlet assembly:...
Page 65 Technical Specifications JT-70 Pump head in position II Ø 76mm / 3” Ø 76mm / 3” Ø 76mm / 3” 100x100mm / 3.94”x 3.94” 100x220mm / 3.94”x 8.66” 100x220mm / 3.94”x 8.66” P-242-00: Straight pump outlet P-222-00: 90 pump outlet P-259-00: 90 pump outlet Water inlet assembly:...
Page 66 JTV-70-50 24V 70Kgf 248,2 328,4 298,2 335,2 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS JT-70 vertical Ra 3.2 0.03 0.03 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±1º - BREAK ALL EDGES Drawn by : Toofan Pour Part No. D-010-10C Holland Marine Parts Scale Drawn date Customer...
Page 67 Technical Specifications JT-90 Pump head in position I Ø 76mm / 3” Ø 76mm / 3” Ø 76mm / 3” 100x100mm / 3.94”x 3.94” 100x220mm / 3.94”x 8.66” 100x220mm / 3.94”x 8.66” P-242-00: Straight pump outlet P-222-00: 90 pump outlet P-259-00: 90 pump outlet Water inlet assembly:...
Page 68 Technical Specifications JT-90 Pump head in position II Ø 76mm / 3” Ø 76mm / 3” Ø 76mm / 3” 100x100mm / 3.94”x 3.94” 100x220mm / 3.94”x 8.66” 100x220mm / 3.94”x 8.66” P-242-00: Straight pump outlet P-222-00: 90 pump outlet P-259-00: 90 pump outlet Water inlet assembly:...
Page 69 JTV-90-50 24V 90Kgf 335,2 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS JT-90 vertical 1 0.03 0.03 Ra 3.2 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±1º - BREAK ALL EDGES D-010-10C Holland Marine Parts Drawn by : Toofan Pour Part No. Scale Drawn date : 21-04-2017...
Page 70 JT70 / JT90 Vertical pump position 542mm Sikaflex 291i Hull 100% flat and preferable horizontal Sikaflex 291i Dc motor, 11 / 15.5Kw P-319-00 Seal I-604-00 Intermediate Flange Water I-618-01 Hexagon cylinder bolt M10x35 F-210-00 Water inlet I-616-00 Hexagon socket countersunk head M10x50 F-222-00 Seal Pump outlet P-260-00...
Page 71 Position of pump unit: - Select a perfect flat position for the pump unit. If not flat, the hull must be made flat - Select a horizontal position. Pump motor must be in vertical position. - Pump unit must be placed below the waterline - Pump unit must be ﬁxed to the interior.
Page 72 Technical Specifications 3-way valve JT-30 Composite (52mm) 207mm (8,15”) 114mm (4,49”) 160mm (6,29”) 241mm (9,49”) 9mm (0,35”) 55mm (2,16”) D-010-10C Holland Marine Parts...
Page 73 Technical Specifications 3-way valve JT-50 (58mm) 207mm (8,15”) 114mm (4,49”) 160mm (6,29”) 241mm (9,49”) 9mm (0,35”) 55mm (2,16”) D-010-10C Holland Marine Parts...
Page 74 Technical Specifications 3-way valve JT-70 / JT-90 275mm (10,83”) 227mm (8,94”) 144mm (5,67”) 188mm (7,4”) 9mm (0,35”) 70mm (2,75”) D-010-10C Holland Marine Parts...
Page 75 C: position of nozzles Note: The Jet Thruster is most efficient when the connections between system components made with the included pressure hoses are as short as possible. Place the pump unit and the 3-way valve as close to the nozzles as possible to achieve this.
Page 76 Holland Marine Parts advises to place suitable battery’s directly next to the pump unit in order to keep the battery cabling as short as possible! The jet thruster uses a lot of electrical energy in a short period of time.
