LED LOW VOLTAGE
TEMPORARY WORK LIGHT
Models: 86-216
INSTALLATION AND SAFETY INSTRUCTIONS
IMPORTANT: Read before installing fixture. Retain for future reference.
WARNING: Risk of Fire or Electric Shock
• Disconnect power before installation or any maintenance of the fixture.
• To avoid damage, falling, electric shock or fire, do not modify the fixture
or replace accessories without confirming with the supplier first.
• Only authorized, qualified personnel should install this fixture and
should follow the owner's manual.
• Do not dismantle the fixture without the supplier's authorization.
• Do not touch the power supply when the fixture is operating.
• For use in environments where an accumulation of non-conductive
dust on the fixture may be expected.
• Suitable for damp location.
IMPORTANT:
This product must be installed in accordance with the applicable installation
code by a person familiar with the construction and operation of the product and the hazards involved.
Model Watts Volts
86-216 10W/12W/24W 36V
Works with the following Satco remote drivers & downlights
Low profile LED edge-lit downlights
4" ROUND S11600, S11601, S11602
6" ROUND S11603, S11604, S11605
8" ROUND S11606, S11607, S11608
4" SQUARE S11609, S11610, S11611
6" SQUARE S11612, S11613, S11614
8" SQUARE S11615, S11616,S11617
INSTALLATION
1. Connect remote driver per instructions in ceiling.
2. Plug low voltage lamp into remote driver connector.
3. Hang lamp using built-in ring.
© Copyright 2020 Satco Products, Inc. 7/20
CCT Lumens Beam CRI
3000K 750 / 950 / 1800 280°
Low profile LED downlights
4 1/2" ROUND S11618, S11619, S11620
4 1/2" SQUARE S11621, S11622, S11623
3 1/2" ROUND S11624, S11625, S11626
3 1/2" SQUARE S11627, S11628, S11629
3 1/2" ROUND S11630, S11631, S11632
3 1/2" SQUARE S11633, S11634, S11635
Fixture Includes:
1 LED Lamp with connector
Dimensions Finish
90 4.6" x 5.8" White
Low profile LED Color Quick
edge-lit downlights
4 " ROUND S11826
6 " ROUND S11827
8 " ROUND S11828
4 " SQUARE S11829
6 " SQUARE S11830
8 " SQUARE S11831
Satco Products, Inc.
Brentwood, NY 11717
