- Page 1 U S E R M A N U A L Nox M Street Light Contents Foreward Safety Warnings Product Information Product Dimensions Mast-Arm Installation Post-Top Installation Internal Access and Connection Version 1.0...
- Page 2 Safety Warnings Please follow these safety guidelines to ensure your LED fitting functions correctly. Ibex warranty does not cover problems or damages that occur as a result of mishandling or from non- compliance with these instructions.
- Page 3 Product Information Item Power Voltage Net Weight Sail Area (max) (max) NMS.XX.XXX.XX.XX.XX.XXX. 220 W 220-240V 9 KG 0.078m^2 50/60Hz Maximum installation height is 15 m. Product Dimensions (mm)
- Page 4 Mast-Arm Installation Loosen 2 x M10 hex grub screws, feed power cable through spigot and cable gland, adjust alignment and tighten screws. Adjust throw by loosening 2 x M8 cap screws, adjust in reference to markings and tighten screws. 2 x M8 Hex socket cap screws Tighten to 10 Nm 2 x M10 Hex socket grub screws 2 x M10 half lock-nuts...
- Page 5 Internal Access and Connection Loosen 2 x M6 cap screws to open lid, engage stand to keep lid open if required, feed power cable through cable gland, connect cable ends to the correct terminals, tighten cable gland, ensure all internal wiring is internally contained, restore lid stand, close lid and re-tighten cap screws.
- Page 6 Thank you.
