Taiwan Main Orthopaedic
Biotechnology Co., Ltd.
Copyright © 2023, Taiwan Main Orthopaedic
Biotechnology, Co,. Ltd. All Rights Reserved.
Abc
Human Anatomy
Copyright © 2018, Taiwan Main Orthopaedic Biotechnology, Co,. Ltd. All Rights Reserved.
Quick Setup Guide
Boot and process teaching
Host Switch
Radiology
The first step
Insert the power cord plug into the socket.
The second step
Insert the other end of the power cord into the
power socket on the side of the dissection table.
The third step
Turn on the power switch of the dissection table to
1.
The fourth step
Switch the power switch of the dissection table to
start the dissection table. At this time, the dissec-
tion table will have a turning on sound, which
represents the dissection table is starting the
operation.
The fifth step
The screen will light up after the dissection table is
turned on. If there is no signal on the screen,
please be patient and wait a few seconds. The
following screen (As shown in figure) will be
displayed.
The sixth step
When this screen appears (As shown in figure), it
means that the boot is complete.
Advertisement
Table of Contents
Related Manuals for SURGLASSES Asclepius
Summary of Contents for SURGLASSES Asclepius
- Page 1 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Quick Setup Guide Boot and process teaching The first step Insert the power cord plug into the socket. The second step Insert the other end of the power cord into the power socket on the side of the dissection table. The third step Turn on the power switch of the dissection table to Copyright ©...
- Page 2 Radiology Human Anatomy of the main menu screen. Asclepius The second step A prompt message asks if you want to shut down, click YES to start the shutdown operation. Shutdown...
- Page 3 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Connect screen synchronization process teaching The first step First complete the boot process and wait for the dissection table screen to appear before proceed- ing to the first step (Figure 1). After completing Human Anatomy Radiology the above steps, there is an HDMI jack on the side of the dissection table(Figure 2), and then the...
- Page 4 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Connect WI-FI process teaching The first step Click the WI-FI icon on the main menu screen. Human Anatomy Radiology The second step Available networks Current network XXXXX Select a WI-FI name you want to connect. wxyz Password If the name of the WI-FI you want to connect, does...
- Page 5 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Safety Precautions WARNING Not Heavy Load. Copyright © 2023, Taiwan Main Orthopaedic DANGER Biotechnology, Co,. Ltd. All Rights Reserved. Keep Hands Away DANGER Hazardous Voltage Do not touch with wet hands. Disconnect power before servicing. Contact will cause electric shock or burn.
- Page 6 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Tilting Control Hold the handle Please do not step on it. Copyright © 2023, Taiwan Main Orthopaedic Pedal Biotechnology, Co,. Ltd. All Rights Reserved. Press gently. Horizontal to Tilted. Tilted to Horizontal. Press the pedal at the bottom of the Press the pedal at the bottom of the １.
