2002 Volvo C70 Coupe & Convertible
than is normal.
If the brake powerassist does not function
The power assist to the brakes functions only when the engine is running. When the car is moving
without the engine running, the brake pedal pressure required to stop the car is increased by 34 times and
the brake pedal feels stiff.
Moisture on brake discs and brake pads affects braking
Driving in rain and slush or passing through an automatic car wash can cause water to collect on the
brake discs and pads. This will cause a delay in braking effect when the pedal is depressed. To avoid
such a delay when the brakes are needed, depress the pedal occasionally when driving through rain,
slush etc. This will remove the water from the brakes. Check that brake application feels normal. This
should also be done after washing or starting in very damp or cold weather.
pg. 79 Brake system - EBD, STC
EBD (Electronic Brake-force Distribution)
EBD is an integrated part of the ABS system. EBD regulates the hydraulic pressure to the rear brakes to
help provide optimal braking capacity.
If the BRAKE and ABS warning lights come on at the same time, this could indicate a fault in the brake
system. If the brake fluid level is above the MIN mark, drive carefully to an authorized Volvo retailer
and have the brake system inspected.
WARNING!
If the fluid level is below the MIN mark in the reservoir, DO NOT DRIVE. Have the car towed to an
authorized Volvo retailer and have the brake system inspected.
Stability and Traction Control (STC) - option on certain models
Stability Traction Control works in conjunction with TRACS to help
control wheel spin at all speeds. At speeds below 25 mph, TRACS
controls the braking system to stop wheel spin. At speeds over 25
file:///K|/ownersdocs/2002/2002_C70/02c70c_04c.htm (2 of 6)12/30/2006 3:53:56 PM
