Matsushita Electric PANASONIC RS-260US Service Manual

Service Manual cues
COMPACT, FULLY EQUIPPED
STEREO CASSETTE TAPE DECK
RS-260US MECHANISM SERIES
move. RS-260US move. RS-260USE
SPECIFICATIONS
Power Source: AC: 90~109, 110~125, 200~219, Frequency Response: NORMAL 40~11,000 Hz
220~250 volts, 50/60 Hz CrOz 40~13,000 Hz
Power Consumption: 6W Signal-To-Noise Ratio: Better than 43 dB
Motor : Electronic speed control DC motor inputs: 2-MIC —~71 dB (0.3 mV)/10KQ
Transistors : 28C1327 (2) 2SC644 (2) 2-LINE —29 dB (30 mV)/100 Ka
Recording System: AC bias Connector: DIN connection
Erase System: AC erase Dimensions: 11-1/4" (W) x 3-1/8" (H) x8"(D)
Tape Speed: 1-7/8 ips. (4.8 cm/s) 285 mm(W) x 80 mm(H) x 203 mm(0)
Tape: Compact cassette tape Weight: Approx. 6-1/8 Ibs. (2.8 kg)
Fast Forward and ;
Rewind Time: Approx. 90 seconds with C-60
cassette tape
These specifications are subject to change in order to accommodate improvements in design.
MATSUSHITA ELECTRICRS
MATSUSHITA ELECTRIC TRADING CO., LTD. gy
P. O. Box 288 Central, Osaka, Japan
ORDER NO. ARD-7303031