Page 77 Pump head position and pump outlets can be changed. Contact your dealer or Holland Harine Parts for additional information. Longitudinal placement: For longitudinal placement attach the 90° hose connector + rubber seal to the pump head. P-513-58 Pump head position I 2”...
Page 78 • Can be placed above or below waterline in any position Jet Thruster Combi: Dirt or sand that drift in the ocean can build up in the system, this will be flushed out during use. The function of the 3-way valve allows for an amount of water flowing through, even when the valve is not in use.
Page 79 C: Position of the nozzles • Based on the type of hull you have chosen a certain nozzle type. Select this nozzle type and the corresponding installation instructions from the below scheme. Please note: Nozzles JT 30 and JT 50 are equipped with an internal Venturi. Do not damage or remove this constriction! Weldable Part number Diameter...
Page 80 Use the included 45 degree elbows in order to place the nozzles as far as forward or aft as possible. In case of application as a stern Jet or in case of Jet Thruster Combi: place the system as far as possible to the stern.
Page 81 Nozzle positions and installation options Note: The standard installation kit provides 1 x 2” 45 elbow. Additional parts must be ordered separately. Note: If you do not need the 45 elbow in your installation: do not use it. I-361-00 1 x 2” BSP 45 elbow to each nozzle.
Page 82 Installing Composite nozzle’s 1. Drilling and preparing of thru-hull nozzle 1.1 Drill 65mm hole Section of boot hull 1.2 Smooth corner with sandpaper 1.3 clean both sides of the thru-hull area with acetone or breakcleaner. This area needs to be completley grease free. 2.
Page 83 This amount of thread is needed for the ball valve or 45 degree elbow. JT-70 & JT-90 assambly Final assambly of a JT-70 & JT-90 Jet Thruster. Nozzle with guide rings & spacers, composite 2’’ ball valve and hose connector.
Page 84 Installing the nozzles and water intake. In case of steel or aluminum vessel plating weldable nozzles are available. Learn more at: For polyester and wooden vessel plating flange threaded nozzles are available. www.youtube.com/user/hollandmarineparts 1: Place vessel horizontal. Select optimum position for nozzle: As far to the front of bow or stern as possible, top side of nozzle 10cm / 4”...
Page 85 7: Outside of vessel: Weldable nozzle: Weld in the nozzle and cut of remaining length. Smoothen surface. Note: Do not cut into, or cut away the internal restriction within the nozzle! Flange treaded nozzle: In case of an rough or not entire flat surface: Apply sealant for maritime purposes: Sikaflex-291i / 3M 5200 adhesive / sealant on the side of the flange of the nozzle that contacts the vessel plating.
Page 86 Remove fouling as soon as possible. Keep surfaces clean. Do not scratch the surfaces with metal tools. Run the Jet Thruster system: By using the Jet Thruster System you clean it and fresh oxygen-rich water ensure formation of the protective ﬁlm Option 2:...
Page 87 Cathodic Protection: Connect the optional Zinc Anode System to the Jet Thruster Pump Unit to protect Stainless Steel parts from corrosion. Parts: • Anode must be inspected / replaced when worn out. • JT30/JT50: CP-001-00 • Verify no live battery cables or live + cables make contact •...
Page 88 In this case clean the stainless steel surface with household mineral bath and tile cleaner. - Important: Never use Steel Wool or any other metal parts or tools on the stainless steel Jet Thruster parts and surfaces.
Page 89 Cathodic Protection of Stainless steel nozzles - CP-010-00 Incl.: - Disc anode Ø90mm • Anode must be placed close to bow or stern nozzles. - Bolt M8 / nut / washers • Do not paint the Anode. - Cable assembly Remove the antifauling Drill and cut thread M8 Use Sikaflex to seal the bolt M8...
Page 90 • Verify no live battery cables or live + cables make contact to Stainless Steel parts at any time! Cable set to metal motor flange Cables are included with zinc anode P-156-00 CP-001-00 Zinc Anode Optional pump outlets JT-30 JT-50 € 62,- P-156-00 P-156-00 Pump outlet threaded € 47.- P-142-52...
