Read this manual carefully before using the product.
Wrong operations deviating from this manual may lead to serious accidents or damages.
Keep this manual convenient location for easy access.
Headquarters:
751, Nishi Hassaku-cho, Midori-ku, Yokohama, Kanagawa, Japan 226-0024
Osaka Branch: 4-14, Toyosaki 3, Kita-ku, Osaka City, Osaka , Japan 531-0072
Chino Plant:
11400-1107, Aza Harayama, Tamagawa, Chino City, Nagano, Japan 391-0011
web: http://www.mutodenki.co.jp
Muto Turbo Blower
KFL
Instruction Manual
Muto Denki Corporation
TEL: 81-45-932-2211,
TEL: 81-6-6372-1100,
TEL: 81-266-79-6071,
Series
FAX: 81-45-932-2219
FAX: 81-6-6372-1797
FAX: 81-266-79-6074
e-mail: sales@mutodeki.co.jp
TMB-061E
Rev.1
Nov. 2023
Advertisement
Table of Contents
Related Manuals for Muto Denki KFL Series
Summary of Contents for Muto Denki KFL Series
- Page 1 Read this manual carefully before using the product. Wrong operations deviating from this manual may lead to serious accidents or damages. Keep this manual convenient location for easy access. Muto Denki Corporation Headquarters: 751, Nishi Hassaku-cho, Midori-ku, Yokohama, Kanagawa, Japan 226-0024...
-
Page 2: Table Of Contents
Table of contents 1. Introduction ·········································································· 3 2. Safety precautions ································································· 3 3. Receiving Checkups ····························································· 5 4. Transportation and Handling ···················································· 5 5. Storage ··············································································· 5 6. Installation ············································································ 5 7. Piping ·················································································· 6 8. Connection to Power and Test run ············································ 6 9. -
Page 3: Introduction
1. Introduction Thank you for purchasing the Muto Turbo Blower KFL Series. This manual contains the information you need for handling, installing, operating and maintaining your new equipment correctly, to ensure trouble-free operation and long service life. Please read it thoroughly. - Page 4 ⚫ Do not insert finger(s) or hand(s) into the rotation check hole cover etc. Do not remove the safety cover during the product is running. Otherwise injuries may occur. ⚫ Shut off the main power switch in case of power failure. Otherwise injuries may occur. ( Disassembly and Reassembly ) ⚫...
-
Page 5: Receiving Checkups
3. Receiving Checkups Check if the products you have received are what have been ordered by referring to the order sheet, drawings, invoices, etc. (1) Check the nameplates on the blower and the motor, and confirm if it matches what have been ordered. -
Page 6: Piping
7. Piping Use the sleeve joint to connect the outlet of the blower with a pipe to avoid unnecessary force to the blower and to isolate the vibration from the blower. If direct connection to the pipe is inevitable, do not give the force to the blower by dimensional tolerances, weight of piping, thermal expansion of piping, etc. -
Page 7: Precautions For Operation
Fig.4 Damper (2) KFL Series has the minimum volume. Do not run the blower below the minimum volume. Because the motor may break down so that it is not cool enough. Each of the minimum volumes is shown on Table 1. -
Page 8: Maintenance
10. Maintenance The following maintenance is recommended to keep the blower in good condition. (1) Pay attention to ventilation to keep the ambient temperature in the range of -15 to 40 deg. C. (2) Pay attention to abnormal noise, abnormal vibration, abnormal temperature and air leakage. If abnormality is found, take actions referring to “11. -
Page 9: Troubleshooting
11. Troubleshooting The following table is for troubleshooting during test run and operation. Trouble Cause What to do Abnormal voltage or frequency Consult with power company. Inappropriate capacity of power Replace with appropriate one. source equipment Missing phase Check wiring. Imbalanced voltage of phase Consult with power company. -
Page 10: Structural Drawing
12. Structural drawing Description Qty. Casing End head Motor Cover Rotation check hole cover Air filter 2 (two sheets of filter each) Pull box Terminal block Damper Sleeve joint Rubber vibration isolator... -
Page 11: Motor
13. Motor Regarding motor, refer to the instruction manual of the motor. 14. Inquiry If you need to contact us regarding this product, please kindly inform us the information on the nameplate such as CAT. No. , PROD. No. , DATE. In case of troubles, inform us the broken portion, running time (days) and condition used and others additionally. - Page 12 Muto Products ⚫ Muto Wide Blower ⚫ Muto Turbo Blower ⚫ Muto Spencer Blower (Under technical license) ⚫ Muto KF Blower ⚫ Muto Scroll Blower ⚫ Muto Central Vacuum System...
