- Page 1 ALSIPERCHA SYSTEM Anchor-Device according to EN 795:2012 Type B Assembly, Use and Safety Instruction Manual Code 6490009ENLZ / 6790009ENLZ ►...
- Page 2 This documentation provides the basis for the evaluation of specifi c risks in the works, and Alsina’s Instruction Manuals may in no case be regarded as a substitute. Sets of vertical formwork equipment, as systems, are made up by joining different components.
- Page 3 ISO 9001:2015 Certifi cation The Alsina Group is ISO 9001:2015 certifi ed. The Alsina Group has been granted the ISO 9001:2015 certifi cation for their sales and rental service of concrete formwork equipment. The certifi cate was granted by BVQI, an institution of renowned prestige and worldwide experience, under UKAS accreditation.
-
Page 4: Description Of The System
The system and its components must be used by Info. competent, qualifi ed personnel. Alsipercha is CE certifi ed in accordance with the DIN EN 795 type B (Notifi ed Body 0158, DEKRA EXAM) Info. The system and its accessories must be inspected by competent, qualifi... -
Page 5: Component Description
Alsipercha with housing tube Alsipercha System Component Description HOUSING TUBE Description: Component that is sunk into the concrete column and houses the Alsipercha fall Info. In all codes the second digit can be either 3, 4, or 7. arrest system. ALSIPERCHA BODY code... -
Page 6: Assembly Process
(*) This tolerance will vary depending on the column section. If using the Alsipercha system in columns with a section smaller than 30 cm, cracks may appear in the concrete. In this case, consult the structure client. LEGEND... - Page 7 120º and stable load). Detail of the installation of the retractable device with the fall arrest system. It is possible to extend the range of action of the Alsipercha, but following a It is important to close the clasp properly.
- Page 8 fl oor measuring approximately 500 m The Alsipercha allows the worker to change anchorings before unhooking from the fi rst Alsipercha Body, so safety is maintained at all times. Use the hook to do this if the next Alsipercha is positioned so that the worker cannot reach to anchor themselves.
- Page 9 Info. Rescue of worker after a fall: It is important that when safely with a radius of 6.5 m, which equals approximately 125 m workers work with the Alsipercha Fall Prevention System, they are not alone. In this way, in the event of a fall, the other...
- Page 10 8.5 m in either direction. The protected area covered by a single Alsipercha unit can be extended by using an alternative set of user equipment, however this MUST be used in a controlled and disciplined manner. Failure to...
- Page 11 Table of minimum concrete strengths Shown below are the time periods for use (the time between pouring column concrete and when the Alsipercha can be used) depending on ambient temperature and column cross-section. The results shown below are from tests performed with Alsipercha in...
-
Page 12: Disassembly Process
Fold the product in the following order: - Insert the safety pin, making sure that the three tubes are perfectly - Remove the boat hook accessory from the Alsipercha and place it on joined and that the safety pin fastens the three tubes. - Page 13 Therefore, in this case and in all those that appear in red in the steel, the tube thicknesses that cause the interaction diagram compression table, the incorporated tube as part of the ALSIPERCHA for the modifi ed section to wrap around the original section.
- Page 14 Storage shall be properly organized in suitable locations, away from The Alsina Group does not participate in the management or execution passageways. of the project, and the client is solely responsible for the proper use of the materials supplied.
-
Page 15: Equipment Maintenance
When assembly is not carried out by Alsina, the user must accept responsibility for proper use and maintenance of the equipment. The users are always responsible for maintaining all equipment, whether rented or the customer's own property. - Page 16 Alsipercha System Appendix 1: Conditions of use on site Alsipercha Body Review Procedure - 84411, column clamps - 83424, column clamp sleeve - 83426 and Tripod for unlading trucks - 84475, Below are the guidelines for reviewing each component of the Alsina 83472, 84478, 83473 inspection procedure.
- Page 17 Conditions of use on site Alsipercha System Leveller Review Procedure - 83416 Control guidelines Procedure - Check that the leveller is in its original condition. Verify that it enters and exits If problems are a housing tube that is in good condition.
-
Page 18: Inspection And Maintenance
Inspection and maintenance Alsipercha system DEVICE IDENTIFICATION SHEET (A) Distributor / Reseller / Details Encofrados J. Alsina S.A. Pol. Ind. Pla d’en Coll (B) Manufacturer Camí de la Font Freda, 1 08110 - Montcada i Reixac (Barcelona - Spain) (C) Product (type, model, code)
