AFFORDABLE LIFTS KCSPM3648 Assembly And Installation Manual

Hide thumbs Also See for KCSPM3648:
Table of Contents

Advertisement

Quick Links

Download this manual
Assembly And Installation Manual For
Affordable Lift Model KCSPM3648
Specifically For Serial Number E9997B
Manual Print Date: Dec 01, 2023, 12:50 PM EST
If you see errors in this manual please notify Shae.Murphy@AffordableLifts.com
Station Height:
Weight Capacity:
Column Length:
Color:
Motor:
Base:
Safety System:
Column Bracing:
Wheel Kit:
Rain Guard:
Battery Backup:
Shipped As:
Shipped On:
All images in this manual are representational only.
Lift E9997B Specifications:
38.0"
500 lbs
78.0"
Gloss Black
1500 lbs w/ Tethered Controller
Armed Base
Self Retracting Lifeline (SRL)
None/NA
Yes
Yes
Not Purchased
Disassembled
On A Regular Pallet

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KCSPM3648 and is the answer not in the manual?

Questions and answers

Related Manuals for AFFORDABLE LIFTS KCSPM3648

Summary of Contents for AFFORDABLE LIFTS KCSPM3648

  • Page 1 Assembly And Installation Manual For Affordable Lift Model KCSPM3648 Specifically For Serial Number E9997B Manual Print Date: Dec 01, 2023, 12:50 PM EST If you see errors in this manual please notify Shae.Murphy@AffordableLifts.com Lift E9997B Specifications: Station Height: 38.0" Weight Capacity:...

  • Page 2: Table Of Contents

    Table of Contents Click on a Section to jump to that section. Section Section Number Introduction Section 1 Safety Section 2 Warnings Section 3 Terminology Section 4 Prepare to Install Your Lift Section 5 The Wheel Kit Section 6 Unpack Your Lift Section 7 Remove Safety Guard Section 8...

  • Page 3: Introduction

    1. Introduction Congratulations on your purchase of a new platform lift! We sincerely hope that this lift will help you accomplish the things that are important to you and those you love. Note: If you are like me, then you hate reading instructions almost as much as you hate having to do things over because you did it wrong.

  • Page 4: Safety

    2. Safety 2.1. Safety is paramount! If you have a question or concern about the safe installation or operation of your lift please call Customer Support at (USA) 434-515-2321 (Provide your Serial Number 'E9997B' and contact information when you call). 2.2.
  • Page 5 3. Warnings Caution! Carefully read the owners manual and the following warnings prior to use. Failure to comply with the following may result in serious bodily injury, death, or damage to the lift. If you have questions, contact Customer Support at (USA) 434-515-2321 (Provide your Serial Number 'E9997B' and contact information when you call).

  • Page 6: Terminology

    Instructions List of all parts and Packing List None components shipped Also available via email on request - call (USA) Assembly and Installation 434-515-2321 (Provide None Manual for the KCSPM3648 your Serial Number 'E9997B' and contact information when you call)
  • Page 7 Affordable Lift - 42.0"x52.0"x35.2", Gloss Disassembled Black Hoist Assembly - 1500 lbs 8.25"x26.0"x7.5", Gloss w/ Tethered Controller Black Standard Steel Lift Column 3.5"x20"x83"x1/4" (.25") - RTS3x3x.25X78 - Flanged 70 lbs 52.0"x40.0"x3.25", Gloss AWB52x40 Base with Arms Black HBH0.5-13x5 Base with Arms - Bolts .5"-13x4.5"...
  • Page 8 6000106 Collar - Backing Plate 3.5"x4.7"x1" Plate 6000014 Collar - Regular Slip Pads .25"x3"x4.1" Collar - Backing Plate Slip 6000013 .25"x3.5"x3.9" HBH0.375-16x5 Collar - Bolt 3/8"-16x5" HNW0.375-16x Collar - Bolt - Nylock Nuts 3/8"-16 Nylock Nuts 3500010 Controller Storage Box 7.1"x11.6"x5.1"...

  • Page 9: Prepare To Install Your Lift

    5.3. We recommend that at least two adults work together to assemble this lift. Some parts of your lift are quite heavy and having two or more people assemble your lift reduces the risk of injury. Affordable Lifts is not responsible for injuries that occur while assembling or utilizing your lift.

