Summary of Contents for FEITIAN M200
- Page 1 M200 Introduction V1.0 Feitian Technologies Co., Ltd. www.FTsafe.com...
-
Page 2: Table Of Contents
M200 Introduction Content Chapter 1. M200 Product Introduction ........................i 1.1 Product Introduction................................i 1.2 Product Appearance ................................i 1.3 Specifications ..................................ii 1.3.1 Dimensions ........................................ii 1.3.2 Screen ..........................................ii 1.3.3 Communication Interface ..................................ii 1.3.4 Battery and Power Source ..................................iii 1.3.5 Audio .......................................... -
Page 3: Chapter 1. M200 Product Introduction
Chapter 1. M200 Product Introduction 1.1 Product Introduction Feitian M 2 0 0 is a s m a r t m o b i l e POS product with PCI PTS6.2 certification. It has a stylish and smart design. Connect with smart phone or tablet via Bluetooth interface, you can easily and quickly complete the payment process. -
Page 4: Specifications
M200 Introduction Figure 1 M200 appearance figure 1.3 Specifications 1.3.1 Dimensions Size: 146mm x 105mm x 57mm 1.3.2 Screen 5.0-inch TFT full color LCD display, resolution of 720 x 1280 Optional resistive touchscreen 1.3.3 Communication Interface RF Band SKU1:Only WIFI... -
Page 5: Audio
M200 Introduction This device can be connected to smart phone or bluetooth headset through this interface. This device supports GPS, as well as GLONASS、Beidou、GPS NFC is a POS function, which supports 13.56MHz，ISO/IEC 14443，ISO18092， Type A&B、Felica， Mifare card 1.3.4 Audio ... -
Page 6: Magnetic Stripe Card Reader
M200 Introduction 1.3.10 Magnetic Stripe Card Reader The magnetic stripe card must be compliant with ISO/IEC 7811, ISO/IEC 7813 standard. The magnetic strip card reader can read data from magnetic track 1, 2, 3 at the same time, support bi-directional swipe, swipe speed ranges from 10mm/s to 100mm/s. -
Page 7: Features
M200 Introduction 1.3.12 Features Tamper-proof and anti-power-down protection Support MK/SK and DUKPT key systems RSA、AES、3DES、SHA-1、SHA-256；Support RSA, AES, 3DES, SHA-1, SHA-256 Support SM2, SM3, SM4 Physical tamper-proof has self-destruction function Support redevelopment 1.4 Certifications ... -
Page 8: Installation
M200 Introduction Amex MSDS Discover PURE 1.5 Installation Step 1. Turning on the device • Connection power adapter, the system will start. • If required, remove the protective film from the display. Step 2. Mobile payment application Please follow the instructions provided by your bank or service provider to download the mobile application onto this device. - Page 9 M200 Introduction printed on the top of the device. • To read a contactless card it must be positioned in close proximity to the device over the contactless symbol. • Follow the instructions provided by your bank or service provider to complete the transaction.
-
Page 10: Fcc Statement
• This device is intended for handheld use only or in an approved cradle/stand. • Dispose any part in an environmentally sound manner and in accordance with local laws. • M200 product will not be held liable for any damage resulting from user operation that does not comply with the above-stated guidance.
