Muto Turbo Blower
MS Series
Instruction Manual
Muto Denki Corporation
TEL: 81-45-932-2211,
TEL: 81-6-6372-1100,
TEL: 81-266-79-6071,
FAX: 81-45-932-2219
FAX: 81-6-6372-1797
FAX: 81-266-79-6074
e-mail: sales@mutodeki.co.jp
TMB-062E-03
Rev.1
Jan. 2020
Advertisement
Table of Contents
Related Manuals for Muto Denki MS Series
Summary of Contents for Muto Denki MS Series
- Page 1 TMB-062E-03 Rev.1 Jan. 2020 Muto Turbo Blower MS Series Instruction Manual Read this manual carefully before using the product. Wrong operations deviating from this manual may lead to serious accidents or damages. Keep this manual convenient location for easy access.
-
Page 2: Table Of Contents
Table of contents 1. Introduction ·········································································· 3 2. Safety precautions ································································· 3 3. Receiving Checkups ····························································· 5 4. Transportation and Handling ···················································· 5 5. Storage ··············································································· 5 6. Installation ············································································ 5 7. Piping ·················································································· 5 8. Connection to Power and Test run ············································ 6 9. -
Page 3: Introduction
1. Introduction Thank you for purchasing the Muto Turbo Blower. This manual contains the information you need for handling, installing, operating and maintaining your new equipment correctly, to ensure trouble-free operation and long service life. Please read it thoroughly. After reading this manual, keep it in convenient place for easy access. For heat resistant model, its name contains “H”. - Page 4 Inlet : Clothing which you are wearing or a part of your body will be sucked in. As a result, injuries may occur. Outlet : A strong wind or flown things may cause injuries. ⚫ Do not insert finger(s) or hand(s) into the opening of the safety covers such as external fan cover and cooling fan cover.
-
Page 5: Receiving Checkups
3. Receiving Checkups Check if the products you have received are what have been ordered by referring to the order sheet, drawings, invoices, etc. (1) Check the nameplates on the blower and the motor, and confirm if it matches what have been ordered. -
Page 6: Connection To Power And Test Run
8. Connection to Power and Test run (1) Check the nameplates of blower and motor and confirm if they agree with the specification for power supply, then connect to power line under instruction by electrical engineer and per electric technical standards and wiring regulation. (2) Jog the blower and check the rotational direction is the same as the mark. -
Page 7: Troubleshooting
11. Troubleshooting The following table is for trouble shooting during test run and operation. Trouble Cause What to do Abnormal voltage or frequency Consult with power company. Inappropriate capacity of power Replace with appropriate one. source equipment Missing phase Check wiring. Imbalanced voltage of phase Consult with power company. -
Page 8: Instruction For Disassembly And Reassembly
12. Instruction for Disassembly and Reassembly Turn the power off before disassembly and reassembly. Following is instructive to disassemble and/or to reassemble the blower as referring to “13. Structural drawing”. (It is very difficult to explain all of details of the work perfectly in writing and by sketches. Therefore it is recommended to understand how the parts put together before disassembling and record the direction and order of the parts while disassembling.) 12-1. -
Page 9: Structural Drawing
13. Structural drawings Qty. MSF-8T MSD-3T MSH-10T MSH-8T Description MSD-4T MSF-12R MSD-3ST MSF-8P MSF-6T MSH-14R MSD-4ST MSD-8R MSD-6P MSH-14R5 MSH-10P Fan case fastening bolt 7 (MSD) , 8 (MSF) , 10 (MSH) Fan case (A) Fan case (C) Fan stopper bolt Fan stopper collar Motor Base... -
Page 10: Motor
14. Motor Regarding motor, refer to the instruction manual of the motor. 15. Inquiry If you need to contact us regarding this product, please kindly inform us the information on the nameplate such as CAT. No. , PROD. No. , DATE. In case of troubles, additionally inform us the broken portion, running time (days) and condition used and others. - Page 11 － ＭＥＭＯ －...