  • Page 10: The Wheel Kit

    6. The Wheel Kit 6.1. Your lift was shipped with a detachable Wheel Kit. We will discuss the Wheel Kit now because you may choose to use it in the next steps. The Wheel Kit consists of two 8" wheels and their axle bolts. These wheels allow the lift to be tilted backwards and wheeled over a smooth hard surface.

  • Page 11: Remove Safety Guard

    8. Remove Safety Guard 8.1. Remove the Safety Guard from in front of the Collar. You will reattach it after finishing the next several steps. Be sure to not lose the four acorn nuts. 9. Connect the Armed Base, Column and Hoist Assembly Here is a video of this step: Click here 9.1.
  • Page 12 on your situation you may choose to do them in different orders, as outlined above. 9.8. Pivot the Column to Its Vertical Position: For tall lifts, please take extreme caution during this step. Depending on its length your Column could weigh over 200 pounds. Consider obtaining scaffolding, ladders, or other equipment so that you can safely do some of these steps.

  • Page 13: Attach The Platform To The Column

    1. With the Column upright, use a scaffold, deck or other structure to safely access the top of the Column. You may wish to temporarily lean the Column slightly or rotate the base to position the Column's top nearer to your landing. 2.
  • Page 14 10.4. Ensure that the Slip Pad you just installed has not fallen out of position. Now insert a common-sized Slip Pad into each of the two pockets found along either side of the lower Collar. If the fit is a bit tight you may need to tap the Slip Pad with a hammer and screwdriver, jiggle the Platform or use a screwdriver to widen the opening.

  • Page 15: Safety Backup System

    10.8. Install the Upper Limit Switch Actuator Spring (a silver L shaped piece of sheet metal with holes on one side) and secure the Backer Plate as shown in the photos below. The Slip Pad must be against the Column. The Upper Limit Switch Actuator Spring is critical and prevents your Upper Limit Switch from being crushed.

  • Page 16: Electrical Power

    3. With the wire rope running through the pulley, attach and secure the SRL cable pulley to the Safety Lock Mounting Lug on the right side of the Column midway down. Do so by inserting the pulley's carabiner or bolt through the holes at the bottom of the pulley.

  • Page 17: Connect Your Synthetic Rope

    13. Connect Your Synthetic Rope 13.1. Attaching the Synthetic Rope: Here is a video of attaching your lift's synthetic rope: Click here 1. Connect your hoist motor to electrical power. 2. While lightly pulling your synthetic rope, use your Controller to unspool enough synthetic rope to reach slightly past the hoist mounting lug.

  • Page 18: Adjust Your Lift's Maximum Height

    15. Adjust Your Lift’s Maximum Height 15.1. Upper Limit Switch: Your lift has an Upper Limit Switch that automatically stops the Platform at a preset station height. This is an important safety feature. You can set this height easily using the 1/8" allen wrench supplied with the lift, taped on to the Upper Limit Switch bracket.

  • Page 19: Anchoring The Armed Base

    2. The photos below show a Rain Guard installed over the switch. 3. To install the Rain Guard, loosen the Upper Limit Switch set screw, slide the Rain Guard tab down between the Column and the Upper Limit Switch mounting bracket, as in the photo below. Then tighten the Upper Limit Switch set screw. 16.

  • Page 20: Finalize Column Bracing

    8. If your Platform's front side passes by an obstruction, then the front side of your Column should be at least 37.75" from that obstruction. This number includes a 1" gap between the edge of your Platform and that obstruction. 9.

  • Page 21: Minimize Platform "Twist

    19.3. Convenience: If you have a gate that is facing a very close, solid, smooth wall for the Platform's entire travel, the gate may not be necessary. It may be more convenient for you to remove and store the gate. This is easy to do using a 3/8" allen wrench.

  • Page 22: Controller Storage Box

    4. If the Platform will not “slide” down the Column under its own weight, then the adjustment is too tight and should be loosened. Reapply tension to the hoist synthetic rope by pushing the "Up" button and then loosen the adjustment bolt. Do this in 1⁄4 turn increments.

  • Page 23: Troubleshooting

    4. Care of your Column: You should not paint the Column where the sliding anti-friction pads have regular contact. Affordable Lifts has an optional special lubricating and anti-rust coating for the column that you can apply. If you would like to purchase this anti-rust coating please contact Customer Support at (USA) 434-515-2321 (Provide your Serial Number 'E9997B' and contact information when you call).
