XL Systems 0001909 Manual

14 Dora Ln Holmdel, NJ 07733
Diesel Sound Decoder with 6 Prime Mover Sound
Thank you for purchasing our advanced DCC diesel 16 bit sound only
decoder. Combined with any non-sound power decoder installed in your
locomotive, and used with your favorite DCC System, our new sound only
decoder will make your model locomotive come to life.
Easy installation - two wire only
Six synchronized diesel prime movers with random associated
locomotive sounds
28 functions (F1 - F28)
2 or 4-digit (1-9999) addressing
Programmable 14, 28, 128 speed steps
Programmable acceleration rate, deceleration rate
Programmable user selectable 22 different horns and 8 bells
Programmable individual sound volumes (16 levels)
Programmable master sound volumes (16 levels)
Supports advanced consisting (CV19)
Supports programming on the main (OPS mode)
Compatible with NMRA DCC standards
Complies with the part 15 of FCC
18mm speaker included
Dimensions: 17.4mm x 17.4mm x 4.0mm
Note- Instead of using CV3 and CV4, the decoder uses CV120 and CV121 as acceleration
and deceleration rates. So you can change its acceleration and deceleration rates without
changing CV3 or CV4 in your power decoder, if you already have these rates tailored for
your locomotives optimum performance.
ADDRESS PROGRAMMING:
The "Sounder" comes with a factory default address of #3, and 28 speed steps. If your
locomotive has a different address, and speed step already programmed into it, place the
locomotive, with decoder and Sounder installed, on your program track and reprogram it to
the address you had originally programmed it to. While it is on the program track, also
reprogram the locomotive to the speed step of your choice, (14-28/128). Since the decoder
does not have a motor driver, you can't read back its CV.
ADDITIONAL INFORMATION:
The Sounder synchronized diesel sound only decoder should perform well when used with
other brand command systems, and decoders. See your DCC command stations manual
to learn how to program and operate any decoder. For more information about register/
CVs and their functions, please refer to the NMRA DCC Standard & Recommended
practices, RP-9.2.2 available directly from the NMRA or their website at www.nmra.org.
TROUBLE SHOOTING:
This decoder should perform well with all DCC systems. The maximum DCC output should
be less than 15 V. If the locomotive does not respond to commands, it may have lost its
address. Please reprogram the address and program CV19 to 0 (disable consist). If it
responds slowly, you should clear its momentum by reprogramming CV120 and CV121 to
zero. You should also clean the track to improve electrical pickup. Read your DCC system
manual to learn how to program and operate the decoder. Whenever the decoder doesn't
XL Systems Inc
Item #0001909
work please use the program track to program CV# 125 with value 1 to restore the decoder
to factory settings. This should bring the decoder to life with address #3.
RETURN PROCEDURE:
This decoder carries a 6 month warranty against factory defects. This warranty does not
include abuse, misuse, neglect, improper installation, or any modifications made to this
decoder. If it should become necessary to return the decoder for warranty repair/
replacement, please include a copy of the original sales receipt. Please include a letter
(printed clearly) with your name, address, daytime phone number, and a detailed
description of the problem you are experiencing. Please also include a check or a money
order for $8.00 to cover return shipping and handling. If the decoder is no longer
considered under warranty, then please include a check or a money order for $12.00 to
cover the cost of repair or replacement and return shipping and handling.
Send the decoder to:
XL Systems Inc
14 Dora Ln
Holmdel, NJ 07733
Email: linzping@gmail.com
FUNCTION CHARTER:
Function Idle/Moving
F1
F2
F3
F4
F5
F6
F7 Air hose firing/uncoupling lever
F8 Click 3 times will shut down when in idle/Manual notch down
F9 Engine cooling fan / Manual notch up
F10 Rail wheel clack (only moving)
F11
F12 Change prime diesel rumble type (CV123, 6 types)
F13 Master volume reduce by 1 / air release
F14 Master volume increase by 1 / air release
F15
F16
F17
F18 Change bell type (8 types plus off)
F19 Horn type select (total 22 different horns plus off)
F20
F21 Change bell volume and turn on the bell
F22
F23 Change diesel rumble volume
F24
F25
F26
F27
F28
Bell on/off
Horn
Air release
Coupling 1
Brake release / brake squeal
Dynamic brake on/off
Traction air compressor
Air compressor
flange squeal
Air release
Associated loco sound
Change horn volume
Safety valve pop
Air release
Flange noise
Sand drop
Air release
