Assembly And Installation Manual For
Affordable Lift Model KCSPM3648
Specifically For Serial Number E9997
Manual Print Date: Dec 01, 2023, 01:03 PM EST
If you see errors in this manual please notify Shae.Murphy@AffordableLifts.com
Station Height:
Weight Capacity:
Column Length:
Color:
Motor:
Base:
Safety System:
Column Bracing:
Wheel Kit:
Rain Guard:
Battery Backup:
Shipped As:
Shipped On:
All images in this manual are representational only.
Lift E9997 Specifications:
38.0"
500 lbs
78.0"
Gloss Black
1500 lbs w/ Tethered Controller
Armed Base
Self Retracting Lifeline (SRL)
None/NA
Yes
Yes
Not Purchased
Assembled
On A Regular Pallet
Advertisement
Table of Contents
Related Manuals for AFFORDABLE LIFTS KCSPM3648
Summary of Contents for AFFORDABLE LIFTS KCSPM3648
- Page 1 Assembly And Installation Manual For Affordable Lift Model KCSPM3648 Specifically For Serial Number E9997 Manual Print Date: Dec 01, 2023, 01:03 PM EST If you see errors in this manual please notify Shae.Murphy@AffordableLifts.com Lift E9997 Specifications: Station Height: 38.0" Weight Capacity:...
-
Page 2: Table Of Contents
Table of Contents Click on a Section to jump to that section. Section Section Number Introduction Section 1 Safety Section 2 Warnings Section 3 Terminology Section 4 Prepare to Assemble and Install Your Lift Section 5 The Wheel Kit Section 6 Unpack Your Lift Section 7 Position Your Lift... -
Page 3: Introduction
1. Introduction Congratulations on your purchase of a new platform lift! We sincerely hope that this lift will help you accomplish the things that are important to you and those you love. Note: We have many of the assembly steps recorded on video for your reference. These videos are not a substitute for this manual. -
Page 4: Safety
2. Safety 2.1. Safety is paramount! If you have a question or concern about the safe installation or operation of your lift please call Customer Support at (USA) 434-515-2321 (Provide your Serial Number 'E9997' and contact information when you call). 2.2. - Page 5 3. Warnings Caution! Carefully read the owners manual and the following warnings prior to use. Failure to comply with the following may result in serious bodily injury, death, or damage to the lift. If you have questions, contact Customer Support at (USA) 434-515-2321 (Provide your Serial Number 'E9997' and contact information when you call).
-
Page 6: Terminology
Instructions List of all parts and Packing List None components shipped Also available via email on request - call (USA) Assembly and Installation 434-515-2321 (Provide your None Manual for the KCSPM3648 Serial Number 'E9997' and contact information when you call) -
Page 7: Prepare To Assemble And Install Your Lift
5.3. We recommend that at least two adults work together to install this lift. Some parts of your lift are quite heavy and having two or more people assemble your lift reduces the risk of injury. Affordable Lifts is not responsible for injuries that occur while installing or utilizing your lift. -
Page 8: The Wheel Kit
6. The Wheel Kit 6.1. Your lift was shipped with a detachable Wheel Kit. We will discuss the Wheel Kit now because you may choose to use it in the next steps. The Wheel Kit consists of two 8" wheels and their axle bolts. These wheels allow the lift to be tilted backwards and wheeled over a smooth hard surface. -
Page 9: Position Your Lift
7.6. Move to installation site: Move the lift and its parts to the lift installation site. 7.7. Weather: Electrical components should be protected from weather until properly installed. 8. Position Your Lift 8.1. Move and orient the lift to the position where it will be used. Do NOT anchor it at this time. 8.2. -
Page 10: Test Your Lift
9.4. Plug in the hoist motor power cord into a suitable outlet. 9.5. Power Cord: Consider using a zip tie to secure any excess power cord out of the way so that it will not rub or chaff. 10. Test Your Lift 10.1. -
Page 11: Anchoring The Armed Base
2. The photos below show a Rain Guard installed over the switch. 3. To install the Rain Guard, loosen the Upper Limit Switch set screw, slide the Rain Guard tab down between the Column and the Upper Limit Switch mounting bracket, as in the photo below. Then tighten the Upper Limit Switch set screw. 11.3. -
Page 12: Finalize Column Bracing
6. If you will use your Platform's left opening at an upper landing, then the left side of your Column should be 25.0" from the edge of that landing. This number includes a 0.5" (1/2") gap between the edge of your Platform and your landing. -
Page 13: Minimize Platform "Twist
14.3. Convenience: If you have a gate that is facing a very close, solid, smooth wall for the Platform's entire travel, the gate may not be necessary. It may be more convenient for you to remove and store the gate. This is easy to do using a 3/8" allen wrench. -
Page 14: Controller Storage Box
4. If the Platform will not “slide” down the Column under its own weight, then the adjustment is too tight and should be loosened. Reapply tension to the hoist synthetic rope by pushing the "Up" button and then loosen the adjustment bolt. Do this in 1⁄4 turn increments. -
Page 15: Troubleshooting
4. Care of your Column: You should not paint the Column where the sliding anti-friction pads have regular contact. Affordable Lifts has an optional special lubricating and anti-rust coating for the column that you can apply. If you would like to purchase this anti-rust coating please contact Customer Support at (USA) 434-515-2321 (Provide your Serial Number 'E9997' and contact information when you call).
