PRODUCT SPECIFICATION
802.11a/b/g/n 2T2R Wireless LAN USB Module
WN4508R(LA)
RT5572
Version 1.0
User Manual
* This document contains confidential proprietary information and is property of LTC. The contents of
this document should not be disclosed to unauthorized persons without the written consent of LTC
Page 1/13
Advertisement
Table of Contents
Related Manuals for LiteOn WN4508R
Summary of Contents for LiteOn WN4508R
- Page 1 PRODUCT SPECIFICATION 802.11a/b/g/n 2T2R Wireless LAN USB Module WN4508R(LA) RT5572 Version 1.0 User Manual * This document contains confidential proprietary information and is property of LTC. The contents of this document should not be disclosed to unauthorized persons without the written consent of LTC...
- Page 2 PRODUCT SPECIFICATION 802.11a/b/g/n 2T2R Wireless LAN USB Module WN4508R(LA) RT5572 Version 1.0 Networking B.U. Lite-on Technology Corporation 4F, No. 90, Chien I Rd., Chung Ho, New Taipei City 235, Taiwan, R.O.C. Phone: +886-2-2222-6181 Fax: +886-2-2221-5288 Contact: Product Marketing Mr. ML Wu #8266 E-mail: ml.wu@liteon.com...
-
Page 3: Table Of Contents
ONTENT FCC WARING STATEMENT ......................4 PRODUCT FEATURES ........................5 PRODUCT SPECIFICATIONS ......................6 ............................6 HIPSET ....................... 6 UNCTIONAL PECIFICATIONS PIN ASSIGMENT ..........................8 USB CONNECTOR SPEC ......................... 8 MECHANICAL ..........................9 BLOCK DIAGRAM ........................... 9 ANTENNA SPEC ..........................10 EEPROM INFORMATION ...................... -
Page 4: Fcc Waring Statement
FCC W ARING TATEMENT FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Product Features
20cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: "Contains FCC ID: PPQ-WN4508R ” Information for the OEMs and Integrators The following statement must be included with all versions of this document supplied to an OEM or integrator, but should not be distributed to the end user. -
Page 6: Product Specifications
RODUCT PECIFICATIONS HIPSET MAC/ Baseband/ RF: Ralink RT5572 UNCTIONAL PECIFICATIONS Wi-Fi Function IEEE802.11a;IEEE802.11b; IEEE 802.11g; IEEE 802.11n Standard Bus Interface USB2.0 802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps 802.11b: 11, 5.5, 2, 1 Mbps Data Rate 802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps 802.11n: MCS 0 to 15 for HT20MHz... - Page 7 14 dBm@54Mbps 802.11n: 2.4G 20MHz: 13 dBm@MCS0 13 dBm@MCS7 13 dBm@MCS15 40MHz: 13 dBm@MCS0 13 dBm@MCS7 13 dBm@MCS15 20MHz: 12 dBm@MCS0 11 dBm@MCS7 11 dBm@MCS15 40MHz: 11 dBm@MCS0 11 dBm@MCS7 11 dBm@MCS15 802.11a: -86 dBm@6Mbps -70 dBm@54Mbps 802.11b: -88 dBm@1Mbps -82 dBm@11Mbps 802.11g: -86 dBm@6Mbps...
-
Page 8: Pin Assigment
SSIGMENT Pin. Pin Define Status +3.3V USB_D- USB_D+ RESET# USB C SPEC ONNECTOR Page 8/13... -
Page 9: Mechanical
ECHANICAL LOCK IAGRAM Page 9/13... -
Page 10: Antenna Spec
SPEC NTENNA Page 10/13... -
Page 11: Eeprom Information
EEPROM I NFORMATION World Wide 2.4G/5G Read from registry; Control by driver Reg Domain Offset 0x38 for 5G: 0xFF Offset 0x39 for 2.4G: 0xFF 0x0471 Vendor ID Product ID 0x2126 NVIRONMENTAL Operating Operating Temperature: 0 to 70 C (32 to 158 F) Relative Humidity: 5-90% (non-condensing) Storage Temperature: -20 to 70 C (-4 to 158 F) -
Page 12: Packing Drawing
ACKING RAWING Tray Page 12/13... - Page 13 Page 13/13...
