Ruijie RG-WS7005-A(V2) Wireless Access
Controller
Hardware Installation and Reference Guide
Document Version: V1.3
Date: August 16, 2023
Copyright © 2023 Ruijie
Networks

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-WS7005-A(V2) and is the answer not in the manual?

Questions and answers

Related Manuals for Ruijie RG-WS7005-A(V2)

Summary of Contents for Ruijie RG-WS7005-A(V2)

  • Page 1 Ruijie RG-WS7005-A(V2) Wireless Access Controller Hardware Installation and Reference Guide Document Version: V1.3 Date: August 16, 2023 Copyright © 2023 Ruijie Networks...
  • Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.

  • Page 3: Preface

    Preface Intended Audience This document is intended for: Network engineers  Technical support and servicing engineers  Network administrators  Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/  Technical Support Website: https://ruijienetworks.com/support  Case Portal: https://caseportal.ruijienetworks.com  Community: https://community.ruijienetworks.com  Technical Support Email: service_rj@ruijienetworks.com...
  • Page 4 2. Signs The signs used in this document are described as follows: Warning An alert that calls attention to important rules and information that if not understood or followed can result in data loss or equipment damage. Caution An alert that calls attention to essential information that if not understood or followed can result in function failure or performance degradation.

  • Page 5: Table Of Contents

    Contents Preface ..............................I 1 Product Overview ..........................1 1.1 About the RG-WS7005-A(V2) ....................1 1.2 Hardware Features........................1 1.3 Package Contents ........................5 1.4 Technical Specifications ......................5 1.4.1 Dimensions and Weight....................5 1.4.2 Ports ..........................6 1.4.3 Power Supply and Consumption ................6 1.4.4 Environment and Reliability ..................
  • Page 6 1.7.2 Ventilation Requirements ..................12 1.7.3 Clearance Requirements ................... 12 1.7.4 Temperature and Humidity Requirements .............. 12 1.7.5 Cleanliness Requirements ..................13 1.7.6 Grounding Requirement ................... 14 1.7.7 ESD Protection Requirements ................... 15 1.7.8 Anti-interference Requirements ................15 1.7.9 Surge Protection Requirements ................16 1.7.10 Others ........................
  • Page 7 2.6 Verifying Installation ......................21 2.6.1 Checking the AC ......................21 2.6.2 Checking Cable Connections ..................21 2.6.3 Checking the Power Supply ..................21 3 Commissioning ..........................22 3.1 Setting Up the Configuration Environment ................. 22 3.1.1 Environment Preparations ..................22 3.1.2 Connecting an Ethernet Cable ..................
  • Page 8 5.2.1 Ethernet Port Is Not Working After the Ethernet Cable Is Plugged In ....27 5.2.2 LED Is Off for a Long Time ..................27 5.2.3 System LED Blinks Green for a Long Time ............... 27 5.2.4 Troubleshooting Power Failures ................28 5.2.5 Troubleshooting System Failures ................

  • Page 9: Product Overview

    The RG-WS7005-A(V2) supports 54 V DC power supply. With one Gigabit WAN port and four Gigabit LAN ports powered by PoE, it can uniformly manage Ruijie wireless access points (APs) and supply power for them. It simplifies wireless networking and supports the expansion of 4G LTE universal I/O modules.
  • Page 10 Hardware Installation and Reference Guide Product Overview Figure 1-2 Top View of the RG-WS7005-A(V2) Figure 1-3 Front Panel of the RG-WS7005-A(V2) Table 1-1 Buttons and Ports on the Front Panel Buttons and Description Ports Used to reboot the device or restore the device to factory Reset button settings PWR LED...
  • Page 11 Hardware Installation and Reference Guide Product Overview Buttons and Description Ports LAN1 status LED Used to indicate the working status of the LAN1 port LAN2 status LED Used to indicate the working status of the LAN2 port LAN3 status LED Used to indicate the working status of the LAN3 port LAN4 status LED Used to indicate the working status of the LAN4 port...
  • Page 12 Hardware Installation and Reference Guide Product Overview Buttons and Description Ports Uplink service port for data transmission, supporting IEEE LAN4 port 802.3af/at-compliant PoE DC power Used to connect with a DC power supply connector Figure 1-4 Rear Panel of the RG-WS7005-A(V2) Table 1-2 Description of the Rear Panel Buttons and...

  • Page 13: Package Contents

    Hardware Installation and Reference Guide Product Overview Package Contents Table 1-3 Package Contents Item Quantity Main unit Rubber pad DC power adapter M3 × 25 mm Phillips pan head screw Warranty Card and Hazardous Substance Table Hardware Installation and Reference Guide Technical Specifications 1.4.1 Dimensions and Weight...

  • Page 14: Ports

    Hardware Installation and Reference Guide Product Overview 1.4.2 Ports Table 1-5 Ports Ports RG-WS7005-A(V2) 1 x 10/100/1000Base-T auto-sensing Ethernet port Fixed service ports 4 x 10/100/1000Base-T auto-sensing Ethernet ports, supporting IEEE 802.3af/at-compliant PoE (PoE power consumption ≤ 56 W) 1 x RJ45 console port Fixed management ports 1 x USB port...

