- Page 1 Westermann Cleanmeleon 800 Elektro Operating Instructions...
-
Page 2: Table Of Contents
Charging the CME 800 Elektro …………………………………… 9 Drive axle and parking brake …………………………………… ... 9 Trouble Shooting ..............10 Exploded drawings ..............11 Plug-in diagrams control unit & speed switch ……………… .11 EC Declaration of Conformity ..........12 Warranty guidelines for Westermann sweepers ....13... -
Page 3: General Information
• Please note that only the operations required for the Cleanmeleon 800 Elektro are explained. For further information on the charger, please refer to the enclosed operating instructions for the charger. -
Page 4: Safety
Only remove the add-on head (column slider) from the basic unit for cleaning. Do not drive the device without this attachment head! The Cleanmeleon 800 Elektro is used only for grooming in dairy farms and can therefore only be used on flat surfaces! -
Page 5: Technical Data
Technical specifications DC motor: • 24 V, 800 watts Batteries / Battery: • 2 x 12V, 44 Ah Working width: • about 800mm Basic unit: • Total weight (including slider) approx. 134 kg • 3-wheel carrier vehicle, steering via front axle •... -
Page 6: Start Preparation
Start Preparation Please check the completeness of the slider Please read the operating instructions and the associated setting instructions before commissioning! Adjustment of the guide bar After delivery, mount the handlebar by attaching it to the screws (see simple arrow, large picture). -
Page 7: Commissioning The Device
Commissioning of the device Before the device can be used, the supplied blue 60 amp fuse must be inserted on the right side of the handlebar. Insert the fuse (see No. 1). Thereon make sure that fuse just plugged in will and contact with Metal housing of the Avoided handlebars becomes Select speed level (min./max .;... -
Page 8: Installation Of The Add-On Head
Installation This is the same process as when removing. Simply slide the slide in and insert the cotter pin. 1) Der Schieber wird soweit ) Nun werden die wie möglich auf die Gabel beiden Stecksplinte eingeschoben. eingesteckt Adjustment of the head The add-on head can be lifted out using the foot pedal (No. -
Page 9: Charging The Cme 800 Elektro
Charging the CMA 800 Elektro Please only use the charger included! 1) Insert the charging plug into the socket on the right side of the bar (see arrow) 2) Set the switch on the charger to 24V. 3) Set the toggle switch on the left and right side of the bar in neutral. -
Page 10: Trouble Shooting
Trouble Shooting The following table contains the most common faults and their remedies In the event of a motor defect or any other defect, please contact your dealer. Problem Cause Remedy • Discharged battery • Charging the battery • • Fuse defective •... -
Page 11: Exploded Drawings
Parts Drawing Sprengzeichnung Seite 6 Wiring diagram control unit Pin diagram speed connector... -
Page 12: Ec Declaration Of Conformity
EC declaration of conformity according to the EC directive 89/392 / EEC The company Westermann GmbH & Co. KG Foppenkamp 14 D 49838 Lengerich (Emsl.) declares under their sole responsibility that their product CLEANMELEON 800 electric, to which this declaration relates corresponds to the relevant basic safety and health requirements of the EC Directive 89/392 / EEC and the EMC Directive 89/336 / EEC. -
Page 13: Warranty Guidelines For Westermann Sweepers
5) The operating instructions for the respective product and safety instructions must be observed. Damage caused by operating errors, improper use or use of accessories that are not approved by Westermann GmbH & Co. KG cannot be recognized as a guarantee. - Page 14 , If a spare part is no longer available (NML), the purchase price paid by you will be reimbursed. 12) The claimed parts or machines are to be sent free to the Westermann plant in Lengerich. After acceptance of the guarantee, the freight costs will be reimbursed.
