ATD AIR ATD-2030 Manual

ATD-2030_man100203 10/2/03
• MAXIMUM RPM OF 20,000
• MAX AIR PRESSURE: 90 PSIG, 6.2 BAR
• RPM OF THE ACCESSORY MUST EXCEED
TOOL RPM
S P E C I F I C A T I O N S
Free Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20,000 RPM
Collet Size (In.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4"
Air Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4"-18NPT
Hose Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8" ID
Air Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90 PSI
Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 CFM
Sound Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86 dBA
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.5"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0 Lbs.
ATD2030
11:28 AM Page 1
THIS INSTRUCTION MANUAL
CONTAINS IMPORTANT
SAFETY INFORMATION
READ CAREFULLY AND
UNDERSTAND ALL
INFORMATION BEFORE
OPERATING THIS TOOL!
SAVE THIS MANUAL
FOR FUTURE REFERENCE.
ATD-2030
MINI RIGHT ANGLE DIE
GRINDER – FRONT EXHAUST
Some dust created by power
ALWAYS READ
sanding, sawing, grinding, drilling,
INSTRUCTIONS
and other construction activities
BEFORE USING
contains chemicals known to cause
POWER TOOLS
cancer, birth defects or other
reproductive harm. Some examples
of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks
• arsenic and chromium from
Your risk from these exposures
varies, depending on how often
you do this type of work. To reduce
your exposure to these chemicals:
work in a well ventilated area,
and work with approved safety
equipment, such as those dust
masks that are specially designed
to filter out microscopic particles.
- 1 -
and cement and other masonry
products, and
chemically-treated lumber.
Rev. 10/02/03
