- Page 1 Ruijie RG-SC6705-SP Wireless Access Controller Hardware Installation and Reference Guide Document Version: V1.1 Date: August 16, 2023 Copyright © 2023 Ruijie Networks...
- Page 2 Due to product version upgrades or other reasons, the content of this document will be updated from time to time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.
-
Page 3: Preface
Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support Case Portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com Technical Support Email: service_rj@ruijienetworks.com... - Page 4 Double slashes at the beginning of a line of code indicate a comment line. 2. Signs The signs used in this document are described as follows: Warning An alert that calls attention to important rules and information that if not understood or followed can result in data loss or equipment damage.
-
Page 5: Table Of Contents
Contents Preface ..............................I 1 Product Overview ..........................1 1.1 About the RG-SC6705-SP ......................1 1.2 Hardware Features........................1 1.3 Package Contents ........................4 1.4 Technical Specifications ......................5 1.4.1 Dimensions and Weight....................5 1.4.2 Ports ..........................5 1.4.3 Power Supply and Consumption ................6 1.4.4 Environment and Reliability .................. - Page 6 2.2.2 Ventilation Requirements ..................11 2.2.3 Clearance Requirements ................... 11 2.2.4 Temperature and Humidity Requirements .............. 11 2.2.5 Cleanliness Requirements ..................12 2.2.6 Grounding Requirement ................... 13 2.2.7 ESD Protection Requirements ................... 14 2.2.8 Anti-interference Requirements ................14 2.2.9 Surge Protection Requirements ................15 2.2.10 Others ........................
- Page 7 3.6 Verifying Installation ......................20 3.6.1 Checking the AC ......................20 3.6.2 Checking Cable Connections ..................20 3.6.3 Checking the Power Supply ..................20 4 Commissioning ..........................21 4.1 Setting Up the Configuration Environment ................. 21 4.1.1 Environment Preparations ..................21 4.1.2 Connecting an Ethernet Cable ..................
- Page 8 6.2.1 Ethernet Port Is Not Working After the Ethernet Cable Is Plugged In ....26 6.2.2 LED Is Off for a Long Time ..................26 6.2.3 System LED Blinks Green for a Long Time ............... 26 6.2.4 Troubleshooting Power Failures ................27 6.2.5 Troubleshooting System Failures ................
-
Page 9: Product Overview
It can manage up to 64 APs. Hardware Features The front panel of the RG-SC6705-SP accommodates 5 x GE ports, 1 x USB 2.0 port, 1 x console port, 1 x button, and 1 x DC power connector. The rear panel provides one 4G module slot. - Page 10 Hardware Installation and Reference Guide Product Overview Figure 1-3 Front Panel of the RG-SC6705-SP 9 10 11 12 Table 1-1 Buttons and Ports on the Front Panel Buttons and Description Ports Used to reboot the device or restore the device to factory...
- Page 11 Uplink service port for data transmission, supporting IEEE LAN3 port 802.3af/at-compliant PoE Uplink service port for data transmission, supporting IEEE LAN4 port 802.3af/at-compliant PoE DC power Used to connect with a DC power supply connector Figure 1-4 Rear Panel of the RG-SC6705-SP...
-
Page 12: Package Contents
Hardware Installation and Reference Guide Product Overview Table 1-2 Description of the Rear Panel Buttons and Description Ports Grounding Used to connect with the ground cable screw Filler panel Filler panel for 4G module Note The product nameplate is located at the bottom of the device. Package Contents Table 1-3 Package Contents... -
Page 13: Technical Specifications
Technical Specifications 1.4.1 Dimensions and Weight Table 1-4 Dimensions and Weight Dimensions and RG-SC6705-SP Weight Dimensions (W x D x 200 mm × 110 mm × 25 mm (7.87 in. x 4.33 in. x 0.98 in.). Rack height 1 RU Weight 1.1 kg (2.43 lbs) -
Page 14: Power Supply And Consumption
Hardware Installation and Reference Guide Product Overview Ports RG-SC6705-SP Module slot 1 x 4G module slot 1.4.3 Power Supply and Consumption Table 1-6 Power Supply and Consumption Power Supply and RG-SC6705-SP Consumption Max. power 64.2 W consumption Power module Not supported... -
Page 15: Led And Button
Hardware Installation and Reference Guide Product Overview Environment and RG-SC6705-SP Reliability Operating humidity: 5% RH to 95% RH (non-condensing) Humidity Storage humidity: 5% RH to 95% RH (non-condensing) Regulatory EN 55032, EN 55035, EN 61000-3-3, EN IEC 61000-3-2, ETSI EN 300... - Page 16 Hardware Installation and Reference Guide Product Overview LED Type LED Status Description orange Blinking The port is sending or receiving data at 10/100 Mbps. orange No link is detected for this port. Solid green The port has made a successful 1000 Mbps link. Blinking The port is sending and receiving traffic at 1000 Mbps.
