- Page 1 ePayPOS600 Introduction V1.0 Feitian Technologies Co., Ltd. www.FTsafe.com ...
-
Page 2: Table Of Contents
Introduction Content Chapter 1. ePayPOS600 Product Introduction .................... i 1.1 Product Introduction............................ i 1.2 Product Appearance ............................ i 1.3 Specifications .............................. i i 1.3.1 Dimensions .................................. ii 1.3.2 Keypad .................................... ii 1.3.3 Screen .................................... iii 1.3.4 Communication Interface .............................. iii 1.3.5 Battery and Power Source ............................. iii 1.3.6 Buzzer .................................... iii 1.3.7 Contact IC card Reader .............................. iii 1.3.8 Contactless IC Card Reader ............................ iii 1.3.9 Magnetic Stripe Card Reader ............................ iii 1.3.10 LED Indicators ................................ iv 1.3.11 Features .................................. iv ... -
Page 3: Chapter 1.Epaypos600 Product Introduction
The appearance is compact and portable,suitable for mobile use. Powerful Support magnetic stripe card,contact card and contact less card.Support Micro USB and Bluetooth. Support iOS/Android/Windows system. Certified PCI4.1,EMVL1&L2,PayPass,PayWavecertified Remoteupgrading Firmware can be upgraded remotely,reducing the cost of late development and maintenance. 1.2 Product Appearance The ePayPOS600 product appearanceis shown as follows: Feitian Technologies Co., Ltd. www.FTsafe.com ... -
Page 4: Specifications
Introduction Figure 1ePayPOS600appearance figure 1.3 Specifications 1.3.1 Dimensions 59mm(W)x12.4mm(H)x113.6mm(L) 1.3.2 Keypad ePayPOS600hasan built‐in passwordkeyboard, thekeys aredescribedin thefollowing table. Table1ePayPOS600keyboard Description Name 1. To inputnumbersfrom 0 to 9,amount, password,etc 0~9 Number Keys 2. Thenumber keys 2,8,4,6 respectively for up,down, left,right * menu #menu < function menu Feitian Technologies Co., Ltd. www.FTsafe.com ... -
Page 5: Screen
Introduction To cancel current operation To confirm currentoperation 1.3.3 Screen Uses 128x64 LCD with backlight,supports both Chinese and English. 1.3.4 Communication Interface MicroUSB When the device is connected to the host(forexample,PC) through this interface,this interface provides twofunctions such as charging and data transfer. Bluetooth 4.2 This device can be connected to smart phone or tablet through this interface. ... -
Page 6: Led Indicators
Introduction 1.3.10 LED Indicators The ePayPOS600 comes with four LED indicators, respectively, red, green, yellow and blue. 1.3.11 Features Tamper‐proof and anti‐power‐down protection; Support DUKPT key systems RSA、AES、3DES、SHA‐1、SHA‐256；Support RSA, AES, 3DES,SHA‐1, SHA‐256 Support SM2, SM3, SM4 Physical tamper‐proof has self‐destruction function; Support red evelopment; 1.4 Certifications PCI PTS 4.1 certified; EMV L1/L2; EMV Contactless L1; PBOC3.0 L1/L2;... - Page 7 Introduction charging. • Charging of the battery will typically take between 2 and 4 hours, whilst not in use. • Battery condition is indicated in the display when the device is switched on. • The terminal is fitted with an internal rechargeable battery which cannot be removed or replaced. This battery should be charged for at least 3 hours when using the terminal for the first time. It is recommended that the battery is charged to at least 40% of its capacity every 4 months. Step 2. Turning on the device • Hold down the power button until the display illuminates. • If required, remove the protective film from the display. Step 3. Mobile payment application and pairing Please follow the instructions provided by your bank or service provider to download the mobile application onto your mobile device and to pair it with the SPm3. Step 4. Performing a chip card sale transaction with PIN ...
- Page 8 Introduction contactless symbol on the display. • To read a contactless card it must be positioned in close proximity to the device over the contactless symbol. Once detected the four LEDs at the top of the device will go green and there will be a confirmation beep. • Follow the instructions provided by your bank or service provider to complete the transaction Troubleshooting In the unlikely event you experience issues with this product, please follow the guidelines below. If this does not resolve the issue, please visit www.spirepayments.com or your solution provider for further assistance. No display • Charge the device with the supplied USB cable. • Ensure the USB socket being used is powered. Poor battery life • Ensure the power is being supplied during charging. • Check battery charge indicator is at maximum • Charge for 2 to 4 hours to ensure a full charge whilst not in use. Pairing problems • Refer to pairing instructions. Cannot read Cards • Ensure the magnetic stripe card has been swiped in the correct orientation. • Ensure the chip card has been inserted in the correct orientation. • Check the contactless symbol is on the device display. Ensure the contactless card has been placed at a distance of 0 to 4 cm from the device display. ...
- Page 9 Introduction Caution and Safety Instructions • Do not attempt to disassemble, modify, service or repair any part. • Do not use if damaged or with signs of tampering. • Only use the device with supplied or manufacturer‐certified accessories. • To avoid the potential hazard of electrical shock do not use in wet environments or during an electrical storm. • Do not use in proximity of potentially flammable gases or substances. • Ensure cables used do not cause a trip hazard or risk the device being dropped on to a hard surface. • Do not expose to excessive heat or cold. Only operate between 0 °C and 40 °C. • Before cleaning, disconnect from the electrical outlet. Use only a dry or dampened soft cloth. • Do not immerse, use liquids, sprays or aerosol cleaners. Clean all spillages quickly.
-
Page 10: Fcc Statement
Introduction 1.7 FCC Statement FCC Warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the...
