Drain Detail:
Assembly Instructions for 72" Wall Mount
Three Station Hand Wash Sink
MSHS-72W1 and MSHS-72W2*
Note: *MSHS-72W2 has 3 sets of 2 holes for faucets
Sink
F (x 4)
D
E
G
**
**Attach wall brackets and legs to wall studs.
***Please make sure wall is structurally sound before installing this unit.
Advertisement
Table of Contents
Related Manuals for BK RESOURCES MSHS-72W1
Summary of Contents for BK RESOURCES MSHS-72W1
- Page 1 Drain Detail: Assembly Instructions for 72” Wall Mount Three Station Hand Wash Sink MSHS-72W1 and MSHS-72W2* Note: *MSHS-72W2 has 3 sets of 2 holes for faucets Sink F (x 4) **Attach wall brackets and legs to wall studs. ***Please make sure wall is structurally sound before installing this unit.
- Page 2 1. Confirm all parts/hardware are included 4. Turn the sink right side up, and place the back side of the sink against 2. Turn sink top upside down on a clean surface to avoid scratching. the wall slightly above the wall brackets. Slide the sink downward Assistance will be needed.
