- Page 1 ALSIPERCHA SYSTEM Anchor-Device according to EN 795:2012 Type B Assembly, Use and Safety Instruction Manual Code 6490009ENLZ / 6790009ENLZ ►...
- Page 2 This documentation provides the basis for the evaluation of specifi c risks in the works, and Alsina’s Instruction Manuals may in no case be regarded as a substitute. Sets of vertical formwork equipment, as systems, are made up by joining different components.
- Page 3 ISO 9001:2015 Certifi cation The Alsina Group is ISO 9001:2015 certifi ed. The Alsina Group has been granted the ISO 9001:2015 certifi cation for their sales and rental service of concrete formwork equipment. The certifi cate was granted by BVQI, an institution of renowned prestige and worldwide experience, under UKAS accreditation.
-
Page 4: Description Of The System
The system and its components must be used by Info. competent, qualifi ed personnel. Alsipercha is CE certifi ed in accordance with the DIN EN 795 type B (Notifi ed Body 0158, DEKRA EXAM) Info. The system and its accessories must be inspected by competent, qualifi... -
Page 5: Component Description
Designed and certifi ed according to the EN 795 anchor devices standard. The ALSIPERCHA TRIPOD is folded up when it is delivered onsite. Once it has been placed in its work position, it is assembled according... - Page 6 0.01 40 mm Alsipercha tripod mounting procedure Step 1 It is very important to mount the ALSIPERCHA To open the tripod leg, release the connecting PINS. Info. TRIPOD on suffi ciently compact and resistant terrain so that the anchor device provides suffi cient safety guarantees.
- Page 7 Step 3 Step 6 Secure it in the open position by placing the pin in the R position. ALSINA TRIPOD in the working position. Step 7 On the HA25 concrete sole plate, drill with an 18 mm - diameter bit to a depth of 140 mm.
- Page 8 Procedure for use on site Step 9 With a dynamometric wrench, torque to 80 Nm. Repeat for all three anchors. Finally, using the crane, place the Alsipercha on top of the General Information ALSIPERCHA TRIPOD. There are 5.5 or 6.5 metres from the anchor point to the fl oor, depending on the type of tripod selected, meaning that the worker can work above the truck load in complete safety.
-
Page 9: Final Assembly
Alsipercha System Trucks that are 6 m long To unload the 6-metre platform of a truck, only one Alsipercha system will need to be used. When parking the truck, the rear box/platform must be situated according to the distances shown in the following... - Page 10 When parking the truck, the rear box/platform must be situated according to the distances shown in the illustration below. The worker must be attached to two Alsipercha systems. This will help him control the movement on the 12 m long platform in the event of a fall.
- Page 11 Therefore, in this case and in all those that appear in red in the steel, the tube thicknesses that cause the interaction diagram compression table, the incorporated tube as part of the ALSIPERCHA for the modifi ed section to wrap around the original section.
- Page 12 Storage shall be properly organized in suitable locations, away from The Alsina Group does not participate in the management or execution passageways. of the project, and the client is solely responsible for the proper use of the materials supplied.
-
Page 13: Equipment Maintenance
When assembly is not carried out by Alsina, the user must accept responsibility for proper use and maintenance of the equipment. The users are always responsible for maintaining all equipment, whether rented or the customer's own property. - Page 14 Alsipercha System Appendix 1: Conditions of use on site Alsipercha Body Review Procedure - 84411, column clamps - 83424, column clamp sleeve - 83426 and Tripod for unlading trucks - 84475, Below are the guidelines for reviewing each component of the Alsina 83472, 84478, 83473 inspection procedure.
- Page 15 Conditions of use on site Alsipercha System Leveller Review Procedure - 83416 Control guidelines Procedure - Check that the leveller is in its original condition. Verify that it enters and exits If problems are a housing tube that is in good condition.
-
Page 16: Inspection And Maintenance
Inspection and maintenance Alsipercha system DEVICE IDENTIFICATION SHEET (A) Distributor / Reseller / Details Encofrados J. Alsina S.A. Pol. Ind. Pla d’en Coll (B) Manufacturer Camí de la Font Freda, 1 08110 - Montcada i Reixac (Barcelona - Spain) (C) Product (type, model, code)