-
Page 17: Preparing For Installation
Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Precautions Note To avoid personal injury and device damage, carefully read the safety precautions before you install the AC. The following safety precautions may not cover all possible hazardous situations. ... -
Page 18: Handling Safety
Hardware Installation and Reference Guide Preparing for Installation 2.1.2 Handling Safety Avoid moving the device frequently. Cut off all power supplies and unplug all power cords before handling the device. 2.1.3 Electric Safety Warning Improper or incorrect electric operations may cause a fire, electric shock, and other ... -
Page 19: Installation Environment Requirements
Hardware Installation and Reference Guide Preparing for Installation Installation Environment Requirements The AC must be installed and used indoors. For normal operation and prolonged service life of the AC, the installation site must meet the following requirements: 2.2.1 Bearing Requirements Evaluate the weight of the device and its accessories (such as the power supply module), and ensure that the installation site can bear the weight. -
Page 20: Cleanliness Requirements
Hardware Installation and Reference Guide Preparing for Installation Note The ambient temperature and humidity of the device are measured at the point that is 1.5 m (4.92 ft.) above the floor and 0.4 m (1.31 ft.) before the device when there is no protective plate in front or at the back of the device. -
Page 21: Grounding Requirement
Hardware Installation and Reference Guide Preparing for Installation Table 2-2 Requirements for Gases Average (mg/m Maximum (mg/m Sulfur dioxide (SO Hydrogen sulfide (H 0.006 0.03 Nitrogen dioxide (NO 0.04 0.15 Ammonia gas (NH 0.05 0.15 Chlorine gas (CI 0.01 Note Average refers to the average value of harmful gases measured in one week. -
Page 22: Esd Protection Requirements
2.2.7 ESD Protection Requirements The RG-SC6705-SP has been designed with rigorous anti-static procedures during circuit design. However, excessive static electricity can still cause damage to its circuit board. Static electricity in the communication network connected to the AC mainly originates from two sources: Outdoor high-voltage transmission lines, lightning, and other external electric fields;... -
Page 23: Surge Protection Requirements
Hardware Installation and Reference Guide Preparing for Installation radio transmitting station and radar launcher. Take electromagnetic shielding measures when necessary. 2.2.9 Surge Protection Requirements The device can guard against lightning strikes. As an electric device, too strong lightning strikes may still damage the device. Take the following surge protection measures: Ensure that the ground cable of the cabinet is in good contact with the ground. -
Page 24: Installing The Device
Hardware Installation and Reference Guide Installing the Device Note The RG-SC6705-SP is not shipped with a tool kit. You need to prepare a tool kit by yourself. Installing the Device Install the RG-SC6705-SP indoors. Caution Before installing the device, make sure that you have carefully read the requirements described in Chapter 2. -
Page 25: Checking Before Installation
Hardware Installation and Reference Guide Installing the Device Figure 3-1 Installation Procedure Start Prepare for installation. Read precautions. Install the device. Install other modules. Connect cables. Bundle cables. Verify installation. Checking Before Installation Carefully plan and arrange the installation location, networking, power supply, and cabling before installing the device. -
Page 26: Precautions
Hardware Installation and Reference Guide Installing the Device Precautions To ensure the normal operation and prolonged service life of the AC, observe the following safety precautions: Do not power on the device during installation. Place the device in a well-ventilated environment. ... -
Page 27: Installing A Power Module
3.4.2 Installing a Power Module RG-SC6705-SP adopts the 54 V DC/1.48 A power supply. Please use the standard power adapter. Please install the power supply according to the following steps: (1) Plug one end of the power adapter that comes with the device into the DC power connector on the front panel of the device, and plug the other end into the AC power socket. -
Page 28: Verifying Installation
Hardware Installation and Reference Guide Installing the Device (2) Fasten the twisted pair cables to the cable management trough of the mounting bracket. (3) Extend the twisted pair cables under the device and route them in a straight line. Verifying Installation 3.6.1 Checking the AC If the device is installed in the cabinet, verify that the installation angle iron of the... -
Page 29: Commissioning
Hardware Installation and Reference Guide Commissioning Commissioning Setting Up the Configuration Environment 4.1.1 Environment Preparations Connect the device to the DC power supply. When setting up the environment, pay attention to the following points: When the AC is powered by DC power supply, ensure that the power cord is properly ... -
Page 30: Setting Terminal Parameters
4.1.3 Setting Terminal Parameters When the RG-SC6705-SP is used for the first time, configure the device through the console port. If you configure the AC using a PC, run a terminal emulation program such as HyperTerminal provided by the Windows operating system. HyperTerminal is used as an example to illustrate the procedure: (1) Navigate to Start >... - Page 31 Hardware Installation and Reference Guide Commissioning Figure 4-3 Selecting the Serial Port (4) Click OK. The COM1 Properties dialog box will appear. Select the following settings: Bits per second: 9600 (115200 during startup process; 9600 in main program); Data bits: 8; Parity check: None; Stop bit: 1; Flow control: None. Figure 4-4 Configuring the Communication Parameters of the Serial Port...