Page 91 Pump outlet zinc anode JT70/JT90 Option 1 Cable set to water inlet and flange Cables are included with zinc anode € 175.- CP-002-00 Zinc anode JT70/JT90 Pump outlet € 56.- CP-006-00 Replacement Zinc anode JT70/ JT90 Water inlet zinc anode JT70/JT90 Cable set to water inlet and flange Cables are included with zinc anode Option 2...
Page 92 D-010-10C Holland Marine Parts...
Page 93 D-010-10C Holland Marine Parts...
Page 94 D-010-10C Holland Marine Parts...
Page 95 4. EU Declaration of Conformity (no.17K001) Jet Thruster controller Manufacturer Karyvo Adress Zeilmakersstraat 3a 8601 WT Sneek The Netherlands Declare under our sole responsibility that: Product: Multifunction Controller for Marine Applications type: Jet Thruster Controller Is in conformity with the relevant Union harmonization legislation:...
Page 96 D-010-10C Holland Marine Parts...
Page 97 D-010-10C Holland Marine Parts...
Page 98 D-010-10C Holland Marine Parts...
Page 99 D-010-10C Holland Marine Parts...
Page 100 Jet Thruster valve test rapport Testdate: HMP No: Jet Thruster test rapport Testdate: HMP No: Name : Signature: JT-30-50: JTV-30-50: ❏ ❏ JT-50-50: JTV-50-50: ❏ ❏ JT-70-50: JTV-70-50: ❏ ❏ JT-90-50: JTV-90-50: ❏ ❏ 300 / 11.8" 175 / 6,9"...
Page 101 Notes ......................
Page 102: Project Info
Project info Owner: ....................Adress: .
Page 103 GENERAL COMMERCIAL TERMS AND CONDITIONS General Commercial Terms and Conditions of Holland Marine Parts B.V. Donker Duyvisweg 297 3316 BL Dordrecht The Netherlands Applicability of the Present General Terms and Conditions 1. The present General Terms and Conditions shall apply to all offers and to all agreements concerning engines, machines and components. Unless the opposite appears explicitly, the present General Terms and Conditions shall equally apply to the assembly, disassembly, repair and other activities.
Page 104 IV Delivery and Delivery Period 1. Goods shall be delivered at our enterprise in Dordrecht (ex Works). Delivery periods shall be determined approximately. 2. The delivery period shall commence when we have conﬁrmed the order in writing, when all formalities required to start the activities have been complied with, when all necessary documents are in our possession and when the contracting party has provided us with all the data concerning the order.
Page 105 5. The contracting party shall have to forthwith inform us of shortcomings or defects to repairs or deliveries that have been discovered, at any rate not later than three working days from the day the shortcoming or defect was discovered, and to do all that is necessary to limit the damage, all this under penalty of the loss of any right to damages or warranty..
Page 106 6. If the contracting party is in default with the payment, it shall be deemed to be in default by operation of law and we shall have the right without any notice of default, to charge an interest on the entire amount due still outstanding, equalling the statutory commercial interest increased by 3% on an annual basis commencing on the date the payment concerned becomes due and payable, or, in the case of instal- ments, commencing on the day the term of the instalment concerned expires, and furthermore to recover all collection costs, both the judi- cial and extrajudical costs, from the contracting party, all this without prejudice to the other rights vested in us.
Page 107 D-010-10C Holland Marine Parts...
Page 108 D-010-10C Holland Marine Parts...
Page 109 D-010-10C Holland Marine Parts...
Page 110 D-010-10C Holland Marine Parts...
Page 111 D-010-10C Holland Marine Parts...
Page 112 D-010-10C Holland Marine Parts...
Page 113 D-010-10C Holland Marine Parts...
Page 114 D-010-10C Holland Marine Parts...
Page 115 D-010-10C Holland Marine Parts...
