Taiwan Main Orthopaedic
Biotechnology Co., Ltd.
Power cord
Power cord
Copyright © 2023, Taiwan Main Orthopaedic
Biotechnology, Co,. Ltd. All Rights Reserved.
Power cord
Copyright © 2022 Taiwan Main Orthopaedic Biotechnology, Co,. Ltd. All Rights Reserved.
Quick Setup Guide
Boot and process teaching
The first step
Insert the power cord plug into the socket.
The second step
Insert the other end of the power cord into the
power socket on the side of the table.
The third step
Turn on the power switch of the dissection table to
1.
The fourth step
Turn "ON" the power switch of the screen block
first.
- Page 1
Advertisement
Table of Contents
Related Manuals for SURGLASSES Asclepius
Summary of Contents for SURGLASSES Asclepius
- Page 1 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Quick Setup Guide Boot and process teaching - Page 1 The first step Insert the power cord plug into the socket. Power cord The second step Insert the other end of the power cord into the power socket on the side of the table.
- Page 2 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Boot and process teaching - Page 2 The fifth step 03:25 Please be patient and wait a few seconds. The Friday, Marth, 3 Press to start following screen (As shown in figure) will be displayed.
- Page 3 The sixth step After the power is turned off, the screen surface Asclepius Table can be covered with a dust cover to protect it from being dirty. Copyright © 2022 Taiwan Main Orthopaedic Biotechnology, Co,. Ltd. All Rights Reserved.
- Page 4 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Connect screen synchronization process teaching The first step First complete the boot process and wait for the dissection table screen to appear before proceed- Histopathology Human Anatomy CTRender Radiology Atlas ing to the first step (Figure 1). After completing the above steps, there is an HDMI jack on the side of the dissection table (Figure 2), and then the Figure 1...
- Page 5 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Safety Precautions WARNING Be careful of the tripping Please careful of the legs of the stands of the equipment and do not trample on the legs as it might result in physical injury. DANGER Hazardous Voltage Do not touch with wet hands.
- Page 6 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Hardware specifications For screen control Power switch Home Undo Menu Volume (Screen) Link screen to notebook (for mouse/ Touch HDMI IN MIC Keyboard) Open the cover Pressed Emergency Stop DVD Port Copyright © 2023, Taiwan Main Orthopaedic Biotechnology, Co,.
- Page 7 Taiwan Main Orthopaedic Biotechnology Co., Ltd. Lifting Control (Safety Precautions) When using the remote control to lift the virtual dissection table, please pay attention to the following: The lifting mechanism of the virtual dissection table is a shared system. When there is more than one virtual dissection table in the same space and if the lifting mechanism is operated, it may cause all the virtual dissection table in the same space to perform the lifting mechanism simultaneously.
