Installation & Operation Guide
Components list
No.
Components
1
Exterior Knob
2
Interior Knob
3
Latch
4
Key
Please check the above components carefully to make sure all items have been received. If any items are
missing, please contact the online Customer Service.
Please read this manual carefully before installing and operating!
Tools Required
(1) Phillips screwdriver
(2) Tape measure
Knob Lock with Fingerprint
Model No.: K01
Quantity
1
1
1
2
1
No.
Components
5
Striker Plate
6
Striker Box
7
Screw A
8
Screw B
English
Quantity
1
1
4
2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KLLOQUE K01
Summary of Contents for KLLOQUE K01
- Page 1 English Knob Lock with Fingerprint Model No.: K01 Installation & Operation Guide Components list Components Quantity Components Quantity Exterior Knob Striker Plate Interior Knob Striker Box Latch Screw A Screw B Please check the above components carefully to make sure all items have been received. If any items are missing, please contact the online Customer Service.
- Page 2 Installation Guide 1. Check The Door’s Dimension （1）Measure to confirm the thickness of the door is between 1-3/8” and 2-1/8” (35~54mm). （2）Measure to confirm the diameter of the hole in the door is 2-1/8” (54mm). （3）Measure to confirm the backset (as shown below) is either 2-3/8” (60mm) or 2-3/4”(70mm). （4）Measure to confirm the diameter of the hole in the door edge is 1”...
- Page 3 2. Install Latch and Strike （1）Set the Latch backset to 60mm(2-3/8”) or 70mm(2-3/4”) to fit your door hole. （2）Insert the Latch into the door hole, and tighten Screw A to fix the Latch. Install Striker Box and Striker Plate also with Screw A into the door frame. Striker Box Striker Plate 3.
- Page 4 Operation Guide (1) Key to unlock Pull out the fingerprint head cover directly. Or press the screw in the back of the Exterior Knob, and the fingerprint head cover will be pushed out a bit so that you can pull it out more easily. Insert the key and turn the key 90°...