  • Page 15: Environment And Reliability

    Hardware Installation and Reference Guide Product Overview Power Supply and RG-WS7005-A(V2) Consumption supporting IEEE 802.3af-compliant PoE output to external PoE output devices 1.4.4 Environment and Reliability Table 1-7 Environment and Reliability Environment and RG-WS7005-A(V2) Reliability Operating temperature: –10°C to +40°C (14°F to 104°F) Storage temperature: –40°C to +70°C (–40°F to +158°F) Temperature Note: At a height between 3000 m (9842.52 ft.) and 5000 m...
  • Page 16 Hardware Installation and Reference Guide Product Overview LED Type LED Status Description green Solid green Initialization is complete. Solid PoE is enabled. orange PoE status LED PoE is disabled. No link is detected for this port. Solid green The port has made a successful 1000 Mbps link. Blinking The port is sending and receiving traffic at 1000 Mbps.
  • Page 17 Hardware Installation and Reference Guide Product Overview Table 1-9 Reset Button Button Action Description Press the button for shorter Restart the AC. than 3s. Reset button Press the button for more Restore the AC to factory settings. than 3s.

  • Page 18: Preparing For Installation

    Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Precautions Note To avoid personal injury and device damage, carefully read the safety precautions  before you install the AC. The following safety precautions may not cover all possible hazardous situations. ...

  • Page 19: Handling Safety

    Hardware Installation and Reference Guide Preparing for Installation 2.1.2 Handling Safety Avoid moving the device frequently.  Cut off all power supplies and unplug all power cords before handling the device.  2.1.3 Electric Safety Warning Improper or incorrect electric operations may cause a fire, electric shock, and other ...

  • Page 20: Installation Environment Requirements

    Hardware Installation and Reference Guide Preparing for Installation Installation Environment Requirements The AC must be installed and used indoors. For normal operation and prolonged service life of the AC, the installation site must meet the following requirements: 2.2.1 Bearing Requirements Evaluate the weight of the device and its accessories (such as the power supply module), and ensure that the installation site can bear the weight.

  • Page 21: Cleanliness Requirements

    Hardware Installation and Reference Guide Preparing for Installation Note The ambient temperature and humidity of the device are measured at the point that is 1.5 m (4.92 ft.) above the floor and 0.4 m (1.31 ft.) before the device when there is no protective plate in front or at the back of the device.

  • Page 22: Grounding Requirement

    Hardware Installation and Reference Guide Preparing for Installation Table 2-2 Requirements for Gases Average (mg/m Maximum (mg/m Sulfur dioxide (SO Hydrogen sulfide (H 0.006 0.03 Nitrogen dioxide (NO 0.04 0.15 Ammonia gas (NH 0.05 0.15 Chlorine gas (CI 0.01 Note Average refers to the average value of harmful gases measured in one week.

  • Page 23: Esd Protection Requirements

    Hardware Installation and Reference Guide Preparing for Installation The lightning protection system of facilities is standalone, and is composed of a lightning rod, a down conductor, and a connector connected to the grounding system. The grounding system is usually used for power reference grounding and safety grounding of the rack.

  • Page 24: Surge Protection Requirements

    Hardware Installation and Reference Guide Preparing for Installation radio transmitting station and radar launcher. Take electromagnetic shielding measures when necessary.  2.2.9 Surge Protection Requirements The device can guard against lightning strikes. As an electric device, too strong lightning strikes may still damage the device. Take the following surge protection measures: Ensure that the ground cable of the cabinet is in good contact with the ground.

  • Page 25: Installing The Device

    Hardware Installation and Reference Guide Installing the Device Note The RG-WS7005-A(V2) is not shipped with a tool kit. You need to prepare a tool kit by yourself. Installing the Device Install the RG-WS7005-A(V2) indoors. Caution Before installing the device, make sure that you have carefully read the requirements described in Chapter 2.

  • Page 26: Checking Before Installation

    Hardware Installation and Reference Guide Installing the Device Figure 3-1 Installation Procedure Start Prepare for installation. Read precautions. Install the device. Install other modules. Connect cables. Bundle cables. Verify installation. Checking Before Installation Carefully plan and arrange the installation location, networking, power supply, and cabling before installing the device.

  • Page 27: Precautions

    Hardware Installation and Reference Guide Installing the Device Precautions To ensure the normal operation and prolonged service life of the AC, observe the following safety precautions: Do not power on the device during installation.  Place the device in a well-ventilated environment. ...

  • Page 28: Installing A Power Module

    Hardware Installation and Reference Guide Installing the Device 3.4.2 Installing a Power Module RG-WS7005-A(V2) adopts the 54 V DC/1.48 A power supply. Please use the standard power adapter. Please install the power supply according to the following steps: (1) Plug one end of the power adapter that comes with the device into the DC power connector on the front panel of the device, and plug the other end into the AC power socket.