-
Page 32: Powering On The Device
Hardware Installation and Reference Guide Commissioning (5) Click OK and the HyperTerminal window will appear. Powering on the Device 4.2.1 Checklist Before Power-On The power cord is properly connected, and the power supply device meets the requirements. The input voltage follows the requirement, and the cables are properly connected. ... -
Page 33: Monitoring And Maintenance
The device supports remote maintenance. Remote Maintenance You can run related commands on the CLI of the device or log in to Eweb page for maintenance. Hardware Maintenance If the hardware is faulty, please contact Ruijie technical support. -
Page 34: Faqs
Hardware Installation and Reference Guide FAQs FAQs Troubleshooting Flowchart Common Faults 6.2.1 Ethernet Port Is Not Working After the Ethernet Cable Is Plugged In Check whether the peer device of the Ethernet cable is working properly. Check whether the Ethernet cable is capable of providing the required data rate and is properly connected. -
Page 35: Troubleshooting Power Failures
Hardware Installation and Reference Guide FAQs Caution If the LED keeps blinking for an hour, the device initialization fails and the device is faulty. 6.2.4 Troubleshooting Power Failures The PWR LED on the front panel indicates whether the device power system is malfunctioning. - Page 36 Hardware Installation and Reference Guide FAQs Terminal emulation: VT100 Notes If console port parameters of the device have been modified, information may be not displayed on the terminal.
-
Page 37: Appendix
Hardware Installation and Reference Guide Appendix Appendix Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T Port The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps auto-negotiation port that supports auto MDI/MDIX Crossover. Compliant with IEEE 802.3ab, the 1000BASE-T port requires 100-ohm Category 5/5e UTP or STP with a maximum distance of 100 meters (328.08 ft.). The 1000BASE-T port requires all four pairs of wires to be connected for data transmission. - Page 38 Hardware Installation and Reference Guide Appendix Figure 7-2 100BASE-TX/10BASE-T Pin Assignments Connector Plug Input Receive Data+ Output Transmit Data+ Input Receive Data– Output Transmit Data– Output Transmit Data+ Input Receive Data+ Output Transmit Data– Input Receive Data– 4, 5, 7, 8 Not Used Not Used The following figure shows feasible connections of the straight-through and crossover...
-
Page 39: Cabling
Hardware Installation and Reference Guide Appendix Cabling During installation, route cable bundles upward or downward along the sides of the rack depending on the actual situation in the equipment room. All cable connectors used for transit should be placed at the bottom of the cabinet rather than be exposed outside of the cabinet. - Page 40 Hardware Installation and Reference Guide Appendix Cables of different types (such as power cords, signal cables, and ground cables) ○ should be separated in cabling and bundling. Mixed bundling is disallowed. When they are close to each other, you are advised to adopt crossover cabling. In the case of parallel cabling, maintain a minimum distance of 30 mm (1.18 in.) between power cords and signal cables.
- Page 41 Hardware Installation and Reference Guide Appendix Figure 7-6 Binding Cables Cables not to be assembled or remaining parts of cables should be folded and ○ placed in a proper position of the rack or cable trough. The proper position refers to a position that does not affect device running or damage the switch or cable.
- Page 42 Hardware Installation and Reference Guide Appendix ① Flat washer ③ Spring washer ② Nut ④ Flat washer Hard power cords should be fastened in the terminal connection area to prevent ○ stress on terminal connection and cable. Do not use self-tapping screws to fasten terminals. ○...
-
Page 43: Power Supply Specifications
Hardware Installation and Reference Guide Appendix Power Supply Specifications Input voltage: 54 V DC; rated current: 1.48 A Table 7-1 DC Connector Specifications Inner Diameter Outer Depth Polarity Diameter 2.1 mm (0.0827 5.5 mm (0.217 10 mm (0.394 in.) Center positive in.) in.)
