Model # SFR1.1
USER MANUAL
START HERE
Accessory Rack Installation Instructions
Record Serial Number Here
Health in Motion LLC
V07062023R1
MADE IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SFR1.1 and is the answer not in the manual?

Questions and answers

Related Manuals for Inspire SFR1.1

Summary of Contents for Inspire SFR1.1

  • Page 1 Model # SFR1.1 USER MANUAL START HERE Accessory Rack Installation Instructions Record Serial Number Here Health in Motion LLC V07062023R1 MADE IN CHINA...

  • Page 3: Before Assembling

    CONGRATULATIONS Welcome to the Inspire Fitness Family. You’ve just taken the first step to a healthier and stronger body. This SF5 Smith Machine Functional Trainer by Inspire Fitness offers the key to unlocking your body’s potential. Regular training on a Smith Machine Functional Trainer has been shown to deliver a host of benefits including: increased muscle tone, decreased body fat, improved energy levels, and a reduction in stress.

  • Page 4: Product Warranty

    PRODUCT WARRANTY To view full warranty details, or to register your product for warranty, visit inspirefitness.com/support AUSTRALIA Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

  • Page 5: Assembly And Setup

    Accessory Rack ASSEMBLY AND SETUP Assembly Hardware Kit (Not to Scale) GM6970-32 STEP 1 (6) BOLT, M10 X 1.5 X 95, HH, BZ, 2pc. (4) WASHER, FLAT, 11 X 20 X 2, BZ, 8pc. (7) BOLT, M10 X 1.5 X 75, HH, BZ, 2pc. (5) NUT, M10 X 1.5, LOCK, BZ, 4pc.
  • Page 6 STEP 1 1. Before installation of the new dumbbell rack, please remove the installed plugs as illustrated below. Please use a flat head or slotted screwdriver to pry-off each of the installed plugs, total of 8 plugs. Pg. 6 V07062023R1...
  • Page 7 Accessory Rack STEP 2 1. Install Dumbbell bracket Right (1), and Dumbbell bracket Right (2) to frame. Use M10 x 95 Hex Bolt (6), #10 Washer (4), M10 Lock Nut (5). Do not fully tightent. 2. Install Weight trays (3) on lower and Upper position. Use M10 x 75 Hex Bolt (7), #10 Washer (4), M10 Lock Nut (5). Do not fully tighten.

  • Page 8: Parts Lists

    PARTS LISTS Part Number Description Qty. GM697300003PT0105 Dumbbell braket -Right GM697300002PT0105 Dumbbell braket -Left GM697300004PZ Weight Tray 0116-010-008 #10 Washer 0110-710-008 M10 Lock Nut 0111-010-959A M10 x 95 Hex Bolt 0111-010-758 M10 x 75 Hex Bolt M330-561-002 14# & 17# Hex Wrench...