  • Page 29: Verifying Installation

    Hardware Installation and Reference Guide Installing the Device (2) Fasten the twisted pair cables to the cable management trough of the mounting bracket. (3) Extend the twisted pair cables under the device and route them in a straight line. Verifying Installation 3.6.1 Checking the AC If the device is installed in the cabinet, verify that the installation angle iron of the...

  • Page 30: Commissioning

    Hardware Installation and Reference Guide Commissioning Commissioning Setting Up the Configuration Environment 4.1.1 Environment Preparations Connect the device to the DC power supply. When setting up the environment, pay attention to the following points: When the AC is powered by DC power supply, ensure that the power cord is properly ...

  • Page 31: Setting Terminal Parameters

    Hardware Installation and Reference Guide Commissioning (3) Connect the RJ-45 connector of the network cable to the console port of the RG-WS7005-A (V2). 4.1.3 Setting Terminal Parameters When the RG-WS7005-A(V2) is used for the first time, configure the device through the console port.
  • Page 32 Hardware Installation and Reference Guide Commissioning Figure 4-3 Selecting the Serial Port (4) Click OK. The COM1 Properties dialog box will appear. Select the following settings: Bits per second: 9600 (115200 during startup process; 9600 in main program); Data bits: 8; Parity check: None; Stop bit: 1; Flow control: None. Figure 4-4 Configuring the Communication Parameters of the Serial Port...

  • Page 33: Powering On The Device

    Hardware Installation and Reference Guide Commissioning (5) Click OK and the HyperTerminal window will appear. Powering on the Device 4.2.1 Checklist Before Power-On The power cord is properly connected, and the power supply device meets the  requirements. The input voltage follows the requirement, and the cables are properly connected. ...

  • Page 34: Monitoring And Maintenance

     The device supports remote maintenance.  Remote Maintenance You can run related commands on the CLI of the device or log in to Eweb page for maintenance. Hardware Maintenance If the hardware is faulty, please contact Ruijie technical support.

  • Page 35: Faqs

    Hardware Installation and Reference Guide FAQs FAQs Troubleshooting Flowchart Common Faults 6.2.1 Ethernet Port Is Not Working After the Ethernet Cable Is Plugged In Check whether the peer device of the Ethernet cable is working properly. Check whether the Ethernet cable is capable of providing the required data rate and is properly connected.

  • Page 36: Troubleshooting Power Failures

    Hardware Installation and Reference Guide FAQs Caution If the LED keeps blinking for an hour, the device initialization fails and the device is faulty. 6.2.4 Troubleshooting Power Failures The PWR LED on the front panel indicates whether the device power system is malfunctioning.
  • Page 37 Hardware Installation and Reference Guide FAQs Terminal emulation: VT100  Notes If console port parameters of the device have been modified, information may be not displayed on the terminal.

  • Page 38: Appendix

    Hardware Installation and Reference Guide Appendix Appendix Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T Port  The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps auto-negotiation port that supports auto MDI/MDIX Crossover. Compliant with IEEE 802.3ab, the 1000BASE-T port requires 100-ohm Category 5/5e UTP or STP with a maximum distance of 100 meters (328.08 ft.). The 1000BASE-T port requires all four pairs of wires to be connected for data transmission.
  • Page 39 Hardware Installation and Reference Guide Appendix Figure 7-2 100BASE-TX/10BASE-T Pin Assignments Connector Plug Input Receive Data+ Output Transmit Data+ Input Receive Data– Output Transmit Data– Output Transmit Data+ Input Receive Data+ Output Transmit Data– Input Receive Data– 4, 5, 7, 8 Not Used Not Used The following figure shows feasible connections of the straight-through and crossover...

  • Page 40: Cabling

    Hardware Installation and Reference Guide Appendix Cabling During installation, route cable bundles upward or downward along the sides of the rack depending on the actual situation in the equipment room. All cable connectors used for transit should be placed at the bottom of the cabinet rather than be exposed outside of the cabinet.
  • Page 41 Hardware Installation and Reference Guide Appendix Cables of different types (such as power cords, signal cables, and ground cables) ○ should be separated in cabling and bundling. Mixed bundling is disallowed. When they are close to each other, you are advised to adopt crossover cabling. In the case of parallel cabling, maintain a minimum distance of 30 mm (1.18 in.) between power cords and signal cables.
  • Page 42 Hardware Installation and Reference Guide Appendix Figure 7-6 Binding Cables Cables not to be assembled or remaining parts of cables should be folded and ○ placed in a proper position of the rack or cable trough. The proper position refers to a position that does not affect device running or damage the switch or cable.
  • Page 43 Hardware Installation and Reference Guide Appendix ① Flat washer ③ Spring washer ② Nut ④ Flat washer Hard power cords should be fastened in the terminal connection area to prevent ○ stress on terminal connection and cable. Do not use self-tapping screws to fasten terminals. ○...

  • Page 44: Power Supply Specifications

    Hardware Installation and Reference Guide Appendix Power Supply Specifications Input voltage: 54 V DC; rated current: 1.48 A  Table 7-1 DC Connector Specifications Inner Diameter Outer Depth Polarity Diameter 2.1 mm (0.0827 5.5 mm (0.217 10 mm (0.394 in.) Center positive in.) in.)
